GE IC693UDR005FP1 – Micro Programmable Controller with Relay Outputs | Series 90-30 Platform
Engineering Background: The GE IC693UDR005FP1 is a compact, high-reliability programmable controller from GE’s renowned Series 90-30 family — one of the most widely deployed PLC platforms in North American industrial automation. Designed for applications demanding deterministic relay-output control in space-constrained panel environments, this unit combines the processing power of the Series 90-30 CPU architecture with integrated discrete I/O in a single-module footprint.
Product Positioning: Targeted at procurement engineers and MRO specialists sourcing verified replacement or expansion modules for existing Series 90-30 installations. The IC693UDR005FP1 is a direct-fit solution for OEM machine builders, utilities, water treatment facilities, and discrete manufacturing lines requiring proven relay-output logic control without the overhead of a full rack-based system.
Complete Technical Specifications
- Part Number / SKU: IC693UDR005FP1
- Manufacturer: GE (General Electric Automation & Controls)
- Product Family: Series 90-30 Micro PLC
- Controller Type: Micro Programmable Logic Controller (PLC)
- Output Type: Relay (UDR — Universal Digital Relay)
- Form Factor: Compact / Standalone Module
- Weight: 4,780 g (shipping weight)
- Country of Origin: United States
- Programming Standard: IEC 61131-3 compatible via GE Proficy Machine Edition
- Communication: Serial / SNP protocol (Series 90-30 standard)
- Power Supply: Per Series 90-30 module specification (refer to GE datasheet GFK-0356)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Certifications: UL Listed, CE Marked, cUL
Proven Application Environments
- Discrete manufacturing — assembly lines, conveyor control, machine interlocking
- Water & wastewater treatment — pump sequencing, valve actuation, level control
- Oil & gas — wellhead control panels, skid-mounted automation
- Building automation — HVAC relay logic, access control integration
- Utilities & power distribution — substation auxiliary control, load shedding
- OEM machine builders — embedded controller for compact machine panels
- MRO replacement — direct drop-in for existing Series 90-30 IC693UDR005 installations
Engineering Advantages
- Relay Output Isolation: Inherent galvanic isolation between control logic and field devices — eliminates ground loop interference in mixed-voltage environments
- Series 90-30 Ecosystem Compatibility: Fully interoperable with existing Series 90-30 racks, power supplies, I/O modules, and Proficy ME programming environment
- Compact Footprint: Integrates CPU and I/O in a single module — reduces panel space requirements vs. modular rack configurations
- Deterministic Scan Cycle: Predictable ladder logic execution for time-critical relay sequencing applications
- Long Field Service Record: IC693 platform has 30+ years of proven deployment across North American industrial infrastructure
- Low Maintenance: Solid-state CPU with relay output stage — no moving parts in logic section; relay contacts rated for extended cycle life
System Architecture & Signal Flow
The IC693UDR005FP1 operates as a self-contained micro PLC within the Series 90-30 architecture. The CPU executes the user ladder/function block program on a fixed scan cycle. Discrete input signals are read at the start of each scan into the input image table; the program logic processes these against internal coils and timers; relay output coils are energized at the end of each scan via the output image table. The relay output stage provides normally-open (NO) dry contacts rated for both AC and DC field loads, enabling direct interface to solenoids, motor starters, pilot lights, and other field devices without intermediate relay panels.
Programming and monitoring are performed via the RS-232 serial port using GE Proficy Machine Edition (PME) software over the SNP protocol. The module supports online monitoring, forced I/O, and program upload/download without power cycling.
Sourcing & Quality Verification
- Stock Condition: Surplus / Refurbished — each unit inspected prior to shipment
- Authenticity: All GE Series 90-30 modules sourced through verified industrial surplus channels; counterfeit screening performed on receipt
- Functional Testing: Power-on and I/O point verification performed where applicable
- Packaging: Anti-static bag + foam-lined carton; ESD-safe handling throughout
- Warranty: 90-day Konmask operational warranty against DOA / latent defects
- Documentation: GE datasheet and wiring diagram available upon request
Procurement Process
- Confirm part number IC693UDR005FP1 against your BOM or existing module label
- Submit inquiry or place order via Konmask.com product page
- Receive order confirmation with lead time and shipping estimate within 1 business day
- Unit ships in ESD-safe packaging with packing slip and inspection record
- Post-delivery technical support available via support@konmask.com
Technical FAQ
Q: Is IC693UDR005FP1 compatible with my existing Series 90-30 rack?
A: Yes — the IC693UDR005FP1 is designed for the Series 90-30 platform and is physically and electrically compatible with standard IC693 racks and power supplies.
Q: What programming software is required?
A: GE Proficy Machine Edition (PME) is the current supported programming environment. Legacy Logicmaster 90-30 software may also be used for older firmware revisions.
Q: Can relay outputs switch AC and DC loads?
A: Yes — relay contacts are rated for both AC and DC field voltages. Refer to the GE IC693UDR005 datasheet for exact contact ratings per output point.
Q: What is the difference between IC693UDR005 and IC693UDR005FP1?
A: The FP1 suffix denotes a firmware/hardware revision. Functionally equivalent for most applications; confirm firmware compatibility with your PME version if required.
Q: Do you provide a certificate of conformance?
A: A Konmask inspection record is included with each shipment. A formal CoC can be arranged for volume orders — contact support@konmask.com.
