GE IC693ALG442 Analog Input/Output Module – Series 90-30
When a critical analog signal chain fails on the plant floor — a temperature loop goes open, a pressure transmitter loses its 4–20 mA feedback, or a proportional valve stops responding — the entire production line can halt within seconds. Without a reliable analog I/O module at the heart of your GE Series 90-30 PLC rack, operators lose visibility into process variables, safety interlocks may trip, and unplanned downtime costs mount rapidly. The GE IC693ALG442 is the precision interface that keeps your analog world connected to your control system, ensuring continuous, accurate signal exchange between field instruments and the PLC CPU.
The IC693ALG442 occupies a well-established position within GE’s Series 90-30 analog I/O family, offering a combined 4-channel analog input and 2-channel analog output configuration in a single module slot. As part of the IC693 series — one of the most widely deployed PLC platforms in North American and global process industries — this module benefits from decades of field-proven reliability, broad third-party compatibility, and an extensive installed base across manufacturing, oil & gas, water treatment, and power generation facilities worldwide.
Technical Specifications
- Model Number: IC693ALG442
- Series: GE Series 90-30
- Module Type: Combination Analog Input/Output
- Analog Inputs: 4 channels
- Analog Outputs: 2 channels
- Input Signal Range: ±10 V DC / 4–20 mA (software selectable per channel)
- Output Signal Range: ±10 V DC / 4–20 mA (software selectable per channel)
- Resolution: 12-bit (1 in 4,096)
- Isolation: Optical isolation between field and backplane
- Power Consumption: Supplied via Series 90-30 backplane
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Module Weight: Approx. 380 g
- Backplane Compatibility: Series 90-30 5-slot, 10-slot, and expansion racks
- Programming Software: GE Proficy Machine Edition (ME)
Key Features & Benefits
- Dual-mode signal flexibility: Each input and output channel supports both voltage (±10 V) and current (4–20 mA) modes, eliminating the need for separate modules for different field device types.
- 12-bit resolution: Provides 4,096 discrete levels of measurement accuracy, suitable for precise process control in temperature, pressure, flow, and level applications.
- Optical isolation: Protects the PLC backplane and CPU from field-side transients, ground loops, and electrical noise common in industrial environments.
- Compact combined I/O: Integrating 4 inputs and 2 outputs in one slot reduces rack space consumption and lowers total system cost compared to using separate input and output modules.
- Hot-swap capable rack design: Compatible with Series 90-30 racks that support module replacement without full system shutdown (subject to system configuration).
- Wide installed base: Extensive global deployment means readily available spare parts, experienced integrators, and comprehensive documentation support.
- Software-configurable channels: Channel parameters are set via Proficy ME software, reducing wiring changes when reconfiguring signal types.
Industry & Equipment Applications
- Oil & Gas: Pipeline pressure monitoring, flow control valve positioning, separator level control
- Water & Wastewater Treatment: Pump speed control via VFD analog reference, pH and turbidity sensor inputs, chemical dosing outputs
- Power Generation: Turbine inlet temperature monitoring, generator excitation control analog signals
- Food & Beverage: Pasteurization temperature loops, filling line pressure feedback, conveyor speed references
- Automotive Manufacturing: Paint booth climate control, robotic welding current feedback, press force monitoring
- HVAC & Building Automation: Chiller setpoint outputs, air handling unit damper position feedback
- Chemical Processing: Reactor temperature and pressure loop control, flow ratio control
System Integration & Compatible Parts
The IC693ALG442 is designed for seamless integration within the GE Series 90-30 ecosystem. Compatible and commonly paired components include:
- CPUs: IC693CPU311, IC693CPU313, IC693CPU323, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU364, IC693CPU374
- Power Supplies: IC693PWR321, IC693PWR322, IC693PWR330, IC693PWR331
- Backplane Racks: IC693CHS391 (5-slot), IC693CHS392 (10-slot), IC693CHS393 (5-slot expansion), IC693CHS398 (10-slot expansion)
- Communications Modules: IC693CMM311, IC693CMM321 (Ethernet), IC693PBS301 (PROFIBUS-DP)
- Related Analog Modules: IC693ALG220 (4-ch analog input), IC693ALG390 (4-ch analog output), IC693ALG391 (8-ch analog output)
- Programming Software: GE Proficy Machine Edition Logic Developer – PLC
Our Quality Assurance Process
At Konmask.com, every GE IC693ALG442 module undergoes a rigorous multi-stage verification process before shipment:
- Visual Inspection: Examination of PCB, connectors, and housing for physical damage, corrosion, or counterfeit indicators
- Label & Traceability Verification: Cross-referencing of GE part numbers, date codes, and serial numbers against manufacturer records
- Functional Testing: Where applicable, modules are bench-tested in a Series 90-30 rack environment to verify analog channel response
- Anti-Static Packaging: All modules are shipped in ESD-safe bags with foam cushioning to prevent transit damage
- Documentation: Certificate of conformance and test records available upon request
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com
- Provide your required quantity, delivery timeline, and destination country
- Receive a formal quotation with lead time and shipping options within 24 business hours
- Confirm the order and receive proforma invoice for payment processing
- Module ships with full tracking; typical international delivery 5–10 business days
For urgent requirements or large-volume orders, please call or WhatsApp: +0086 19859288691
Why Choose Konmask.com?
- ✅ Specialized in industrial automation components — PLC, DCS, HMI, drives, and more from leading global brands
- ✅ Genuine parts sourcing — strict supplier qualification and anti-counterfeit verification on every unit
- ✅ Global export experience — serving clients in Southeast Asia, Middle East, Europe, and the Americas
- ✅ Fast response — dedicated B2B inquiry team responds within 24 hours
- ✅ Flexible logistics — DHL, FedEx, UPS, sea freight, and consolidated shipment options
- ✅ After-sales support — technical consultation and warranty claim assistance
Frequently Asked Questions
Q: Is the IC693ALG442 compatible with all Series 90-30 CPUs?
A: Yes, the IC693ALG442 is compatible with all standard Series 90-30 CPUs. Configuration is performed through GE Proficy Machine Edition software, where you assign the module to a rack slot and configure each channel’s signal type and range.
Q: Can I mix voltage and current channels on the same module?
A: Yes. Each input and output channel on the IC693ALG442 can be independently configured for either voltage (±10 V) or current (4–20 mA) mode via software, providing maximum flexibility for mixed field device installations.
Q: Do you supply new, refurbished, or surplus units?
A: Konmask.com supplies both new-in-box and tested surplus/refurbished units. The condition is clearly stated in the quotation. All units pass our quality assurance process regardless of condition grade.
Q: What is the lead time for the IC693ALG442?
A: Lead time depends on current stock levels. In-stock units typically ship within 1–3 business days. For out-of-stock items, lead time is quoted at the time of inquiry, typically 1–3 weeks for sourcing.
Q: Can you provide a datasheet or technical manual?
A: Yes. GE Series 90-30 Analog I/O Module documentation (GFK-0898 and related manuals) is available. Contact us and we will provide the relevant technical documentation with your quotation.
Q: Do you accept returns if the module is defective?
A: Yes. We offer a warranty period on all units. If a module is found to be defective upon arrival, please contact us within the warranty window and we will arrange replacement or refund per our terms.
