GE IC200MDL750E 12/24VDC Output Module | Replacement, Equivalent & Selection Guide
The GE IC200MDL750E is a 12/24VDC digital output module from GE Fanuc’s VersaMax Micro PLC series. Designed for high-reliability discrete control in industrial automation environments, this module delivers 16 points of sourcing (PNP) output at 12 or 24VDC. Whether you are sourcing an original unit, evaluating a compatible replacement, or selecting the right module for a new panel build, this guide covers everything you need.
Technical Specifications
- Part Number: IC200MDL750E
- Series: VersaMax Micro / IC200 Series
- Manufacturer: GE Fanuc Automation (now Emerson / Proficy)
- Module Type: Digital Output Module
- Output Voltage: 12/24VDC
- Output Type: Sourcing (PNP)
- Number of Output Points: 16
- Output Current per Point: 0.5A
- Total Module Current: 4A max
- Isolation: Optical isolation between field and logic side
- Backplane Current (5VDC): 80mA
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Weight: Approx. 140g
- Certifications: UL, CE, cUL
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the IC200MDL750E. Always verify electrical and mechanical compatibility before substitution:
- IC200MDL750 – Earlier revision of the same module; functionally identical in most applications
- IC200MDL750D – Revision D; same output specs, minor firmware differences
- IC200MDL740 – 12/24VDC sinking (NPN) output, 16 points; use when NPN loads are required
- IC200MDL730 – 24VDC sourcing output, 8 points; suitable for lower-density applications
- Siemens 6ES7 322-1BH01-0AA0 – Third-party equivalent for 24VDC 16-point sourcing output; requires adapter for VersaMax backplane
- Mitsubishi QY10 – Functional equivalent in output type; not pin-compatible, requires rewiring
Note: Konmask.com recommends using original GE Fanuc / Emerson parts for safety-critical applications. Contact us for cross-reference verification.
Why Choose the Original IC200MDL750E
- ✅ Guaranteed compatibility with all VersaMax Micro CPU and expansion backplanes
- ✅ Firmware-certified for use with Proficy Machine Edition and GE PAC software
- ✅ Optical isolation protects CPU from field-side voltage spikes
- ✅ Proven reliability in harsh industrial environments (automotive, food & beverage, utilities)
- ✅ Full OEM documentation and GE Fanuc technical support available
- ✅ Plug-and-play replacement — no configuration changes required when swapping same revision
Typical Applications
- Solenoid valve control in pneumatic and hydraulic systems
- Motor starter and contactor switching
- Conveyor and material handling control
- Indicator lamp and alarm output driving
- Packaging machine discrete output control
- HVAC and building automation relay driving
- Water treatment and pump station control panels
System Compatibility
- Compatible CPUs: IC200UDR002, IC200UDR005, IC200UDR020, IC200UAL006, IC200UEX011 and all VersaMax Micro expansion bases
- Programming Software: GE Proficy Machine Edition 8.x and above; legacy Logicmaster 90 (read-only)
- Communication: Operates via local backplane bus; no separate network configuration required
- Power Supply: Powered from backplane 5VDC bus; field side requires external 12/24VDC supply
- Expansion: Supports up to 7 expansion modules per VersaMax Micro base
Selection Guide
Use the table below to select the correct IC200 output module for your application:
| Model | Points | Voltage | Output Type | Max Current/Pt | Best For |
|---|---|---|---|---|---|
| IC200MDL750E | 16 | 12/24VDC | Sourcing (PNP) | 0.5A | Standard PNP loads, solenoids |
| IC200MDL740 | 16 | 12/24VDC | Sinking (NPN) | 0.5A | NPN sensor-driven loads |
| IC200MDL730 | 8 | 24VDC | Sourcing (PNP) | 0.5A | Low-density, cost-sensitive |
| IC200MDL760 | 16 | 24VDC | Sourcing (PNP) | 1.0A | High-current loads, motors |
| IC200MDL330 | 8 | 120VAC | Triac | 0.5A | AC load switching |
Key selection criteria: Match output type (PNP/NPN) to your field device wiring; verify supply voltage; confirm point count meets I/O requirements; check per-point and total current ratings against load specifications.
Quality Assurance & Sourcing
- 🔍 Authenticity: All units sourced from authorized distributors or verified surplus channels with traceability documentation
- 📦 Condition: New, refurbished, and tested-used options available — clearly labeled on each listing
- 🧪 Testing: Functional test performed on all non-new units prior to shipment
- 📄 Documentation: GE Fanuc datasheet and wiring diagram available upon request
- 🚚 Lead Time: In-stock units ship within 1–3 business days; contact us for bulk order lead times
- 🔒 Warranty: 90-day replacement warranty on all units sold by Konmask.com
How to Order
- Confirm your required quantity and condition (new / refurbished / tested-used)
- Add IC200MDL750E to cart and proceed to checkout
- For bulk orders (>5 units), contact us for volume pricing: support@konmask.com
- Provide your shipping address — we ship worldwide via DHL, FedEx, and UPS
- Payment accepted: T/T (wire transfer), PayPal, credit card via Shopify Payments
Replacement & Compatibility FAQ
Q: Can IC200MDL750D replace IC200MDL750E directly?
A: In most cases yes — the hardware is identical. Revision E includes minor firmware and EMC compliance updates. Verify with your GE Fanuc service documentation before substitution in safety-rated systems.
Q: Is IC200MDL750E compatible with VersaMax (non-Micro) systems?
A: No. The IC200 series is specific to VersaMax Micro. VersaMax standard systems use IC200 modules with different backplane connectors. Do not interchange.
Q: What is the difference between IC200MDL750E (PNP) and IC200MDL740 (NPN)?
A: PNP (sourcing) outputs supply current to the load; NPN (sinking) outputs sink current from the load. Selection depends on your field device wiring convention. Most European industrial standards use PNP; many Asian standards use NPN.
Q: Can I use a third-party module as a drop-in replacement?
A: Third-party modules are not pin-compatible with the VersaMax Micro backplane. Adapters or rewiring are required. Konmask.com recommends original GE Fanuc parts for guaranteed compatibility.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC is available upon request for new units. Contact support@konmask.com.
