GE IC697CMM711 – Communications Coprocessor Module | Series 90-70 PLC Platform
Engineering Background
The GE IC697CMM711 is a dedicated Communications Coprocessor Module engineered for the GE Series 90-70 programmable logic controller (PLC) platform — one of the most widely deployed rack-based control architectures in heavy industrial environments. Designed to offload serial communication tasks from the CPU, this module enables deterministic, high-throughput data exchange across multi-drop networks without impacting scan cycle performance.
Product Positioning
Targeted at procurement engineers and system integrators managing legacy Series 90-70 installations, the IC697CMM711 is the authoritative solution for extending or maintaining serial communication capability in existing control panels. Konmask.com supplies this module as a verified OEM or factory-refurbished unit, fully tested and ready for immediate deployment.
Complete Technical Specifications
- Part Number: IC697CMM711
- Manufacturer: GE Automation & Controls (now part of Emerson / GE Vernova ecosystem)
- Platform: GE Series 90-70 PLC
- Module Type: Communications Coprocessor
- Form Factor: Single-slot VME-based rack module
- Communication Ports: Dual serial ports (RS-232 / RS-485 configurable)
- Supported Protocols: SNP, SNP-X, RTU, ASCII, Modbus RTU (via configuration)
- Processor: Onboard coprocessor (independent of main CPU)
- Backplane Interface: Series 90-70 VME backplane
- Power Consumption: Supplied via rack backplane
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Weight: Approx. 1,380 g
- Certifications: UL, CE (original OEM certifications)
- Firmware: Field-upgradeable via serial port
Proven Application Environments
- Power generation and utility SCADA systems requiring serial polling of RTUs
- Oil & gas pipeline monitoring with Modbus RTU field devices
- Automotive and heavy manufacturing lines with legacy HMI serial links
- Water/wastewater treatment plants using SNP protocol for remote I/O
- Chemical processing facilities with multi-drop RS-485 instrument networks
- Mining and minerals processing with distributed control architectures
Engineering Advantages
- CPU Offload: Dedicated coprocessor handles all serial communication tasks independently, preserving CPU scan time for control logic.
- Dual-Port Flexibility: Two independently configurable serial ports allow simultaneous connection to different networks or protocols.
- Protocol Versatility: Native support for SNP/SNP-X enables seamless integration with GE HMIs (CIMPLICITY, iFIX) and third-party SCADA systems.
- Backward Compatibility: Drop-in replacement for existing Series 90-70 racks — no hardware modification required.
- Deterministic Performance: Guaranteed message response times critical for real-time process control loops.
System Architecture & Signal Flow
The IC697CMM711 occupies a single slot in the Series 90-70 rack and communicates with the CPU module via the VME backplane. Serial data from field devices enters through Port 1 or Port 2 (DB-9 connectors), is processed by the onboard coprocessor, and is transferred to the CPU’s data table via shared memory on the backplane. Configuration is performed through the GE Proficy Machine Edition (PME) or Logicmaster 90-70 programming software. The module supports both point-to-point and multi-drop topologies, with baud rates configurable from 300 bps to 19,200 bps.
Sourcing & Quality Verification
- Source: OEM surplus, factory-refurbished, or pull-tested units — clearly stated per order
- Testing: Each unit undergoes functional power-on verification and port continuity testing prior to shipment
- Packaging: Anti-static ESD bag + foam-lined carton with desiccant
- Documentation: Original GE datasheet and installation guide available upon request
- Warranty: 12-month replacement warranty against manufacturing defects
- Traceability: Serial number and firmware version recorded for each shipped unit
Procurement Process
- Submit RFQ via Konmask.com product page or email support@konmask.com
- Receive stock confirmation and lead time within 24 business hours
- Review proforma invoice — payment via T/T, PayPal, or trade credit
- Unit ships within 1–3 business days via DHL / FedEx with tracking
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is the IC697CMM711 compatible with all Series 90-70 rack sizes?
A: Yes. It is compatible with all standard Series 90-70 racks (5-slot, 9-slot, 12-slot) and requires no special slot position.
Q: Can this module communicate using Modbus TCP?
A: No. The IC697CMM711 supports serial Modbus RTU only. For Modbus TCP, consider the GE IC697CMM742 Ethernet module.
Q: What programming software is required for configuration?
A: GE Proficy Machine Edition (PME) v8.0+ or Logicmaster 90-70 v9.05+. Configuration is stored in the CPU program and downloaded to the module at runtime.
Q: Is firmware upgrade supported in the field?
A: Yes. Firmware can be updated via the serial port using GE’s firmware upgrade utility. Contact Konmask for the latest firmware file.
Q: What is the lead time for bulk orders (>5 units)?
A: Typically 5–10 business days depending on stock. Contact us for volume pricing and consolidated shipping options.
