GE IC670GBI002 – Bus Interface Unit | GE Fanuc Series 90-70 PLC Platform
The GE IC670GBI002 is a Bus Interface Unit (BIU) designed for the GE Fanuc Series 90-70 programmable controller platform. In distributed I/O architectures, the BIU serves as the critical communication bridge between the remote I/O rack and the main CPU backplane — enabling high-speed, deterministic data exchange across the Genius Bus network. Procurement engineers sourcing replacement or expansion modules for legacy Series 90-70 systems will find the IC670GBI002 to be a direct, specification-matched solution.
At Konmask.com, every IC670GBI002 unit is individually inspected, function-tested, and shipped with full traceability documentation — ensuring your control system returns to operation without compromise.
Complete Technical Specifications
- Part Number: IC670GBI002
- Manufacturer: GE Fanuc Automation (now part of Emerson / GE Vernova)
- Series / Platform: Series 90-70 / Genius I/O
- Module Type: Bus Interface Unit (BIU)
- Function: Interfaces remote I/O drops to the Genius Bus; manages block-level communication
- Bus Protocol: Genius Bus (31.25 kbps / 153.6 kbps / 1 Mbps selectable)
- Max I/O Blocks per Drop: Up to 8 I/O blocks
- Power Supply: Derived from backplane; no external power required
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Mounting: Series 90-70 I/O rack slot
- Weight: Approx. 1,130 g
- Agency Approvals: UL, CE (refer to GE Fanuc datasheet GFK-0898 for full compliance)
- Firmware: Factory-loaded; field-configurable via Logicmaster 90 or Proficy Machine Edition
Proven Application Environments
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and assembly transfer systems using distributed I/O drops
- Pulp & Paper: Winder and rewinder control, stock preparation, and DCS-integrated process loops
- Water & Wastewater: Pump station remote I/O, SCADA-integrated lift stations, and treatment plant automation
- Power Generation: Auxiliary control panels, BOP (Balance of Plant) systems, and turbine auxiliary I/O
- Food & Beverage: Packaging lines, filling systems, and CIP (Clean-in-Place) automation with remote rack configurations
- Oil & Gas: Wellhead control panels and pipeline SCADA remote terminal units (RTUs)
Engineering Advantages
- Seamless Legacy Integration: Drop-in replacement for existing Series 90-70 distributed I/O architectures — no rewiring or rack modification required
- Deterministic Bus Communication: Genius Bus protocol guarantees scan-cycle-synchronized I/O updates, critical for motion and safety-adjacent applications
- Compact Footprint: Single-slot module preserves rack space for additional I/O expansion
- Broad Software Compatibility: Fully supported by Logicmaster 90-70, Proficy Machine Edition, and third-party HMI/SCADA via OPC bridges
- Robust Industrial Rating: Designed for continuous operation in harsh EMI, vibration, and temperature environments typical of heavy industry
System Architecture & Signal Flow
In a typical Series 90-70 distributed I/O configuration, the IC670GBI002 BIU occupies a slot in the remote I/O rack. The CPU communicates over the Genius Bus coaxial cable to the BIU, which then manages all I/O block transactions within its drop. The BIU handles address assignment, fault reporting, and data packetization — offloading bus management from the CPU and enabling scan times as low as 1 ms per drop at 1 Mbps bus speed.
Signal path: CPU Backplane → Genius Bus Cable → IC670GBI002 BIU → Local I/O Blocks (IC670MDL, IC670ALG, etc.)
Sourcing & Quality Verification
- ✅ Genuine GE Fanuc hardware — no counterfeit or remarked components
- ✅ Individual functional test — each unit powered and bus-communication verified prior to shipment
- ✅ Visual inspection — connector integrity, PCB condition, and label authenticity confirmed
- ✅ Anti-static packaging — ESD-safe bags and foam-lined cartons for safe transit
- ✅ Traceability documentation — test report and inspection checklist included with every order
- ✅ 90-day warranty — covering manufacturing defects and functional failures under normal operating conditions
Procurement Process
- Confirm compatibility: Verify your Series 90-70 rack type and Genius Bus configuration against GE Fanuc GFK-0898 / GFK-0867 documentation
- Request a quote: Contact support@konmask.com with your required quantity and delivery timeline
- Order confirmation: Receive proforma invoice with unit price, lead time, and shipping options (DHL / FedEx / sea freight)
- Shipment & tracking: Units dispatched within 1–3 business days; tracking number provided upon dispatch
- Incoming inspection: Use provided test report to validate unit against your acceptance criteria
Technical FAQ
Q: Is the IC670GBI002 compatible with the IC693 CPU series?
A: The IC670GBI002 is designed for the Series 90-70 I/O rack (IC670 family). It communicates with IC693 CPUs via the Genius Bus — the CPU must have a Genius Bus Controller (e.g., IC693BEM331) installed to interface with IC670 remote drops.
Q: Can this BIU be configured without Logicmaster 90?
A: Yes. Proficy Machine Edition (PME) v8.0 and later fully supports Series 90-70 hardware configuration, including BIU address and bus speed settings.
Q: What is the maximum cable length on the Genius Bus?
A: At 153.6 kbps, the Genius Bus supports up to 750 m (2,460 ft) of RG-6 coaxial cable. At 1 Mbps, the maximum distance is reduced to 75 m (246 ft).
Q: Do you offer exchange / repair services?
A: Yes. Contact support@konmask.com to discuss exchange pricing or board-level repair options for IC670GBI002 units with physical damage.
