GE VMIPCI-5565-110000 Reflective Memory Interface | PCI-5565 Series

GE VMIPCI-5565-110000 Reflective Memory Interface – PCI-5565 Series

Imagine a high-speed manufacturing line where dozens of controllers, motion systems, and SCADA nodes must share real-time process data with zero latency tolerance. Without a dedicated reflective memory interface, engineers are forced to rely on conventional Ethernet or fieldbus solutions that introduce unacceptable jitter, protocol overhead, and single-point-of-failure risks. A missed synchronization pulse in a turbine control system or a delayed position update in a coordinated robotics cell can cascade into costly downtime, equipment damage, or even safety incidents. The GE VMIPCI-5565-110000 eliminates this vulnerability by providing deterministic, broadcast-based shared memory across the entire control network.

The VMIPCI-5565-110000 is the PCI form-factor flagship of GE’s renowned VMIC PCI-5565 Reflective Memory Node family — a product line that has earned its place as the gold standard for real-time distributed shared memory in mission-critical industrial automation. Deployed across power generation, aerospace test rigs, semiconductor fabrication, and advanced motion control platforms worldwide, the PCI-5565 series is trusted where determinism is non-negotiable. The -110000 variant delivers the full-featured configuration with fiber-optic ring topology support, making it the preferred choice for electrically noisy industrial environments requiring galvanic isolation and long-distance node interconnection.

Technical Specifications

• Part Number: VMIPCI-5565-110000
• Manufacturer: GE (formerly VMIC / GE Intelligent Platforms)
• Series: PCI-5565 Reflective Memory Node
• Form Factor: PCI (32-bit, 33/66 MHz)
• Memory Size: 64 MB shared reflective memory
• Interface: Fiber-optic ring network
• Data Transfer Rate: Up to 174 MB/s (node-to-node)
• Network Topology: Unidirectional fiber-optic ring
• Max Nodes per Ring: 256
• Max Ring Distance: Up to 10 km (multimode fiber)
• Interrupt Support: Yes — network and local interrupts
• OS Support: Windows, Linux, VxWorks, LynxOS, QNX, Solaris
• Operating Temperature: 0°C to +55°C
• Weight: 380 g
• RoHS Compliance: Please confirm with datasheet

Note: All specifications are sourced from GE official documentation. Konmask.com does not fabricate or alter manufacturer specifications.

Key Features & Benefits

• True Determinism: Reflective memory architecture guarantees that data written at one node is available at all other nodes within a fixed, bounded latency — no polling, no arbitration delays.
• Fiber-Optic Isolation: The -110000 variant uses fiber-optic interconnects, providing complete galvanic isolation and immunity to EMI/RFI — essential in high-voltage switchgear rooms, motor drive environments, and welding cells.
• Transparent to Software: The shared memory appears as standard RAM to the host CPU; no special communication protocol stack is required, dramatically simplifying application development.
• Scalable Ring Architecture: Supports up to 256 nodes on a single ring, enabling large-scale distributed control architectures without a central communication bottleneck.
• High Throughput: 174 MB/s sustained transfer rate supports high-resolution process data, waveform capture, and coordinated motion profiles.
• Interrupt-Driven Synchronization: Hardware interrupt generation on data arrival enables tight real-time loop closure without CPU polling overhead.
• Broad OS Ecosystem: Supported under all major real-time and general-purpose operating systems used in industrial computing platforms.

Industry & Equipment Applications

• Power Generation & Utilities: Turbine control synchronization, generator protection relay coordination, substation automation
• Aerospace & Defense Test: Hardware-in-the-loop (HIL) simulation, flight control system test benches, radar signal processing
• Semiconductor Manufacturing: Wafer handling robot coordination, process chamber synchronization, APC (Advanced Process Control) data sharing
• Automotive Test & Assembly: Engine test cell data acquisition, coordinated multi-axis press control, end-of-line functional testers
• Oil & Gas: Compressor train control, pipeline SCADA integration, safety instrumented system (SIS) data exchange
• Research & Simulation: Real-time simulation clusters (dSPACE, National Instruments, Speedgoat), distributed data acquisition systems

