GE IC697VAL314 Analog Output Module – Series 90-70 PLC
Imagine a continuous process line — a chemical reactor, a paper mill, or a water treatment plant — where the analog control signals suddenly drop out. Valves freeze in position, variable-speed drives lose their setpoints, and the entire process drifts out of specification within minutes. Without a reliable analog output module at the heart of the control rack, there is no bridge between the digital intelligence of the PLC and the physical world of actuators, drives, and control valves. The GE IC697VAL314 is that bridge — a precision instrument that converts digital commands into real-world analog signals with the accuracy and stability that mission-critical industrial processes demand.
The IC697VAL314 occupies a well-defined technical position within GE’s Series 90-70 PLC ecosystem — one of the most widely deployed large-frame PLC platforms in North American and global heavy industry. As an 8-channel analog output module with 12-bit resolution, it delivers the channel density and signal fidelity required for complex multi-loop control architectures. Decades after its introduction, the IC697VAL314 remains an active part of thousands of installed base systems across oil & gas, power generation, automotive manufacturing, and municipal infrastructure — a testament to the enduring engineering quality of the Series 90-70 platform.
Technical Specifications
- Part Number: IC697VAL314
- Series: GE Series 90-70 PLC
- Module Type: Analog Output Module
- Number of Output Channels: 8
- Output Signal Range: ±10V DC (voltage) / 4–20 mA (current)
- Resolution: 12-bit (1 in 4096)
- Output Type: Voltage or Current (selectable per channel)
- Backplane Interface: Series 90-70 VME-based backplane
- Power Consumption: Supplied via Series 90-70 rack backplane
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Dimensions: Standard Series 90-70 single-slot module form factor
- Weight: Approx. 420 g
- Certifications: UL Listed, CE Marked
Key Features & Benefits
- 8 Independent Analog Output Channels — High channel density reduces rack space requirements and simplifies wiring in multi-loop control systems.
- 12-Bit Resolution — Provides 4096 discrete output levels for smooth, precise control of proportional actuators, control valves, and variable-frequency drives.
- Dual Output Mode (Voltage & Current) — Supports both ±10V voltage outputs and 4–20 mA current loop outputs, accommodating a wide range of field devices without additional signal converters.
- Native Series 90-70 Backplane Integration — Plug-and-play compatibility with all Series 90-70 racks and CPUs eliminates integration complexity and reduces commissioning time.
- Proven Long-Term Reliability — Designed for continuous 24/7 industrial operation in harsh environments, with robust EMI shielding and industrial-grade components.
- Hot-Standby Redundancy Support — Compatible with Series 90-70 redundancy architectures for high-availability process control applications.
- Extensive Installed Base — Widely supported by GE Proficy Machine Edition and third-party SCADA/DCS integration tools.
Industry & Equipment Applications
- Oil & Gas: Pipeline pressure regulation, compressor speed control, separator level control
- Power Generation: Turbine governor control, boiler feedwater regulation, generator excitation systems
- Chemical & Petrochemical: Reactor temperature control, flow ratio control, distillation column management
- Water & Wastewater Treatment: Pump speed control, chemical dosing systems, aeration blower control
- Automotive Manufacturing: Paint line conveyor speed, robotic welding current control, press tonnage regulation
- Pulp & Paper: Stock flow control, dryer section temperature, winder tension control
- Food & Beverage: Filling machine flow control, pasteurizer temperature regulation, CIP system management
System Integration & Compatible Parts
The IC697VAL314 is designed for seamless integration within the GE Series 90-70 PLC platform. Compatible and commonly paired components include:
- CPUs: IC697CPU731, IC697CPU771, IC697CPU781, IC697CPU782, IC697CPM915
- Power Supplies: IC697PWR711, IC697PWR724, IC697PWR748
- Racks: IC697CHS750, IC697CHS782, IC697CHS790
- Analog Input Modules: IC697ALG230, IC697ALG320, IC697ALG440
- Communications Modules: IC697CMM711, IC697CMM742 (Ethernet, Genius Bus)
- Programming Software: GE Proficy Machine Edition (Logic Developer – PLC)
Our Quality Assurance Process
Every GE IC697VAL314 unit sourced and shipped by Konmask.com undergoes a rigorous multi-stage quality verification process:
- Visual Inspection: Board-level examination for physical damage, corrosion, component integrity, and label authenticity
- Functional Verification: Where applicable, modules are bench-tested against known-good Series 90-70 rack configurations
- Authenticity Screening: Cross-referenced against manufacturer date codes, lot traceability, and known counterfeit indicators
- ESD-Safe Packaging: All modules are packed in anti-static bags with foam cushioning and clearly labeled for safe transit
- Documentation: Shipments include packing lists, test records (where available), and certificate of conformance upon request
How to Order
- Submit an Inquiry: Use the contact form or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, availability, and lead time.
- Confirm & Pay: We accept T/T (bank transfer), PayPal, and other agreed payment terms for B2B orders.
- Shipping: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation (commercial invoice, packing list, COO) provided for international shipments.
- After-Sales Support: Our technical team is available post-delivery to assist with installation questions and compatibility verification.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, HMI, and automation components — not a generalist distributor.
- ✅ Global Sourcing Network: Access to new, surplus, and refurbished inventory from verified suppliers worldwide.
- ✅ Fast Response: Dedicated B2B inquiry team with <24-hour quote turnaround.
- ✅ Export Expertise: Experienced in international trade compliance, customs documentation, and cross-border logistics.
- ✅ Technical Competence: Our team includes engineers with hands-on experience in GE Series 90-70 systems.
- ✅ Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing on hard-to-find parts.
Frequently Asked Questions
Q: Is the IC697VAL314 still in production by GE?
A: The GE Series 90-70 platform has been discontinued by GE (now part of Emerson’s portfolio). However, the IC697VAL314 remains widely available as new-surplus and refurbished stock. Konmask.com maintains sourcing channels for this module to support ongoing installed base maintenance.
Q: Can the IC697VAL314 output both voltage and current signals simultaneously?
A: The module supports both ±10V voltage and 4–20 mA current output modes. Output type is configured per channel via software (GE Proficy Machine Edition), but each channel operates in one mode at a time.
Q: What is the difference between IC697VAL314 and IC697ALG320?
A: The IC697VAL314 is an analog output module (DAC — digital to analog), while the IC697ALG320 is an analog input module (ADC — analog to digital). They serve complementary roles in a closed-loop control system.
Q: Do you provide a warranty on this module?
A: Yes. Konmask.com provides a standard 90-day warranty on all modules covering defects in materials and workmanship under normal operating conditions. Extended warranty options are available — please inquire.
Q: Can you provide an export certificate of origin for customs clearance?
A: Yes. We provide full export documentation including commercial invoice, packing list, and certificate of origin for all international shipments.
Q: What is the minimum order quantity (MOQ)?
A: There is no minimum order quantity. We supply single units as well as bulk orders for MRO and project requirements.
