GE IS200DSPXH1CAA DSP Extension Board | Replacement, Equivalent & Selection Guide
The GE IS200DSPXH1CAA is a Digital Signal Processor (DSP) Extension Board designed for use in GE’s Mark VI Turbine Control System. It serves as a critical processing component within the DSPX module assembly, handling real-time signal processing tasks for gas and steam turbine control applications. Konmask.com supplies genuine, tested, and compatible units with full traceability.
Technical Specifications
- Part Number: IS200DSPXH1CAA
- Manufacturer: GE (General Electric)
- Series: Mark VI Turbine Control
- Module Type: DSP Extension Printed Circuit Board
- Form Factor: PCB Card
- Weight: 470 g (approx.)
- Application: Gas turbine / Steam turbine control systems
- Communication: Compatible with Mark VI I/O and controller backplane
- Operating Environment: Industrial control panel / DCS cabinet
- Condition Available: New, Refurbished, Tested
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional equivalents or drop-in replacements for the IS200DSPXH1CAA. Always verify firmware revision and hardware revision compatibility before substitution:
- IS200DSPXH1BAA — Earlier hardware revision; functionally similar, verify Rev compatibility
- IS200DSPXH1AAA — Base revision; may require firmware update
- IS200DSPXH2CAA — Upgraded variant with enhanced DSP capacity
- IS215DSPXH1A — Mark VIe platform equivalent (confirm system compatibility)
- Contact Konmask for cross-reference assistance if your exact revision is not listed
Why Choose the Original IS200DSPXH1CAA
- Exact hardware and firmware revision match — eliminates integration risk
- Validated for GE Mark VI DSPX module assembly without reconfiguration
- Maintains OEM diagnostic and fault-reporting integrity
- Preferred for safety-critical turbine control environments
- Reduces commissioning time versus cross-revision substitution
Typical Applications
- Gas turbine control panels (GE Frame 6, Frame 7, Frame 9 series)
- Steam turbine governor and protection systems
- Combined-cycle power plant DCS integration
- Compressor control and surge protection systems
- Retrofit and upgrade projects for aging Mark V → Mark VI migrations
System Compatibility
- Primary System: GE Mark VI Turbine Control System
- Module Assembly: DSPX (Digital Signal Processor Extension)
- Backplane: Mark VI VME-based I/O backplane
- Software: Toolbox ST (GE Mark VI configuration tool)
- Not compatible with: Mark IV, Mark V (without adapter), or non-GE DCS platforms without engineering review
Selection Guide
Use the following criteria to confirm the correct part for your application:
- Step 1 — Identify your Mark VI revision: Check the system nameplate or Toolbox ST project file for the hardware BOM revision.
- Step 2 — Match the hardware suffix: H1CAA indicates hardware rev H1, configuration C, assembly A. Mismatched suffixes may cause boot failures.
- Step 3 — Confirm firmware version: IS200DSPXH1CAA requires a specific firmware load; verify with your GE service documentation or contact Konmask.
- Step 4 — Check slot assignment: The DSPX board occupies a defined slot in the Mark VI controller chassis — confirm physical slot availability.
- Step 5 — Evaluate refurbished vs. new: For critical turbine applications, new or fully tested refurbished units with burn-in certification are recommended.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or decommissioned OEM systems
- Functional testing performed prior to shipment
- Anti-static packaging with humidity indicator cards
- Certificate of conformance available upon request
- Traceability documentation provided for regulated industries
- 12-month warranty on tested refurbished units; 24-month on new stock
How to Order
- Part Number: IS200DSPXH1CAA
- Minimum Order: 1 unit
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Payment: T/T, PayPal, credit card accepted
- Shipping: DHL / FedEx / UPS worldwide express available
- Submit your RFQ via support@konmask.com or use the cart above
Replacement & Compatibility FAQ
Q: Can IS200DSPXH1BAA replace IS200DSPXH1CAA?
A: Possibly, but hardware revision differences may affect firmware compatibility. Always verify with GE documentation or contact our technical team before substitution.
Q: Is this board compatible with Mark VIe?
A: No. Mark VIe uses a different architecture (IS215 series). The IS200 series is specific to Mark VI. Cross-platform use requires engineering review.
Q: Do you provide a test report?
A: Yes. Functional test reports and certificates of conformance are available upon request for all refurbished units.
Q: What is the lead time for a new unit?
A: New units typically ship within 5–15 business days depending on stock. Contact us for real-time availability.
Q: Can Konmask assist with Mark VI system troubleshooting?
A: We provide part identification and cross-reference support. For system-level diagnostics, we recommend engaging a GE-certified service engineer.