System Integration & Compatible Parts

The VMIPCI-5565-110000 is designed to operate within GE’s broader VMIC reflective memory ecosystem. Compatible and complementary components include:

• VMIVME-5565 — VMEbus form-factor reflective memory node for legacy VME backplane systems
• VMIC-5565-3MFIB — 3-meter multimode fiber-optic patch cable for ring interconnection
• VMIPCI-5565-110001 — Variant with extended temperature range for harsh environments
• GE PMCPCI-5565 — PMC mezzanine form-factor for embedded computing platforms
• GE RFM2g Driver SDK — Software development kit for Linux/Windows application integration

Contact Konmask.com to verify cross-compatibility and request a complete BOM for your system architecture.

Our Quality Assurance Process

Every GE VMIPCI-5565-110000 unit sourced and supplied by Konmask.com undergoes a rigorous multi-stage verification process before shipment:

• Visual Inspection: PCB, connectors, fiber-optic ports, and component integrity checked against GE reference standards
• Functional Power-On Test: Unit is powered and enumerated in a PCI test chassis to confirm firmware boot and memory initialization
• Loopback Communication Test: Fiber-optic ring loopback test performed to validate transmit/receive path integrity
• Firmware Version Verification: Confirmed against GE’s published firmware revision history
• Anti-Static Packaging: Shipped in ESD-safe bags with foam cushioning and moisture barrier packaging
• Documentation Package: Certificate of testing, original GE datasheet, and packing list included with every shipment

How to Order

1. Submit an Inquiry: Use the contact form on this page or email support@konmask.com with your required quantity and delivery timeline.
2. Receive a Quotation: Our technical sales team will respond within 1 business day with pricing, lead time, and availability confirmation.
3. Order Confirmation: Confirm your purchase order via email or our online checkout process.
4. Quality Inspection & Dispatch: Unit is tested, packaged, and dispatched with full tracking information.
5. After-Sales Support: Our engineering team remains available for integration assistance and warranty claims.

Why Choose Konmask.com?

• ✅ Specialized in Industrial Automation Components — PLC modules, DCS cards, motion controllers, and communication interfaces from leading global brands
• ✅ Genuine Parts Guarantee — We source directly from authorized distributors and verified secondary market channels; every unit is traceable
• ✅ Technical Expertise — Our team includes experienced control system engineers who can advise on compatibility, integration, and system design
• ✅ Global Shipping — Fast, reliable international logistics with DHL, FedEx, and UPS; export documentation provided for customs clearance
• ✅ Responsive Quotation — Inquiry-to-quote within 24 hours; urgent requirements accommodated
• ✅ Long-Term Partnership — We support MRO buyers, system integrators, OEMs, and engineering firms with ongoing supply chain solutions

Frequently Asked Questions

Q: Is the VMIPCI-5565-110000 compatible with modern PCIe motherboards?
A: The VMIPCI-5565-110000 uses the legacy 32-bit PCI bus standard. It is NOT compatible with PCIe slots. A PCI-to-PCIe bridge card or a motherboard with native PCI slots is required. Please verify your host system’s slot availability before ordering.

Q: What fiber-optic cable type is required?
A: The -110000 variant uses 62.5/125 µm multimode fiber-optic cable with ST connectors. Maximum segment length is approximately 300 meters per node-to-node link (up to 10 km total ring circumference).

Q: Can this card be used in a mixed VME/PCI network?
A: Yes. The PCI-5565 and VME-5565 nodes share the same reflective memory protocol and can coexist on the same fiber-optic ring, enabling hybrid VME/PCI system architectures.

Q: Do you provide driver software and SDK?
A: GE’s RFM2g driver package supports Windows and Linux. We can assist customers in locating the appropriate driver version. SDK licensing is managed by GE/Abaco Systems.

Q: What is the warranty on this product?
A: Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available upon request.

Q: Can you supply multiple units for a large project?
A: Yes. We maintain relationships with multiple supply channels and can fulfill both single-unit MRO orders and multi-unit project requirements. Contact us for volume pricing.

---
