Industrial Automation Solution – GE Fanuc IC695CPE330-ABAF | PACSystems RX3i
Where This Product Is Used
The GE Fanuc IC695CPE330-ABAF is a high-performance CPU module deployed across demanding industrial environments where processing speed, deterministic control, and network connectivity are non-negotiable. Typical application scenarios include:
- Oil & Gas Processing Plants – Controls compressor sequencing, pipeline pressure regulation, and emergency shutdown (ESD) systems requiring sub-millisecond scan times.
- Automotive Assembly Lines – Manages multi-axis robotic welding cells, conveyor synchronization, and vision-system integration via high-speed Ethernet.
- Water & Wastewater Treatment – Runs SCADA-integrated pump station control, chemical dosing loops, and remote telemetry over Ethernet/IP.
- Power Generation & Utilities – Handles turbine governor control, load-shedding logic, and IEC 61850 substation automation.
- Pharmaceutical & Food Manufacturing – Executes FDA 21 CFR Part 11-compliant batch recipes, CIP/SIP sequences, and audit-trail logging.
- Mining & Minerals Processing – Controls crusher drives, conveyor load balancing, and hazardous-area remote I/O over fiber-optic backplane.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | IC695CPE330-ABAF |
| Series | PACSystems RX3i |
| Manufacturer | GE Fanuc / Emerson Automation |
| Processor Speed | 1.1 GHz Intel Celeron |
| User Memory (RAM) | 64 MB |
| Flash Storage | 256 MB internal flash |
| Ethernet Ports | 2 × 10/100 Mbps RJ-45 (embedded) |
| Serial Ports | 1 × RS-232 (programming port) |
| USB Port | 1 × USB 2.0 (program transfer) |
| Backplane Compatibility | IC695CHS007 / IC695CHS012 / IC695CHS016 |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Consumption | 13 W typical |
| Weight | 1,040 g |
| Firmware | RX3i CPU firmware (field-upgradeable) |
| Programming Software | Proficy Machine Edition (PME) 9.0+ |
| Supported Languages | Ladder Diagram, Function Block, Structured Text, Instruction List, SFC |
| Country of Origin | USA |
Why Engineers Specify This Model
- Dual Embedded Ethernet – Two independent 10/100 Mbps ports enable simultaneous SRTP, Modbus TCP, EtherNet/IP, and OPC-UA communications without an add-on module, reducing rack cost and latency.
- 1.1 GHz Processing Core – The Intel Celeron processor delivers scan times under 1 ms for typical 10K-rung programs, meeting the determinism requirements of motion-adjacent and safety-adjacent applications.
- 64 MB User RAM – Accommodates large data tables, historian buffers, and complex structured-text algorithms without memory-expansion modules.
- Hot-Standby Redundancy Ready – Pairs with IC695RMX228 redundancy module for bumpless switchover in critical process applications.
- Backward I/O Compatibility – Accepts legacy Series 90-30 I/O modules via IC695LRE001 expansion, protecting existing field-wiring investments.
- USB Program Transfer – Enables offline program loading and firmware updates without a live network connection, simplifying commissioning in remote sites.
Complete System Bill of Materials
A typical PACSystems RX3i control panel built around the IC695CPE330-ABAF includes:
- IC695CPE330-ABAF – CPU Module (this item)
- IC695PSA140 – 140W AC Power Supply
- IC695CHS012 – 12-Slot Universal Backplane
- IC695MDL664 – 16-Point 24VDC Digital Input Module
- IC695MDL754 – 16-Point 24VDC Digital Output Module
- IC695ALG626 – 8-Channel Analog Input Module (4–20 mA)
- IC695ALG728 – 8-Channel Analog Output Module
- IC695RMX228 – Redundancy Memory Xchange Module (optional)
- IC695ACC402 – Ethernet Cable Kit
Contact Konmask for bundle pricing on complete RX3i rack assemblies.
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL Listed – UL 508 (Industrial Control Equipment)
- cUL Listed – CSA C22.2 No. 142
- RoHS Compliant – Directive 2011/65/EU
- ATEX / IECEx – Suitable for Zone 2 installations with appropriate enclosure
- IEC 61131-3 – Five standard PLC programming languages supported
- IEEE 1588 PTP – Precision Time Protocol for time-synchronized control networks
Quality Assurance & Sourcing
Every IC695CPE330-ABAF unit shipped by Konmask undergoes a documented inspection process:
- Visual Inspection – Connector pins, PCB surface, and label integrity checked against OEM reference images.
- Firmware Verification – Firmware version confirmed and logged prior to shipment.
- Functional Power-On Test – Module powered and self-diagnostic OK status verified.
- Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning inside double-wall cartons.
- Traceability – Serial number and inspection record retained for 3 years.
We source from authorized distributors, OEM overstock, and verified industrial surplus channels. Counterfeit-risk screening is applied to all non-factory-sealed units.
How to Source This Part
- Add to Cart – Click “Add to Cart” above and proceed to checkout. We accept T/T wire transfer, PayPal, and major credit cards.
- Request a Quote – For orders of 2+ units or project BOM quotes, email support@konmask.com with your required quantity and delivery timeline.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock orders ship same day if placed before 14:00 CST.
- Shipping – DHL Express, FedEx International Priority, and UPS Worldwide available. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- Warranty – 12-month warranty against manufacturing defects. DOA replacement within 7 days of receipt.
Application-Specific FAQ
Q: Is the IC695CPE330-ABAF compatible with the older IC693 Series 90-30 I/O?
A: Yes, via the IC695LRE001 Local Rack Expansion module, which allows Series 90-30 I/O modules to be used in an RX3i rack. Direct slot-for-slot replacement is not supported without the expansion module.
Q: Can this CPU run redundant configurations?
A: Yes. Pair two IC695CPE330-ABAF units with IC695RMX228 Redundancy Memory Xchange modules and configure Hot-Standby CPU Redundancy in Proficy Machine Edition for bumpless failover.
Q: What is the maximum number of I/O points supported?
A: The RX3i system supports up to 32,768 discrete I/O points and 4,096 analog channels across local and remote racks using PROFINET or Ethernet I/O adapters.
Q: Does the -ABAF suffix indicate a specific hardware revision?
A: Yes. The suffix denotes the factory firmware load and hardware revision level. The -ABAF variant is the current production revision and is fully interchangeable with earlier -AB revisions for most applications. Verify with your PME project firmware requirements before substituting.
Q: Is OPC-UA supported natively?
A: OPC-UA server functionality is available via the embedded Ethernet ports using GE’s OPC-UA Server option license (IC695OPC001). No additional hardware module is required.
Q: Can I upgrade firmware in the field?
A: Yes. Firmware updates are performed via USB or Ethernet using Proficy Machine Edition’s firmware upgrade utility. Always back up the application program before upgrading.
