Turbine Control Gate Driver Solution — GE IS200IGPAG2AED | Mark VI Series
Where This Product Is Used
The GE IS200IGPAG2AED is an IGPA (Insulated Gate Power Amplifier) gate driver printed circuit board designed for deployment within GE Mark VI Turbine Control Systems. It is a critical power electronics interface board found in the following industrial environments:
- Gas turbine power generation plants — drives IGBT switching stages in excitation and auxiliary power circuits
- Steam turbine control systems — interfaces with the Mark VI VCMI/VCRC control racks for gate pulse distribution
- Combined-cycle (CCGT) facilities — used in both gas and steam turbine control cabinets within the same plant
- Industrial compressor stations — deployed in variable-speed drive control panels using GE Mark VI architecture
- Offshore oil & gas platforms — installed in turbine-driven generator sets requiring high-reliability gate driver boards
- Petrochemical and refinery facilities — supports continuous-process turbine-driven equipment with 24/7 uptime requirements
Engineers specify this board when the Mark VI system reports gate driver faults, IGBT overcurrent trips, or when preventive maintenance schedules call for PCB-level replacement of the IGPA module.
Technical Specifications
| Part Number | IS200IGPAG2AED |
| Manufacturer | General Electric (GE) |
| Series | Mark VI Turbine Control System |
| Board Type | IGPA Gate Driver Printed Circuit Board |
| Form Factor | PCB module, rack-mount compatible |
| Function | IGBT gate pulse amplification and isolation for power converter stages |
| Revision | G2AED (confirm revision compatibility with your Mark VI rack before ordering) |
| Weight | 240 g (bare board) |
| Compatibility | GE Mark VI VCMI, VCRC, and associated power converter racks |
| Operating Environment | Industrial control cabinet, DIN-rail or card-cage installation |
Note: Always cross-reference the revision suffix (G2AED) against your existing Mark VI BOM and GE service documentation before installation.
Why Engineers Specify This Model
- Direct OEM replacement — IS200IGPAG2AED is the exact GE part number; no firmware re-flashing or parameter re-mapping required upon swap-out
- Eliminates root-cause ambiguity — gate driver faults (L3DIAG, IGBT overcurrent, gate voltage out-of-range) are definitively resolved by replacing the IGPA board rather than chasing wiring or IGBT module issues
- Minimizes turbine downtime — a spare IS200IGPAG2AED on the shelf reduces mean-time-to-repair (MTTR) from days to under one hour
- Proven in continuous-duty service — the Mark VI IGPA architecture is field-proven across thousands of GE Frame 6, Frame 7, and Frame 9 turbine installations worldwide
- Supports predictive maintenance programs — rotating spare boards allow condition-based replacement before in-service failure occurs
Complete System Bill of Materials
The IS200IGPAG2AED is typically sourced alongside the following Mark VI and power converter components for a complete repair or spare-parts kit:
- IS200VCMIH2BAB — Mark VI VCMI VME Controller Board
- IS200VCRCH1BBB — Mark VI VCRC Relay Contact Board
- IS200EDCFG1A — Mark VI DC/DC Converter Board
- IS200EPCTG1A — Mark VI Excitation Power Control Board
- DS200SDCCG1AFB — Mark VI Speed/Dynamics Control Card
- IS200IGPAG2AED (this board) — IGPA Gate Driver PCB
Contact support@konmask.com to request a complete Mark VI spare-parts quotation for your plant’s turbine model.
Compliance & Industry Standards
- CE Marking — board manufactured to applicable EU low-voltage and EMC directives
- RoHS — confirm revision-specific RoHS compliance status with GE service documentation
- IEC 61511 / IEC 61508 — Mark VI system architecture is designed for use in SIL-rated safety instrumented systems; consult GE for SIL certification scope
- IEEE 1613 — communication interfaces within the Mark VI platform comply with IEEE 1613 environmental requirements for substation equipment
- ATEX / IECEx — for hazardous-area installations, verify enclosure and installation method compliance separately; the PCB itself is not ATEX-rated
Quality Assurance & Sourcing
Konmask sources the IS200IGPAG2AED through established industrial automation supply channels. Our standard quality process includes:
- Visual inspection — component-level check for physical damage, corrosion, burnt traces, and missing components
- Functional verification — bench-level power-on test where applicable prior to shipment
- Anti-static packaging — all PCBs shipped in ESD-safe bags with foam cushioning inside rigid outer cartons
- Traceability — GE part number, revision, and serial number documented on the packing slip
- Warranty — 90-day replacement warranty against defects in materials and workmanship
We supply both new surplus and professionally refurbished units. Stock condition is confirmed at time of order. Lead time for in-stock units is typically 1–3 business days ex-warehouse.
How to Source This Part
To place an order or request a quotation for the GE IS200IGPAG2AED:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://konmask.com
Please include your turbine model (e.g., GE Frame 7EA), Mark VI rack configuration, and required quantity in your inquiry to ensure revision compatibility and fastest response.
We accept T/T bank transfer, PayPal, and major trade-finance instruments. Export documentation (commercial invoice, packing list, COO) provided for all international shipments.
Application-Specific FAQ
Q: Can the IS200IGPAG2AED be used as a direct drop-in replacement without reconfiguration?
A: Yes, for the same revision (G2AED). The board is a hardware replacement; no software or parameter changes are required in the Mark VI controller. Always verify the revision suffix matches your existing board before installation.
Q: What Mark VI fault codes indicate a failed IGPA gate driver board?
A: Common diagnostic codes include L3DIAG gate driver fault, IGBT overcurrent (IOC) trip, gate voltage out-of-range alarm, and asymmetric gate pulse width errors. Consult your GE Mark VI maintenance manual (GEH-6721) for fault-code-to-board mapping.
Q: Do you supply the IS200IGPAG2AED for both gas and steam turbine Mark VI systems?
A: Yes. The IGPA board is used across GE’s Mark VI platform regardless of turbine type. Confirm your rack slot assignment and revision with your plant’s as-built drawings.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, sourcing lead time is typically 2–4 weeks. Contact us for real-time stock confirmation.
Q: Can Konmask provide a certificate of conformance (CoC)?
A: Yes. A CoC documenting part number, revision, condition, and inspection results is available upon request at no additional charge.
