GE IC693CHS391 – 10-Slot CPU Base Rack | Series 90-30 PLC Platform
Engineering Background
The GE Fanuc Series 90-30 is one of the most widely deployed mid-range PLC platforms in North American industrial automation, with an installed base spanning discrete manufacturing, process control, utilities, and building automation. The IC693CHS391 is the primary CPU-bearing base rack in this family, providing the structural and electrical backbone for complete controller assemblies.
Product Positioning
The IC693CHS391 is a 10-slot CPU base rack designed to house the CPU module (specifically paired with CPU331 and compatible variants), I/O modules, and communication adapters within the Series 90-30 architecture. It serves as the central integration point for power, backplane communication, and module addressing. Procurement engineers specifying replacement or expansion racks for existing Series 90-30 systems will find this unit a direct, drop-in compatible solution.
Complete Technical Specifications
| Part Number | IC693CHS391 |
| Manufacturer | GE Fanuc / General Electric |
| Series / Platform | Series 90-30 PLC |
| Module Type | CPU Base Rack |
| Total Slots | 10 (1 dedicated CPU slot + 9 I/O / option module slots) |
| Compatible CPU | CPU331 (IC693CPU331); also compatible with CPU340, CPU341, CPU350, CPU360, CPU363, CPU374 |
| Backplane Bus | Series 90-30 parallel backplane |
| Power Supply Interface | Accepts Series 90-30 power supply modules (e.g., IC693PWR321, IC693PWR330, IC693PWR331) |
| Expansion Capability | Supports expansion racks via IC693CBL300/301/302/303 cables |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | 950 g (approx.) |
| Compliance | UL Listed, CE Marked, CSA Certified |
Proven Application Environments
- Discrete Manufacturing: Automotive assembly lines, stamping, and robotic cell controllers using CPU331-based Series 90-30 systems
- Process Control: Water/wastewater treatment, chemical dosing, and HVAC sequencing where mid-range PLC reliability is critical
- Utilities & Power Distribution: Substation automation and load management panels with existing Series 90-30 infrastructure
- Building Automation: Legacy BAS integrations requiring Series 90-30 rack expansion or base replacement
- OEM Machine Builders: Retrofit and spare-parts programs for machines originally built on the Series 90-30 platform
Engineering Advantages
- 10-slot capacity maximizes I/O density in a single base, reducing the need for expansion racks in most mid-scale applications
- CPU-dedicated slot ensures deterministic backplane arbitration and eliminates slot-addressing conflicts
- Broad CPU compatibility across the Series 90-30 CPU family allows flexible upgrades without rack replacement
- Robust backplane design supports mixed analog, digital, and specialty module configurations simultaneously
- Field-proven reliability with MTBF data consistent with GE Fanuc’s industrial-grade component standards
System Architecture & Signal Flow
The IC693CHS391 backplane provides a shared parallel bus connecting the CPU slot to all nine I/O module slots. The CPU module (CPU331) occupies Slot 1 (leftmost position). The power supply module mounts to the dedicated PSU bay on the left end of the rack and distributes regulated DC power across the backplane to all installed modules. I/O modules in Slots 2–10 communicate with the CPU via the backplane bus at the rack’s native scan rate. Expansion racks connect via the rack expansion port using Series 90-30 expansion cables, extending the I/O address space beyond the base rack.
Slot Assignment Summary:
- PSU Bay: Power supply module (IC693PWR3xx series)
- Slot 1: CPU module (IC693CPU331 or compatible)
- Slots 2–10: I/O modules, communication adapters, or specialty modules
Sourcing & Quality Verification
All IC693CHS391 units offered through Konmask.com are sourced from verified industrial surplus channels and authorized distribution networks. Each unit undergoes the following pre-shipment process:
- Visual inspection for physical damage, bent pins, and label integrity
- Backplane connector continuity check
- Firmware/revision label verification against GE Fanuc revision history
- Anti-static packaging with humidity indicator card
- Lot traceability documentation available upon request for regulated industries
Procurement Process
- RFQ / Bulk Orders: Contact support@konmask.com for volume pricing, lead times, and blanket PO arrangements
- Lead Time: In-stock units ship within 1–3 business days; out-of-stock units subject to sourcing lead time (typically 5–15 business days)
- Export Compliance: ECCN classification and export documentation available for international shipments
- Payment Terms: T/T, PayPal, and credit card accepted; net terms available for qualified accounts
- Returns: 30-day return window for unused, uninstalled units in original packaging
Technical FAQ
Q: Is the IC693CHS391 compatible with CPU340 and CPU350?
A: Yes. While the rack is specifically paired with CPU331 in many configurations, it is mechanically and electrically compatible with all Series 90-30 CPU modules including CPU340, CPU341, CPU350, CPU360, CPU363, and CPU374.
Q: Can this rack be used as an expansion rack?
A: No. The IC693CHS391 is a CPU base rack. For expansion racks, refer to IC693CHS392 (5-slot) or IC693CHS398 (10-slot expansion). Expansion racks do not have a CPU slot.
Q: What power supply is required?
A: Any Series 90-30 compatible power supply (IC693PWR321, IC693PWR330, or IC693PWR331) is compatible. Power supply selection depends on input voltage requirements (120/240 VAC or 24 VDC) and total module load.
Q: Is a warranty included?
A: All units carry a 90-day functional warranty against defects in materials and workmanship. Extended warranty options are available — contact us for details.
Q: Can I request a test report or inspection certificate?
A: Yes. Inspection documentation and test reports are available upon request for quality-critical procurement. Please specify requirements at time of order.
