GE Multilin UR6DV – Digital I/O Input Module | Universal Relay Platform
Engineering Background: The GE Multilin Universal Relay (UR) series represents GE Grid Solutions’ flagship protection and control platform, deployed across transmission substations, generation facilities, and industrial power systems worldwide. The UR platform’s modular architecture allows engineers to configure relay functionality precisely to application requirements — eliminating over-specification and reducing lifecycle cost.
Product Positioning: The UR6DV is a dedicated Digital I/O module designed for the UR chassis. It expands the relay’s digital input and output capacity, enabling integration with external switching devices, SCADA systems, and interlocking circuits. This module is essential for complex protection schemes requiring high channel density and deterministic response times.
Complete Technical Specifications
- Part Number / SKU: UR6DV
- Manufacturer: GE Multilin (GE Grid Solutions)
- Platform: Universal Relay (UR) Series
- Module Type: Digital I/O Input Module
- Form Factor: UR Modular Chassis Plug-in Card
- Digital Inputs: 24 channels (wet/dry contact configurable)
- Digital Outputs: High-speed form-A and form-C relay outputs
- Input Voltage Range: 24 VDC / 48 VDC / 110 VDC / 125 VDC / 250 VDC (field selectable)
- Response Time: < 1 ms (digital input recognition)
- Communication Protocol: IEC 61850 GOOSE, DNP3, Modbus RTU/TCP
- Operating Temperature: –40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Compliance: IEC 60255, IEEE C37.90, UL, CE
- Mounting: UR 19″ rack chassis (3U / 6U compatible)
- Weight: Approx. 0.45 kg
- Country of Origin: Canada / USA
Proven Application Environments
- Transmission and distribution substation protection panels
- Generator protection and excitation control systems
- Motor protection and feeder management in industrial plants
- Busbar differential protection schemes
- SCADA-integrated interlocking and supervisory control circuits
- Renewable energy (wind/solar) grid interconnection protection
- Oil & gas upstream/downstream electrical protection systems
Engineering Advantages
- High Channel Density: 24 digital I/O channels per module slot — maximizes chassis utilization and minimizes panel footprint.
- Deterministic Latency: Sub-millisecond input recognition ensures protection scheme timing integrity.
- IEC 61850 GOOSE Ready: Native support for peer-to-peer protection messaging without hardwired interposing relays.
- Wide DC Input Range: Field-selectable voltage thresholds accommodate diverse substation battery bus standards.
- Hot-Swap Compatible: UR chassis architecture supports module replacement without full system de-energization (verify with site safety procedures).
- Backward Compatible: Interoperable with existing UR chassis generations — protects prior capital investment.
System Architecture & Signal Flow
The UR6DV installs into any available I/O slot of a UR chassis (3U or 6U form factor). Digital input signals from field devices (auxiliary contacts, pushbuttons, SCADA outputs) are optically isolated and conditioned before being passed to the UR CPU module via the chassis backplane. The CPU processes logic equations and protection elements in real time, then drives output commands back through the UR6DV’s relay output contacts to trip coils, alarms, or interlocking circuits. All I/O states are time-stamped and logged for post-event analysis via the UR’s onboard event recorder.
Sourcing & Quality Verification
- Source: Konmask.com sources UR6DV modules from verified OEM channels and authorized industrial surplus networks.
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-shipment checks.
- Authenticity: GE Multilin holographic labels and date codes are verified prior to dispatch.
- Condition: New (sealed OEM) and refurbished (tested, warranted) stock available — specify at inquiry.
- Documentation: Factory test reports and calibration certificates available upon request for critical applications.
Procurement Process
- Submit your RFQ via the product page or email support@konmask.com.
- Receive stock confirmation, lead time, and formal quotation within 24 hours.
- Issue PO — we accept T/T wire transfer, PayPal, and major credit cards.
- Unit ships with commercial invoice, packing list, and tracking number.
- Customs documentation (HS code, COO certificate) provided for international orders.
Technical FAQ
Q: Is the UR6DV compatible with all UR chassis generations?
A: The UR6DV is designed for the GE Multilin UR platform. Compatibility depends on chassis firmware version — contact us with your chassis model for confirmation.
Q: Can the digital inputs be configured for both wet and dry contacts?
A: Yes. Input thresholds are field-configurable via UR Setup software to accommodate both wet (voltage-sourced) and dry (voltage-free) contact types.
Q: What is the warranty on refurbished units?
A: Refurbished UR6DV modules carry a 12-month functional warranty. New sealed units carry the standard GE Multilin warranty.
Q: Do you provide IEC 61850 configuration support?
A: Yes. Our engineering team can assist with SCL/CID file configuration for IEC 61850 GOOSE integration — inquire at time of order.
Q: What is the lead time for in-stock units?
A: In-stock units ship within 1–3 business days. Out-of-stock lead times vary by sourcing channel — typically 2–6 weeks.
