GE IC693PWR331 – High-Reliability AC Power Supply Module | Series 90-30 PLC Platform
Engineering Background
The GE Fanuc IC693PWR331 is a standard AC input power supply module designed for the Series 90-30 programmable logic controller platform — one of the most widely deployed mid-range PLC architectures in global industrial automation. Originally developed under GE Fanuc Automation and subsequently transitioned to GE Intelligent Platforms (now Emerson), the Series 90-30 system remains a backbone controller in process, discrete, and hybrid manufacturing environments worldwide.
Product Positioning
The IC693PWR331 serves as the primary power source for Series 90-30 CPU and I/O baseplate assemblies. It accepts standard 120/240VAC utility power and delivers regulated 5VDC and 24VDC bus power to the backplane, supporting full-rack configurations. For procurement engineers managing legacy system maintenance, expansion projects, or spare-parts inventory, the IC693PWR331 represents a critical, long-lead-time component that demands verified sourcing.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IC693PWR331 |
| Platform | GE Series 90-30 PLC |
| Module Type | AC Input Power Supply |
| Input Voltage | 120/240 VAC (auto-ranging or jumper-selectable) |
| Input Frequency | 47–63 Hz |
| Input Current (120VAC) | ≤ 2.0 A |
| Input Current (240VAC) | ≤ 1.0 A |
| Output Power (Total) | 30 W |
| +5 VDC Output | Up to 4.0 A |
| +24 VDC Output (Isolated) | Up to 0.8 A |
| Backplane Bus | Series 90-30 standard backplane |
| Isolation | Input-to-output galvanic isolation |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | Occupies 1 slot on Series 90-30 baseplate |
| Weight | Approx. 520 g |
| Certifications | UL Listed, CE Marked, cUL |
| Mounting | Baseplate slot (leftmost position) |
| Status Indicators | PWR LED (green = normal operation) |
Proven Application Environments
- Automotive Manufacturing — Body-in-white assembly lines, paint shop conveyors, and press control systems using Series 90-30 racks
- Food & Beverage Processing — Packaging lines, filling stations, and batch control panels requiring 24/7 uptime
- Water & Wastewater Treatment — SCADA-integrated pump control and chemical dosing systems
- Oil & Gas Upstream/Midstream — Remote wellhead monitoring and pipeline valve control panels
- Pharmaceutical Manufacturing — GMP-compliant process control with validated PLC configurations
- Power Generation & Utilities — Auxiliary control systems in thermal and hydro generation facilities
- Material Handling & Logistics — Conveyor routing, sortation, and warehouse automation
Engineering Advantages
- Dual-Voltage Input Flexibility — Accepts both 120VAC and 240VAC, simplifying deployment across North American and international facilities without hardware changes
- Isolated 24VDC Output — Provides clean, isolated 24VDC for field device power, reducing noise coupling from sensor circuits into the PLC backplane
- Thermal Robustness — Rated to +60°C ambient, suitable for non-air-conditioned enclosures in industrial environments
- Drop-in Replacement Compatibility — Direct form-fit-function replacement for existing IC693PWR331 installations; no firmware or configuration changes required
- Proven MTBF — Long field service history across millions of installed Series 90-30 systems globally
- Compact Single-Slot Footprint — Maximizes available I/O slots on 5-slot, 10-slot, and expansion baseplates
System Architecture & Signal Flow
The IC693PWR331 installs in the leftmost slot of any Series 90-30 baseplate (5-slot: IC693CHS391; 10-slot: IC693CHS392; expansion: IC693CHS393/398). AC mains connect to the module’s terminal block. The module converts and regulates AC input to +5VDC backplane bus power (logic supply) and an isolated +24VDC rail (field device supply). The CPU module (e.g., IC693CPU374) and all I/O modules draw from the 5VDC bus; field-side 24VDC sensors and actuators may draw from the isolated 24VDC output. A single green PWR LED provides local health indication. No external fusing is required for the backplane bus; however, field wiring to the 24VDC output should be protected per local electrical codes (IEC 60364 / NEC).
Sourcing & Quality Verification
Konmask.com sources IC693PWR331 modules through established industrial automation distribution channels. Each unit undergoes the following verification process before shipment:
- Visual inspection for physical damage, corrosion, and counterfeit indicators
- Label and date-code verification against known-good reference units
- Functional power-on test: input voltage application, output voltage measurement on 5VDC and 24VDC rails
- Backplane connector pin inspection (no bent pins, no oxidation)
- Anti-static packaging with humidity indicator card
Certificates of conformance and test reports are available upon request for regulated industries (pharmaceutical, defense, utilities).
Procurement Process
- Step 1 — Inquiry: Submit your part number, required quantity, and delivery timeline via email or phone
- Step 2 — Quote: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options
- Step 3 — Order Confirmation: Purchase order or proforma invoice accepted; T/T wire transfer and major credit cards supported
- Step 4 — Quality Check & Dispatch: Unit tested, documented, and dispatched with tracking within agreed lead time
- Step 5 — After-Sales Support: Technical support available post-delivery for installation verification and commissioning questions
Technical FAQ
Q: Is the IC693PWR331 compatible with all Series 90-30 baseplates?
A: Yes. It is compatible with all standard Series 90-30 baseplates including IC693CHS391 (5-slot), IC693CHS392 (10-slot), IC693CHS393, and IC693CHS398 expansion racks.
Q: Can the IC693PWR331 power a full 10-slot rack with all I/O modules populated?
A: The 30W total output capacity must not be exceeded. For high-density I/O configurations, calculate total backplane current draw from all installed modules. If the 5VDC load exceeds 4.0A, a second power supply or a higher-capacity unit (IC693PWR321 — 40W) should be considered.
Q: What is the difference between IC693PWR331 and IC693PWR321?
A: The IC693PWR331 provides 30W total output (4.0A @ 5VDC, 0.8A @ 24VDC). The IC693PWR321 provides 40W total output (6.0A @ 5VDC, 1.0A @ 24VDC). Both accept 120/240VAC input. Select based on total backplane power budget.
Q: Does this module support hot-swap replacement?
A: No. The Series 90-30 power supply must be replaced with the rack de-energized. Always follow lockout/tagout (LOTO) procedures before servicing.
Q: What warranty is provided?
A: Konmask provides a 90-day functional warranty on all verified units. Extended warranty options are available — contact us for details.
Q: Can you provide documentation or datasheets?
A: Yes. GE Fanuc Series 90-30 PLC Hardware Reference Manual (GFK-0356) and the IC693PWR331 datasheet are available upon request.
