Industrial Automation Solution – GE IC697CPX782 | Series 90-70 PLC CPU Module
Where This Product Is Used
The GE IC697CPX782 is a high-performance Central Processor Unit (CPU) designed for the GE Series 90-70 Programmable Logic Controller platform. It is widely deployed across demanding industrial environments where deterministic control, high-speed scan cycles, and large I/O capacity are mission-critical requirements.
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and powertrain assembly cells requiring synchronized multi-axis coordination.
- Oil & Gas Processing: Wellhead control panels, compressor station automation, and pipeline SCADA integration where continuous uptime is non-negotiable.
- Power Generation & Utilities: Turbine governor control, substation automation, and load-shedding logic in coal, gas, and hydroelectric plants.
- Chemical & Petrochemical Plants: Batch reactor sequencing, distillation column control, and safety interlock systems (SIS) requiring IEC 61511 alignment.
- Pulp & Paper Mills: Digester control, stock preparation, and winder/rewinder automation with high-speed analog loop management.
- Water & Wastewater Treatment: Pump station control, SCADA-linked remote I/O, and chemical dosing automation.
- Food & Beverage Processing: CIP (Clean-In-Place) sequencing, filling line control, and cold-chain conveyor management.
- Discrete Manufacturing: Machine tool control, press automation, and robotic cell integration via Genius Bus or Ethernet.
Technical Specifications
- Part Number: IC697CPX782
- Series: GE Series 90-70 (90-70)
- Manufacturer: GE Automation & Controls (formerly GE Fanuc)
- Processor Type: Central Processing Unit (CPU)
- Memory: 512 KB user program memory (expandable)
- I/O Capacity: Up to 12,000 discrete I/O points; up to 4,000 analog channels
- Communication Ports: Serial (RS-232/RS-485), Ethernet TCP/IP (via co-processor), Genius Bus
- Scan Time: <1 ms/K of Boolean logic
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Power Consumption: 5 VDC bus (supplied by rack power supply)
- Backplane Compatibility: IC697CHS750, IC697CHS782, IC697CHS790 (Series 90-70 racks)
- Programming Software: Proficy Machine Edition (ME) / Logicmaster 90-70
- Weight: 840 g
- Form Factor: Single-slot VME-based module
Why Engineers Specify This Model
- Proven Platform Longevity: The Series 90-70 architecture has been deployed in critical infrastructure since the 1990s. The IC697CPX782 represents a mature, field-validated CPU with an extensive installed base — minimizing integration risk on brownfield projects.
- High-Density I/O Scalability: Supports up to 12,000 discrete I/O points across multiple racks, making it the preferred choice for large-scale process plants and complex machine lines.
- Deterministic Scan Performance: Sub-millisecond Boolean scan times ensure tight loop control and reliable safety interlock response — critical in chemical and power generation applications.
- Multi-Protocol Communication: Native Genius Bus support combined with optional Ethernet co-processors enables seamless integration into both legacy and modern SCADA/DCS architectures.
- Backward Compatibility: Drop-in replacement for earlier IC697CPU7xx series CPUs, protecting existing rack, wiring, and program investments during system upgrades.
- Robust Environmental Rating: Rated for 0–60°C operation and wide humidity tolerance, suitable for harsh plant-floor environments without additional enclosure conditioning.
Complete System Bill of Materials
A fully operational GE Series 90-70 control system built around the IC697CPX782 typically includes:
- CPU: IC697CPX782 (this module)
- Rack: IC697CHS750 (5-slot) / IC697CHS782 (9-slot) / IC697CHS790 (9-slot, enhanced)
- Power Supply: IC697PWR711 / IC697PWR724 (120/240 VAC or 24 VDC input)
- Discrete Input Modules: IC697MDL340 (24 VDC, 32-pt) / IC697MDL341
- Discrete Output Modules: IC697MDL940 (Relay, 16-pt) / IC697MDL753
- Analog Input Modules: IC697ALG320 (16-ch, ±10 V / 4–20 mA)
- Analog Output Modules: IC697ALG390 (8-ch)
- Ethernet Interface: IC697CMM742 / IC697CMM741
- Genius Bus Controller: IC697BEM731
- Memory Expansion: IC697MEM715 / IC697MEM719
- Programming Cable: IC690ACC901 (Serial SNP)
Compliance & Industry Standards
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed: UL 508 (Industrial Control Equipment)
- IEC 61131-2: Programmable Controllers — Hardware Requirements
- IEC 61131-3: Supports Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), and Instruction List (IL)
- RoHS: Compliant (verify batch documentation upon request)
- ATEX / Class I Div 2: Suitable for use in associated safe-area control panels for hazardous location applications (consult project engineer)
Quality Assurance & Sourcing
At Konmask.com, every GE IC697CPX782 unit undergoes a rigorous multi-stage inspection process before shipment:
- ✅ Visual Inspection: PCB, connector pins, and faceplate examined for physical damage, corrosion, or counterfeit indicators.
- ✅ Functional Power-On Test: Module powered and self-diagnostics verified (OK LED status confirmed).
- ✅ Firmware Version Check: Firmware revision documented and disclosed prior to shipment.
- ✅ ESD-Safe Packaging: Shipped in anti-static bags with foam cushioning and double-wall carton.
- ✅ Traceability Documentation: Serial number, test date, and inspector ID recorded for each unit.
- ✅ Sourcing Transparency: Units sourced from decommissioned OEM systems, authorized distributors, or certified refurbishers — never grey-market or unverified channels.
How to Source This Part
- Confirm Compatibility: Verify your existing rack model (IC697CHS7xx series) and power supply capacity before ordering. Contact our engineering team if unsure.
- Request a Quote: Email support@konmask.com with your required quantity, delivery timeline, and any firmware version requirements.
- Review Documentation: We provide datasheet, test report, and firmware revision upon request before purchase commitment.
- Place Order: Secure checkout via this product page. We accept T/T bank transfer, PayPal, and major credit cards.
- Fast Dispatch: In-stock units ship within 1–3 business days. Express DHL/FedEx worldwide shipping available.
- After-Sales Support: 90-day warranty on all tested units. Technical support available via email and WhatsApp.
Application-Specific FAQ
Q: Can the IC697CPX782 replace an IC697CPU772 or IC697CPU781 in my existing rack?
A: Yes. The IC697CPX782 is backward-compatible with earlier Series 90-70 CPU modules and will fit the same rack slot. Program re-download via Proficy ME or Logicmaster 90-70 is required after swap.
Q: Does this CPU support Ethernet communications natively?
A: The IC697CPX782 does not have a built-in Ethernet port. Ethernet connectivity is achieved by adding an IC697CMM742 or IC697CMM741 Ethernet Interface Module to the same rack.
Q: What programming software is required?
A: GE Proficy Machine Edition (Logic Developer – PLC) is the current supported programming environment. Legacy Logicmaster 90-70 software is also compatible for existing program maintenance.
Q: Is this module suitable for safety-critical SIS applications?
A: The standard IC697CPX782 is not SIL-rated. For Safety Instrumented Systems requiring IEC 61511 / SIL 2–3 compliance, a dedicated GE RX3i Safety CPU or third-party SIS platform should be specified.
Q: What is the typical lead time for out-of-stock units?
A: For units not currently in stock, typical sourcing lead time is 5–15 business days. Contact us to join the waitlist or discuss alternative compatible CPU options.
Q: Do you provide a warranty?
A: All tested units carry a 90-day functional warranty. Extended warranty options are available — contact our sales team for details.
