Distributed I/O Solution – GE IC693CHS393 | Series 90-30 Remote Expansion Chassis
Where This Product Is Used
The GE IC693CHS393 is a 9-slot remote expansion chassis designed for the GE Series 90-30 PLC platform. It is deployed wherever engineers need to extend I/O capacity beyond the local rack — placing field-level I/O modules physically close to the process equipment while maintaining centralized CPU control. Typical deployment environments include:
- Discrete Manufacturing Lines — Automotive assembly, packaging machinery, and conveyor systems where I/O points are spread across a large floor area.
- Oil & Gas Facilities — Wellhead control panels, pipeline monitoring stations, and compressor skids requiring remote I/O in hazardous or remote locations.
- Water & Wastewater Treatment Plants — Pump stations, lift stations, and filtration systems distributed across large plant footprints.
- Power Generation & Utilities — Substation automation and generator control where I/O must be located near switchgear.
- Food & Beverage Processing — Filling lines, CIP systems, and batch reactors with distributed sensor/actuator networks.
- Building Automation & HVAC — Large commercial facilities using Series 90-30 for centralized BMS with remote zone control.
Technical Specifications
- Part Number: IC693CHS393
- Series: GE Series 90-30
- Chassis Type: Remote Expansion Chassis
- Slot Count: 9 I/O module slots
- Backplane Bus: Series 90-30 parallel I/O bus
- Power Supply: Requires separate Series 90-30 power supply module (e.g., IC693PWR321/322/330)
- Communication: Connects via Series 90-30 Bus Expansion Cable (IC693CBL300/301/302 series)
- Compatible CPUs: All Series 90-30 CPU modules (IC693CPU311 through IC693CPU374)
- Module Compatibility: Accepts all standard Series 90-30 I/O and specialty modules
- Weight: 1.9 kg (chassis only, without modules)
- Mounting: DIN rail or panel mount
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
Why Engineers Specify This Model
- Proven Platform Longevity: The Series 90-30 has been in continuous production since the early 1990s. The IC693CHS393 is a mature, field-proven chassis with an extensive installed base and well-documented behavior.
- 9-Slot Capacity: Provides maximum I/O density in a single remote chassis — accommodating up to 9 mixed I/O or specialty modules without requiring an additional expansion chassis.
- Reduced Field Wiring Cost: Placing the chassis near field devices eliminates long cable runs from sensors and actuators back to a central panel, significantly reducing installation labor and material costs.
- Flexible Topology: Multiple IC693CHS393 chassis can be daisy-chained from a single CPU rack, enabling scalable distributed architectures without additional communication processors.
- Broad Module Compatibility: Accepts the full range of Series 90-30 discrete, analog, specialty, and communications modules — no module restrictions in remote slots.
- Simplified Spare Parts Management: A single chassis model covers all remote expansion needs in the Series 90-30 family, reducing spare parts inventory complexity.
Complete System Bill of Materials
A typical remote I/O node built around the IC693CHS393 requires the following components:
- IC693CHS393 — Remote Expansion Chassis (this item)
- IC693PWR321 / IC693PWR322 / IC693PWR330 — Series 90-30 Power Supply (select per voltage requirement)
- IC693CBL300 / IC693CBL301 / IC693CBL302 — Bus Expansion Cable (select per distance: 0.6 m / 1.8 m / 7.6 m)
- IC693MDL340 / IC693MDL654 / IC693ALG221 — I/O Modules (discrete input, discrete output, or analog — per application)
- IC693CHS391 / IC693CHS392 — Local or additional expansion chassis (if more slots are required at the CPU rack)
Compliance & Industry Standards
- UL Listed (UL 508 — Industrial Control Equipment)
- CE Marked — Compliant with EU Low Voltage Directive and EMC Directive
- RoHS Compliant
- Designed for use in NFPA 79 compliant machine control panels
- Compatible with IEC 61131-3 programming environments via GE Proficy Machine Edition
Quality Assurance & Sourcing
All GE IC693CHS393 units offered by Konmask.com are sourced through verified industrial automation supply channels. Each unit undergoes the following before shipment:
- Visual inspection for physical damage, bent pins, and label integrity
- Verification of part number and revision markings against GE documentation
- Anti-static packaging with humidity indicator cards for long-term storage protection
- Optional functional test available upon request — contact us for details
We supply both new-in-box (NIB) and factory-refurbished units. Condition is clearly stated on each listing. All refurbished units carry a 90-day replacement warranty.
How to Source This Part
- In-Stock Orders: Add to cart and check out directly. Most orders ship within 1–3 business days from our warehouse.
- Bulk / Project Quantities: Contact us for volume pricing and lead time confirmation before placing large orders.
- Urgent Requirements: Mark your inquiry as urgent — we will prioritize sourcing and provide a same-day response during business hours.
- Cross-Reference / Replacement: If you are replacing a different chassis model, contact us with your current part number and we will confirm compatibility.
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Can the IC693CHS393 be used as the main (local) CPU chassis?
A: No. The IC693CHS393 is a remote expansion chassis only. It does not accept a CPU module. The CPU must reside in a local base chassis (IC693CHS391 or IC693CHS392).
Q: How many IC693CHS393 chassis can I connect to one CPU?
A: The Series 90-30 supports up to 7 expansion racks (local + remote) per CPU, depending on the CPU model. Consult the GE Series 90-30 Hardware Reference Manual (GFK-0356) for your specific CPU’s expansion limits.
Q: What is the maximum cable distance between the CPU rack and a remote IC693CHS393?
A: Using IC693CBL302 (7.6 m) cables in series, the maximum total bus expansion distance is approximately 15 meters. For longer distances, a Bus Transmitter Module (IC693BEM320) is required.
Q: Does the IC693CHS393 require its own power supply?
A: Yes. Each remote chassis requires a dedicated Series 90-30 power supply module installed in its leftmost slot. The CPU rack power supply does not power remote chassis.
Q: Is the IC693CHS393 compatible with the Series 90-70 or VersaMax platforms?
A: No. The IC693CHS393 is exclusively compatible with the Series 90-30 platform. Series 90-70 uses IC697 chassis; VersaMax uses its own modular I/O system.
