GE IC697VRD008 Strain Bridge Module | Replacement, Equivalent & Selection Guide
The GE IC697VRD008 is a Strain Bridge Input Module designed for the GE Series 90-70 PLC platform. It provides 8 channels of high-accuracy strain gauge / bridge signal conditioning, making it ideal for force, torque, pressure, and weight measurement in demanding industrial environments. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing the IC697VRD008 or its equivalents.
Technical Specifications
- Part Number: IC697VRD008
- Manufacturer: GE Fanuc Automation (now Emerson / GE Vernova)
- Series: Series 90-70
- Module Type: Strain Bridge / Analog Input
- Input Channels: 8 differential strain bridge channels
- Bridge Excitation: 5 VDC (ratiometric)
- Input Range: ±15 mV to ±120 mV (software selectable per channel)
- Resolution: 16-bit
- Accuracy: ±0.05% of full scale
- Isolation: Channel-to-backplane isolated
- Backplane Interface: Series 90-70 VME-based backplane
- Power Consumption: 5 VDC @ 1.5 A (typical)
- Operating Temperature: 0 °C to 60 °C
- Weight: 680 g
- Form Factor: Single-slot VME module
- Certifications: CE, UL listed
Compatible Replacement & Equivalent Models
When the IC697VRD008 is discontinued, obsolete, or unavailable, the following alternatives may be considered. Always verify firmware, backplane, and software compatibility before substitution.
- IC697VRD008A – Revised hardware revision; functionally equivalent, direct drop-in replacement
- IC697ALG440 – GE Series 90-70 Analog Input module; suitable for general analog signals but lacks dedicated bridge excitation
- IC697ALG230 – 16-channel analog input; requires signal conditioning adapter for strain bridge use
- Emerson PACSystems RX7i Analog I/O – Next-generation platform; requires migration project and new rack
- Third-party VME strain bridge modules – Must confirm VME bus protocol and GE Logicmaster / Proficy ME driver support
Note: Konmask.com recommends using original GE parts wherever possible to ensure full system warranty and support.
Why Choose the Original IC697VRD008
- ✅ Factory-calibrated 16-bit resolution for precision measurement
- ✅ Native integration with GE Series 90-70 backplane — no adapter required
- ✅ Ratiometric excitation eliminates reference voltage errors
- ✅ Per-channel software-configurable input range via Logicmaster 90 / Proficy ME
- ✅ Proven reliability in heavy industry: steel mills, automotive, aerospace
- ✅ Full GE Fanuc technical documentation and firmware support
Typical Applications
- Industrial weighing and batching systems
- Force and torque measurement on production lines
- Structural load monitoring in civil and aerospace engineering
- Pressure transducer signal acquisition
- Material testing machines (tensile, compression)
- Crane and hoist load cells
System Compatibility
- PLC Platform: GE Series 90-70 (IC697 family)
- Rack Compatibility: IC697CHS750, IC697CHS782, IC697CHS790 and all standard Series 90-70 racks
- CPU Compatibility: IC697CPU731, IC697CPU771, IC697CPU781, IC697CPU782, IC697CPU788, IC697CPU789
- Programming Software: Logicmaster 90-70, Proficy Machine Edition (ME) v5.0+
- Communication: Via Series 90-70 backplane; supports Genius Bus, Ethernet (with CMM module)
Selection Guide
Use the following criteria to confirm the IC697VRD008 is the right module for your application:
- Signal type: Full-bridge, half-bridge, or quarter-bridge strain gauges (350 Ω or 120 Ω)
- Channel count: Up to 8 independent channels per module; add modules for more channels
- Excitation requirement: 5 VDC ratiometric — confirm sensor compatibility
- Resolution need: 16-bit is sufficient for most industrial weighing; upgrade to higher-resolution external conditioners for laboratory-grade accuracy
- Environment: Rated for 0–60 °C; use conformal-coated variants or enclosures for harsh environments
- Existing platform: Only compatible with Series 90-70 racks — not interchangeable with Series 90-30 or PACSystems RX3i/RX7i without migration
Quality Assurance & Sourcing
- All IC697VRD008 units sourced by Konmask.com are tested for functionality prior to shipment
- Units are supplied as new surplus, refurbished, or used tested — condition clearly stated on each listing
- Traceability documentation available upon request
- 30-day return policy on all stocked items
- Worldwide shipping with DHL, FedEx, and UPS express options
How to Order
- Confirm part number: IC697VRD008 (check label on existing module for hardware revision suffix)
- Specify required condition: New Surplus / Refurbished / Used Tested
- Add to cart or contact us for bulk pricing and lead time
- Provide shipping address — we ship globally from our warehouse
- Receive tracking number within 1 business day of payment confirmation
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Is IC697VRD008 still in production?
A: GE Fanuc has discontinued many Series 90-70 modules. The IC697VRD008 is available as new surplus and refurbished stock through authorized distributors like Konmask.com.
Q: Can I use IC697VRD008 in a Series 90-30 rack?
A: No. The IC697 series is exclusively for Series 90-70 VME racks. Series 90-30 uses the IC693 family.
Q: What is the difference between IC697VRD008 and IC697VRD008A?
A: The “A” suffix denotes a hardware revision with minor component updates. Both are functionally identical and software-compatible.
Q: Do you provide a warranty?
A: Yes — all units carry a 30-day tested warranty. Extended warranty options are available; contact us for details.
Q: Can Konmask.com help with system migration from Series 90-70 to PACSystems?
A: We can recommend compatible PACSystems equivalents and provide technical documentation. Full migration engineering services are available through our partner network.
