Industrial HMI Operator Interface Solution – GE IC755CSW07CDACA-CG | Quick Panel Series
Where This Product Is Used
The GE IC755CSW07CDACA-CG Quick Panel is a 7-inch widescreen touch screen Human-Machine Interface (HMI) designed for demanding industrial environments. It is widely deployed in the following application scenarios:
- Discrete Manufacturing: Machine tool control panels, assembly line operator stations, and robotic cell interfaces requiring real-time visualization and operator input.
- Process Industries: Water/wastewater treatment plants, chemical dosing systems, and oil & gas skid-mounted control panels where compact, ruggedized HMIs are essential.
- Building Automation & HVAC: Chiller plant monitoring, air handling unit control, and BMS operator terminals integrated with GE PACSystems or third-party PLCs.
- Food & Beverage: Hygienic production line monitoring, batch control visualization, and CIP (Clean-in-Place) sequence displays.
- Power Generation & Utilities: Generator set control panels, substation automation HMI stations, and energy management dashboards.
- OEM Machine Builders: Embedded operator interface for packaging machines, printing presses, and material handling equipment.
Technical Specifications
| Part Number | IC755CSW07CDACA-CG |
| Brand / Manufacturer | GE (General Electric) / Emerson Automation Solutions |
| Series | Quick Panel+ Operator Interface |
| Display Size | 7-inch Widescreen TFT LCD |
| Resolution | 800 × 480 pixels (WVGA) |
| Touch Technology | Resistive Touch Screen |
| Processor | ARM Cortex-A8, 800 MHz |
| Memory | 512 MB RAM / 4 GB Flash |
| Operating System | Windows Embedded Compact 7 |
| Communication Ports | 2× USB Host, 1× USB Device, 1× Ethernet (10/100 Mbps), 1× RS-232/485 Serial |
| Power Supply | 24 VDC (18–30 VDC range) |
| Power Consumption | ≤ 15 W typical |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -20°C to +70°C |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel cutout, flush mount |
| Weight | Approx. 720 g |
| Software | Proficy Machine Edition (PME) / View Designer compatible |
Why Engineers Specify This Model
- Seamless GE PACSystems Integration: Native EtherNet/IP and serial connectivity enables direct communication with GE RX3i, RSTi, and Micro PLC families without additional gateways.
- Compact 7″ Form Factor: Fits standard panel cutouts where space is constrained, while delivering a full-color, high-brightness display readable in bright factory lighting.
- IP65 Front Panel: Protects against dust ingress and water jets — critical for washdown environments in food processing and pharmaceutical applications.
- Windows Embedded CE 7 Platform: Supports custom .NET applications alongside Proficy ME projects, enabling advanced data logging, recipe management, and remote diagnostics.
- Wide Input Voltage Range (18–30 VDC): Tolerates industrial power supply fluctuations without additional conditioning hardware.
- Long Product Lifecycle: GE/Emerson maintains extended support for Quick Panel+ series, reducing obsolescence risk for long-running OEM machine designs.
Complete System Bill of Materials
For a complete Quick Panel operator station, engineers typically specify the following complementary components:
- IC755CSW07CDACA-CG — This HMI unit (7″ Quick Panel+)
- IC695PSD040 — GE PACSystems RX3i 40W Power Supply
- IC695CPE330 — RX3i CPU with Ethernet (controller)
- IC695ETM001 — RX3i Ethernet Interface Module
- IC694MDL754 — Digital Output Module (16-point, 24VDC)
- IC694ALG220 — Analog Input Module (4-channel)
- 24 VDC DIN-rail power supply (e.g., Phoenix Contact QUINT series)
- Shielded Ethernet patch cable (Cat5e or Cat6, industrial rated)
- Panel cutout gasket kit (IP65 sealing)
Contact support@konmask.com for complete BOM sourcing and volume pricing.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive and EMC Directive
- UL Listed — UL 508 (Industrial Control Equipment)
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
- IP65 — IEC 60529 ingress protection (front panel)
- ATEX / Class I Div 2 — Consult factory for hazardous location variants
- EtherNet/IP — ODVA conformance tested
Quality Assurance & Sourcing
Konmask.com sources the GE IC755CSW07CDACA-CG exclusively through verified industrial distribution channels and authorized surplus networks. Every unit undergoes the following before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Power-on functional test: display, touch calibration, and communication port verification
- Firmware version check and documentation
- Anti-static packaging with humidity indicator card
- Certificate of conformance (CoC) available upon request
We carry both new surplus and factory-refurbished stock. Condition is clearly stated on each listing. All units ship with a 12-month warranty against defects in materials and workmanship.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Confirm Stock & Condition: Our team will confirm real-time inventory, unit condition (new/refurbished), and lead time within 24 business hours.
- Receive Proforma Invoice: We issue a detailed PI with unit price, shipping cost, HS code, and payment terms (T/T, PayPal, or trade assurance).
- Shipping & Export: We ship worldwide via DHL, FedEx, or UPS Express. Export documentation (commercial invoice, packing list, CoC) provided for customs clearance.
- After-Sales Support: Technical support available via email and WhatsApp for installation, configuration, and Proficy ME project assistance.
Application-Specific FAQ
Q: Is the IC755CSW07CDACA-CG compatible with non-GE PLCs?
A: Yes. Via its serial RS-232/485 port and Ethernet port, it supports Modbus RTU, Modbus TCP, and EtherNet/IP protocols, enabling connectivity with Siemens, Allen-Bradley, Mitsubishi, and other PLC brands using Proficy ME driver libraries.
Q: What software is required to program this HMI?
A: GE Proficy Machine Edition (PME) with the View Designer module is the primary development environment. A valid PME license is required on the engineering workstation. Contact us if you need software procurement assistance.
Q: Can this unit be used as a replacement for the IC755CSW07CDAC (without the -CG suffix)?
A: The “-CG” suffix typically denotes a country-specific or configuration variant. Functionally, the units are equivalent in most applications, but verify firmware compatibility with your existing PME project before deployment.
Q: What is the panel cutout dimension?
A: The standard panel cutout for the 7″ Quick Panel+ is approximately 192 mm × 138 mm (W × H). Refer to GE document GFK-2847 for exact mechanical drawings.
Q: Do you offer expedited shipping for urgent plant shutdowns?
A: Yes. We maintain express stock for critical MRO situations. Contact us via WhatsApp at +0086 19859288691 for same-day quotation and next-flight-out shipping options.
