GE IC200UDR005-BD VersaMax Micro Controller | Replacement, Equivalent & Selection Guide
The GE IC200UDR005-BD is a compact 14-point DC input/relay output VersaMax Micro PLC controller designed for small-to-mid-scale industrial automation. Whether you are sourcing an original unit, evaluating a compatible replacement, or selecting the right controller for a new project, this guide covers everything you need.
Technical Specifications
- Part Number: IC200UDR005-BD
- Brand: GE (General Electric) / GE Fanuc / Emerson
- Series: VersaMax Micro
- Form Factor: Micro PLC (standalone, DIN-rail mountable)
- I/O Points: 14 total — 8 DC inputs, 6 relay outputs
- Input Voltage: 24 VDC
- Output Type: Relay
- Power Supply: 24 VDC
- Communication Port: RS-232 serial (built-in)
- Programming Software: Proficy Machine Edition (ME)
- Memory: 16 KB program memory
- Weight: approx. 580 g
- Operating Temperature: 0°C to 55°C
- Certifications: CE, UL
Compatible Replacement & Equivalent Models
If the IC200UDR005-BD is unavailable or discontinued in your region, the following models offer functional equivalence or drop-in compatibility:
- IC200UDR005 — Base variant without the -BD suffix (same I/O, verify firmware revision)
- IC200UDR020 — 20-point DC/relay VersaMax Micro; upward-compatible with expanded I/O
- IC200UDR040 — 40-point version for larger applications requiring the same relay output type
- IC200UAL005 — AC-powered variant; same 14-point layout, different power supply
- Emerson IC200UDR005-BD — Rebranded equivalent after GE Automation & Controls acquisition
- Siemens SIMATIC S7-1200 CPU 1211C — Cross-brand alternative for new designs (requires reprogramming)
- Mitsubishi FX3U-16MR/ES — Cross-brand relay output alternative with comparable I/O count
Note: Always verify I/O count, power supply voltage, and communication protocol before substituting. Contact support@konmask.com for compatibility confirmation.
Why Choose the Original IC200UDR005-BD
- Proven reliability in OEM machine designs and legacy system retrofits
- Direct drop-in replacement for existing VersaMax Micro installations — no rewiring required
- Native compatibility with GE Proficy Machine Edition programming environment
- Relay outputs support mixed AC/DC load switching up to 2 A per point
- Compact footprint ideal for panel space-constrained applications
- Long field service history with extensive third-party documentation and community support
Typical Applications
- Conveyor and material handling control
- Pump and motor sequencing
- HVAC and building automation
- Packaging machine control
- Water treatment and process control
- OEM machine builders requiring a compact, cost-effective PLC
System Compatibility
- Programming Software: GE Proficy Machine Edition 8.x and later
- Communication: RS-232 direct serial; optional Ethernet via IC200USB001 USB adapter
- Expansion: Compatible with VersaMax Micro expansion modules (IC200EXM series)
- HMI Integration: Compatible with GE QuickPanel, Weintek, Proface, and most Modbus-capable HMIs
- SCADA: Integrates with iFIX, Ignition, and other OPC-DA/UA platforms via serial gateway
Selection Guide
Use the table below to select the right VersaMax Micro model for your application:
- 14-pt DC input / Relay output / 24 VDC power → IC200UDR005-BD ✓ (this model)
- 14-pt DC input / Relay output / 120 VAC power → IC200UAL005
- 20-pt DC input / Relay output / 24 VDC power → IC200UDR020
- 28-pt DC input / Transistor output / 24 VDC power → IC200UDD020
- 40-pt DC input / Relay output / 24 VDC power → IC200UDR040
Key selection criteria: total I/O count, output type (relay vs. transistor), power supply voltage, and required communication ports.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Pre-shipment functional testing available on request
- Original factory packaging and documentation where available
- Traceability records maintained for industrial and regulated applications
- Warranty: 90-day replacement warranty on all stocked units
How to Order
- Confirm part number: IC200UDR005-BD
- Specify required quantity
- Add to cart and proceed to checkout, or contact us for bulk/project pricing
- For urgent requirements, email support@konmask.com or call +0086 19859288691
- Lead time: in-stock units ship within 1–3 business days; sourced units 5–15 business days
Replacement & Compatibility FAQ
Q: Is IC200UDR005 the same as IC200UDR005-BD?
A: The -BD suffix typically denotes a specific firmware or hardware revision. Functionally they are equivalent in most applications, but verify the revision level with your OEM documentation before substituting.
Q: Can I replace IC200UDR005-BD with a Siemens or Mitsubishi PLC?
A: Yes, but it requires reprogramming in the target platform’s software. Cross-brand replacements are suitable for new designs, not direct drop-in retrofits.
Q: Does this controller support Ethernet communication?
A: Not natively. Ethernet connectivity requires an external serial-to-Ethernet gateway or the IC200USB001 adapter with a PC-based OPC server.
Q: What programming cable is required?
A: Use the IC690ACC901 RS-232 cable or a compatible USB-to-serial adapter with the Proficy Machine Edition software.
Q: Is this model still in production?
A: GE Automation & Controls (now Emerson) has transitioned some VersaMax Micro variants to end-of-life. Konmask.com maintains stock of new and refurbished units to support legacy installations.
