HMI Touchscreen Solution – GE IC754VSI06MTD | View Intermediate Series
Where This Product Is Used
The GE IC754VSI06MTD is a 6-inch monochrome touchscreen Human-Machine Interface (HMI) panel from GE’s View Intermediate series. It is deployed across a wide range of industrial environments where compact, reliable operator interfaces are required:
- Manufacturing & Assembly Lines — Machine status monitoring, alarm acknowledgment, and parameter entry on production floors.
- Water & Wastewater Treatment — Pump control panels, flow monitoring stations, and SCADA front-end terminals.
- Oil & Gas Facilities — Wellhead control panels and compressor station HMI terminals.
- Building Automation & HVAC — Chiller plant control, AHU monitoring, and BMS operator stations.
- Food & Beverage Processing — Batch control interfaces and conveyor line operator panels.
- Power Distribution & Utilities — Substation control rooms and switchgear monitoring panels.
Its DC power input and compact 6-inch form factor make it ideal for panel-mount installations in space-constrained enclosures.
Technical Specifications
- Part Number: IC754VSI06MTD
- Manufacturer: General Electric (GE)
- Series: View Intermediate
- Display Size: 6 inches (diagonal)
- Display Type: Monochrome (Mono) Touchscreen
- Power Supply: DC (Direct Current)
- Interface Type: Touch (resistive touchscreen)
- Weight: 980 g
- Mounting: Panel mount
- Communication Ports: Serial (RS-232/RS-485) and Ethernet (refer to GE datasheet for full port configuration)
- Operating Temperature: 0°C to 50°C (refer to GE datasheet for full environmental ratings)
- Protection Rating: NEMA 4 / IP65 front panel (refer to GE datasheet for confirmation)
Note: Always verify specifications against the official GE IC754VSI06MTD datasheet before final design-in.
Why Engineers Specify This Model
- Proven GE View Intermediate Platform — A well-established HMI family with broad PLC compatibility and a large installed base, reducing integration risk.
- Compact 6-Inch Form Factor — Fits standard panel cutouts where larger displays are impractical, without sacrificing operator usability.
- DC Power Input — Simplifies integration into DC-powered control panels and eliminates the need for an AC/DC converter at the panel level.
- Monochrome Display — High contrast in bright industrial environments; lower power consumption versus color TFT alternatives.
- Resistive Touchscreen — Operable with gloved hands, a critical requirement in manufacturing and process environments.
- GE Proficy Machine Edition Compatible — Programmed using GE’s standard HMI development environment, enabling reuse of existing screen libraries and logic.
- Long Service Life — Designed for continuous 24/7 industrial operation with robust EMI/RFI immunity.
Complete System Bill of Materials
For a complete operator station or control panel using the IC754VSI06MTD, engineers typically specify the following complementary components:
- PLC / Controller: GE PACSystems RX3i (IC695 series) or VersaMax Micro (IC200 series)
- Communication Cable: RS-232 or RS-485 serial cable (shielded, per GE wiring guide)
- Ethernet Switch: Industrial managed switch (e.g., GE EPSMGMT series) for networked installations
- DC Power Supply: 24 VDC DIN-rail power supply (e.g., 60W–120W depending on panel load)
- Panel Enclosure: NEMA 4/12 steel or stainless enclosure with appropriate cutout for 6-inch panel mount
- Programming Software: GE Proficy Machine Edition (HMI/SCADA development)
- Backup Battery (if applicable): Refer to GE IC754VSI06MTD datasheet for internal battery specifications
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive and EMC Directive (verify with GE certificate of conformity)
- UL Listed — UL 508 (Industrial Control Equipment) — verify current listing status with GE
- RoHS Compliant — Restriction of Hazardous Substances Directive
- NEMA 4 / IP65 — Front panel ingress protection against dust and water jets (verify with GE datasheet)
- FCC Part 15 — Electromagnetic emissions compliance for North American markets
Konmask supplies genuine OEM units. Compliance documentation available upon request for project submittals.
Quality Assurance & Sourcing
At Konmask.com, every IC754VSI06MTD unit is subject to the following quality controls before shipment:
- Authenticity Verification — Units are sourced from authorized distributors and verified OEM supply chains. Counterfeit screening is performed on all incoming stock.
- Visual & Functional Inspection — Each unit undergoes physical inspection for cosmetic integrity and connector condition.
- Traceability — Lot codes and date codes are recorded for full supply chain traceability.
- Secure Packaging — Anti-static packaging with shock-absorbing foam inserts for safe international transit.
- Documentation — Original GE documentation, datasheet, and certificate of conformity available upon request.
How to Source This Part
- Add to Cart — Click “Add to Cart” above and proceed to checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Request a Quote — For bulk orders (5+ units), OEM projects, or urgent delivery requirements, contact us directly at support@konmask.com for a formal quotation.
- Lead Time — In-stock units ship within 1–3 business days. Out-of-stock units: contact us for current lead time from GE authorized supply.
- Export & Customs — We handle export documentation (commercial invoice, packing list, COO) for international shipments. HS Code available upon request.
- Technical Pre-Sales Support — Our engineering team can assist with compatibility verification, wiring diagrams, and system integration questions before purchase.
Application-Specific FAQ
Q: Is the IC754VSI06MTD compatible with GE PACSystems RX3i controllers?
A: Yes. The View Intermediate series supports native communication with GE PACSystems RX3i via Ethernet and serial protocols. Verify the specific driver version in Proficy Machine Edition.
Q: Can this HMI be used in outdoor enclosures?
A: The front panel is rated NEMA 4 / IP65, making it suitable for outdoor enclosures with proper panel sealing. The rear of the unit must remain in a controlled environment.
Q: What DC voltage does the IC754VSI06MTD require?
A: The unit operates on 24 VDC nominal. Refer to the GE datasheet for the full input voltage range and current draw specifications.
Q: Is programming software included?
A: No. GE Proficy Machine Edition software is licensed separately from GE. Konmask can advise on software procurement if required.
Q: Can Konmask supply a Certificate of Conformity or test report?
A: Yes. Compliance documentation is available upon request for project submittals and regulatory audits. Contact support@konmask.com.
Q: Do you offer warranty on this unit?
A: All units supplied by Konmask carry a 12-month warranty against manufacturing defects. Warranty claims are processed via our RMA procedure.
