GE IC752QPT012-24 QuickPanel HMI Touch Panel | GE QuickPanel Series
The GE IC752QPT012-24 is a high-performance Human-Machine Interface (HMI) touch panel from GE’s industry-proven QuickPanel Series, engineered for demanding industrial automation environments. Designed for procurement engineers and system integrators who require a reliable, spec-verified operator interface, this unit delivers robust touchscreen control with seamless integration into GE Fanuc and third-party automation architectures.
At Konmask.com, every IC752QPT012-24 unit is sourced through verified supply channels, inspected for authenticity, and backed by our technical support team — ensuring your project timeline and quality standards are met without compromise.
Complete Technical Specifications
- Part Number / SKU: IC752QPT012-24
- Manufacturer: GE (General Electric) / GE Fanuc
- Series: QuickPanel
- Display Type: Color TFT LCD Touchscreen
- Display Size: 12-inch (nominal)
- Touch Technology: Resistive touch panel
- Operating Voltage: 24 VDC
- Communication Ports: RS-232, RS-485, Ethernet (model-dependent)
- Operating Temperature: 0°C to 50°C (32°F to 122°F)
- Storage Temperature: -20°C to 60°C
- Protection Rating: IP65 front panel (NEMA 4/4X)
- Weight: Approx. 270 g (unit only)
- Mounting: Panel mount, cutout installation
- Certifications: CE, UL (verify with datasheet for specific listing)
- Compatible Software: GE Proficy Machine Edition / QuickPanel WorkShop
Proven Application Environments
- Discrete manufacturing lines requiring operator touchscreen control
- Process automation panels in chemical, oil & gas, and water treatment facilities
- Machine tool HMI replacement and retrofit projects
- SCADA front-end operator stations in distributed control architectures
- Food & beverage processing with washdown-rated enclosure requirements
- Building automation and HVAC control systems
Engineering Advantages
- IP65 Front Panel Seal: Protects against dust ingress and water jets — suitable for harsh plant environments
- 24 VDC Operation: Directly compatible with standard industrial control panel power supplies
- GE Ecosystem Integration: Native compatibility with GE Series 90, VersaMax, and PACSystems PLCs
- Resistive Touch: Operable with gloves — critical for industrial floor personnel
- Compact Panel-Mount Form Factor: Minimizes enclosure footprint while maximizing display real estate
- Long-Term Parts Availability: Konmask maintains stock of legacy GE QuickPanel units to support MRO and retrofit programs
System Architecture & Signal Flow
The IC752QPT012-24 operates as an operator interface terminal (OIT) within a layered automation architecture:
- Field Level: Sensors, actuators, and I/O modules feed data to the PLC/PAC controller
- Control Level: GE PACSystems or Series 90 PLC processes logic and communicates via Ethernet/IP or serial to the QuickPanel
- HMI Level: IC752QPT012-24 renders real-time process data, alarms, and operator controls on the 12″ touchscreen
- Supervisory Level: Optional Ethernet uplink to SCADA/MES systems for data logging and remote monitoring
Signal flow is bidirectional — the QuickPanel both reads process variables and writes setpoints/commands back to the controller, enabling closed-loop operator interaction.
Sourcing & Quality Verification
- Source: Authorized distributor channels and verified surplus inventory
- Inspection: Each unit undergoes visual inspection and functional verification prior to shipment
- Authenticity: Genuine GE-branded hardware — no counterfeit or refurbished-as-new misrepresentation
- Documentation: Datasheet, wiring diagrams, and software download links available upon request
- Warranty: Contact Konmask for current warranty and return policy terms
Procurement Process
- Confirm Part Number: Verify IC752QPT012-24 against your BOM or existing panel documentation
- Request Quote: Contact support@konmask.com with quantity and required delivery date
- Order Confirmation: Receive proforma invoice with lead time and shipping options
- Payment & Dispatch: Secure payment processed; unit ships with tracking and commercial invoice
- Incoming Inspection: Use provided datasheet to verify unit against your acceptance criteria
Technical FAQ
Q: Is the IC752QPT012-24 compatible with GE PACSystems RX3i?
A: Yes. The QuickPanel communicates with PACSystems controllers via Ethernet or serial protocols supported by Proficy Machine Edition.
Q: What programming software is required?
A: GE QuickPanel WorkShop or Proficy Machine Edition HMI/SCADA is used to develop and download screen applications to this unit.
Q: Can this unit replace an older IC752QPT010 or IC752QPT011?
A: Physical and electrical compatibility should be verified against your existing panel cutout dimensions and wiring. Contact our technical team for a compatibility assessment.
Q: Do you provide expedited shipping for urgent MRO requirements?
A: Yes. Express air freight options are available globally. Contact us with your required delivery date.
Q: Is a Certificate of Conformance (CoC) available?
A: Yes, upon request for qualifying orders.
