GE DS200SHVMG1AED – Turbine Control Module | Mark VI Series Platform
Engineering Background
The DS200SHVMG1AED is a high-voltage interface and turbine control module developed by GE as part of the Mark VI Turbine Control System — one of the most widely deployed distributed control architectures in power generation and heavy industrial environments. Designed to operate within GE’s redundant I/O framework, this module serves as a critical bridge between field instrumentation and the Mark VI controller backbone.
Product Positioning
Targeted at maintenance engineers, OEM integrators, and procurement specialists managing gas turbine, steam turbine, and combined-cycle power plant control systems. The DS200SHVMG1AED is a direct replacement-grade module suitable for both emergency sparing and planned lifecycle upgrades. Konmask supplies this module with full traceability documentation and pre-shipment functional verification.
Complete Technical Specifications
| Part Number | DS200SHVMG1AED |
| Manufacturer | GE (General Electric) |
| Series / Platform | Mark VI Turbine Control System |
| Module Type | High-Voltage Interface / Turbine Control Module |
| Form Factor | PCB-based plug-in module (Mark VI rack-compatible) |
| Operating Voltage | Refer to GE Mark VI system documentation |
| Communication Interface | Mark VI internal I/O bus |
| Operating Temperature | 0°C to +60°C (standard industrial range) |
| Weight | ~1,000 g (module + packaging) |
| Condition Available | New surplus / Refurbished / Tested used |
| Warranty | 12 months from shipment date |
| Compliance | CE, RoHS (where applicable) |
| Country of Origin | USA |
Proven Application Environments
- Gas turbine control systems (Frame 5, Frame 6, Frame 7, Frame 9 series)
- Steam turbine governor and protection systems
- Combined-cycle power plant (CCPP) automation
- Compressor station control and surge protection
- Offshore and onshore oil & gas processing facilities
- Industrial co-generation and district energy plants
- Petrochemical and refinery rotating equipment control
Engineering Advantages
- Drop-in Replacement: 100% pin-compatible with existing Mark VI rack installations — no firmware reconfiguration required in most applications.
- Redundancy Support: Fully compatible with GE’s TMR (Triple Modular Redundancy) and dual-redundant control architectures.
- High-Voltage Interface Capability: Designed to handle high-voltage field signals with built-in isolation and protection circuitry.
- Proven Field Reliability: Deployed across thousands of turbine installations globally with documented MTBF performance.
- Rapid Deployment: Pre-tested modules reduce commissioning time and minimize plant downtime during emergency replacements.
System Architecture & Signal Flow
Within the Mark VI architecture, the DS200SHVMG1AED interfaces directly with the VCMI (VME Communication Module Interface) and PPRO (Protection Processor) boards. Field signals — including high-voltage discrete inputs from turbine protection circuits — are conditioned, isolated, and transmitted to the Mark VI controller via the internal I/O bus. The module supports both simplex and redundant signal paths depending on system configuration.
Signal flow: Field Instrumentation → DS200SHVMG1AED (HV Interface & Conditioning) → Mark VI I/O Bus → VCMI/PPRO Controller → HMI / SCADA
Sourcing & Quality Verification
- Source Traceability: All modules are sourced from verified OEM channels, authorized distributors, or decommissioned plant inventories with documented chain of custody.
- Pre-Shipment Testing: Each unit undergoes functional power-on verification and visual inspection prior to dispatch.
- Counterfeit Mitigation: Konmask applies component-level authentication checks including PCB marking verification, date code analysis, and supplier cross-referencing.
- Packaging: ESD-safe anti-static packaging with moisture barrier and shock-absorbing foam insert.
- Documentation: Certificate of conformance, test report, and packing list included with every shipment.
Procurement Process
- Inquiry: Submit your part number, required quantity, and delivery timeline via email or the contact form below.
- Quotation: Konmask responds within 1 business day with pricing, lead time, and stock availability confirmation.
- Order Confirmation: Purchase order accepted via email. Proforma invoice issued for payment processing.
- Quality Check & Dispatch: Module tested, packaged, and dispatched with full documentation within agreed lead time.
- Delivery & Support: Global shipping via DHL / FedEx / UPS with tracking. Post-delivery technical support available.
Technical FAQ
Q: Is the DS200SHVMG1AED compatible with all Mark VI variants?
A: It is designed for the GE Mark VI platform. Compatibility with specific sub-variants (Mark VIe, Mark VIs) should be confirmed against your system’s I/O configuration drawing. Contact Konmask for application-specific verification.
Q: Can this module be used in a TMR (Triple Modular Redundancy) configuration?
A: Yes. The DS200SHVMG1AED supports TMR architectures when installed in sets of three within a properly configured Mark VI rack.
Q: What is the lead time for this module?
A: In-stock units ship within 3–5 business days. For out-of-stock inquiries, typical lead time is 2–6 weeks depending on sourcing channel.
Q: Do you provide a warranty?
A: Yes. All modules carry a 12-month warranty from the date of shipment, covering functional failure under normal operating conditions.
Q: Can Konmask assist with installation or commissioning?
A: Konmask provides remote technical guidance and documentation support. On-site commissioning services can be arranged through our partner network upon request.
