GE IS200VVIBH1CAC – VME Vibration Monitor Card | Mark VI Turbine Control Platform
Engineering Background: The IS200VVIBH1CAC is a VME-format vibration monitoring input card designed for GE’s Mark VI turbine control system — one of the most widely deployed distributed control architectures in power generation and heavy industrial applications. This card serves as the front-end signal acquisition interface for shaft vibration, bearing vibration, and proximity probe inputs, feeding real-time data into the Mark VI’s redundant control loops.
Product Positioning: Engineered for mission-critical rotating machinery protection, the IS200VVIBH1CAC is a direct replacement or spare component for gas turbines, steam turbines, and compressor trains running on GE Mark VI / Mark VIe platforms. Konmask.com supplies this card as a tested, quality-verified unit sourced through authorized industrial channels, suitable for immediate deployment or strategic spare inventory.
Complete Technical Specifications
- Part Number: IS200VVIBH1CAC
- Manufacturer: GE (General Electric) — Energy Controls Division
- Platform: Mark VI / Mark VIe Turbine Control System
- Form Factor: VME (Versa Module Europa) Card
- Function: Vibration Monitoring Input Card
- Input Type: Proximity probe / eddy-current sensor inputs (Bently Nevada compatible signal levels)
- Channel Configuration: Multi-channel vibration and position signal acquisition
- Communication: VME backplane bus interface to Mark VI I/O rack
- Operating Temperature: 0°C to 60°C (standard industrial range)
- Power Supply: Supplied via VME backplane (±5V / ±12V / +24V)
- Weight: 220 g
- Compliance: CE, UL industrial standards applicable to GE Mark VI platform
- Revision: H1CAC (hardware revision suffix)
Proven Application Environments
- Gas turbine generator sets (Frame 5, Frame 6, Frame 7, Frame 9 series)
- Steam turbine control and protection systems
- Industrial compressor trains with Mark VI DCS integration
- Combined-cycle power plants (CCPP) with GE turbine islands
- Offshore platform turbine control (ATEX-rated enclosure installations)
- Petrochemical plant rotating equipment protection systems
Engineering Advantages
- Direct OEM Replacement: Plug-and-play compatibility with existing Mark VI I/O racks — no firmware modification required for same-revision swap
- High-Resolution Signal Acquisition: Captures shaft vibration data with the precision required for API 670 machinery protection compliance
- Redundancy Support: Compatible with Mark VI TMR (Triple Modular Redundancy) and simplex configurations
- Proven Field Reliability: Deployed across thousands of GE turbine installations globally with documented MTBF exceeding 100,000 hours
- Minimal Downtime Swap: Hot-swap capable within Mark VI rack architecture (configuration-dependent)
System Architecture & Signal Flow
The IS200VVIBH1CAC resides in the Mark VI I/O module rack and interfaces directly with proximity probes mounted on turbine bearing housings. Raw analog vibration signals are conditioned, digitized, and transmitted via the VME backplane to the Mark VI controller (VCMI/VCRC boards). The controller processes these signals against configured alarm and trip setpoints, enabling real-time machinery protection and predictive maintenance data logging.
Signal Path: Proximity Probe → IS200VVIBH1CAC (signal conditioning + ADC) → VME Backplane → Mark VI Controller → HMI / Historian
Sourcing & Quality Verification
- Each unit undergoes visual inspection for PCB integrity, connector condition, and component completeness
- Functional bench test performed against GE Mark VI I/O rack reference configuration prior to shipment
- Units supplied with anti-static packaging and humidity indicator cards
- Traceability documentation available upon request (serial number, test record)
- 90-day warranty against manufacturing defects and functional failure under normal operating conditions
Procurement Process
- Step 1: Confirm your Mark VI rack slot assignment and existing card revision (H1CAC or compatible)
- Step 2: Submit your purchase order or RFQ to support@konmask.com
- Step 3: Receive proforma invoice with lead time confirmation (typically 3–7 business days for in-stock units)
- Step 4: Payment via T/T, L/C, or agreed terms — shipment via DHL / FedEx with full tracking
- Step 5: Receive unit with test report and installation guidance documentation
Technical FAQ
- Q: Is IS200VVIBH1CAC compatible with Mark VIe as well as Mark VI?
- A: The IS200VVIBH1CAC is primarily designed for the Mark VI VME rack architecture. Mark VIe uses a different I/O module form factor (IS200 series ETM/IONet). Please confirm your rack type before ordering.
- Q: Can this card be used as a cold spare without pre-configuration?
- A: Yes. The card stores no site-specific configuration — all parameters reside in the Mark VI controller. A same-revision replacement card can be installed and will adopt the existing configuration automatically upon rack initialization.
- Q: What proximity probe types are compatible?
- A: The card is designed for Bently Nevada 3300/3500 series compatible eddy-current proximity probes operating at standard -24V DC driver supply. Verify probe driver compatibility with your site’s existing probe system.
- Q: Do you provide export documentation for international shipments?
- A: Yes. We provide commercial invoice, packing list, certificate of origin, and ECCN classification documentation as required for customs clearance.
