HBM WGX002-PX01PN – High-Speed Precision Measurement Amplifier | PMX Platform
Engineering Background: The PMX system is HBM’s flagship modular measurement platform, engineered for demanding industrial test & measurement environments. Designed in Germany to DIN EN ISO 9001 standards, the PMX platform delivers laboratory-grade accuracy in production and field conditions alike.
Product Positioning: The WGX002-PX01PN is a universal amplifier module for the PMX carrier system, purpose-built for procurement engineers who require traceable, high-bandwidth signal conditioning for strain gauges, load cells, force transducers, and torque sensors. It eliminates the need for external signal conditioners, reducing panel footprint and wiring complexity in multi-channel test rigs.
Complete Technical Specifications
- Part Number / SKU: WGX002-PX01PN
- Platform / Series: HBM PMX Modular Measurement System
- Module Type: Universal Amplifier / Signal Conditioner
- Manufacturer: HBM (Hottinger Baldwin Messtechnik GmbH), Germany
- Country of Origin: Germany (DE)
- Input Compatibility: Strain gauge (full/half/quarter bridge), LVDT, potentiometer, voltage, current
- Excitation Voltage: Configurable (typically 2.5 V / 5 V / 10 V DC)
- Measurement Rate: Up to 19,200 samples/second per channel
- Resolution: 24-bit ADC
- Accuracy Class: 0.01% FS (typical)
- Communication Interface: EtherCAT, Ethernet (TCP/IP), USB (via PMX base unit)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +70 °C
- Protection Class: IP20 (module), IP65 (system enclosure option)
- Power Supply: Via PMX backplane (24 V DC system bus)
- Dimensions (W × H × D): ~25 mm × 130 mm × 110 mm (single slot)
- Weight: Approx. 200 g
- Certifications: CE, RoHS compliant
- HS Code: 9031.80 (Measuring / checking instruments)
Proven Application Environments
- Automotive NVH and durability test benches (force, torque, strain)
- Aerospace structural fatigue testing and load monitoring
- Industrial press force monitoring and quality control
- Wind turbine drivetrain torque measurement
- Railway bogie and wheel-set load testing
- Research & development labs requiring multi-channel synchronous acquisition
- OEM integration into custom test & measurement systems
Engineering Advantages
- Hot-swap capable: Modules can be replaced without powering down the PMX base unit, minimizing production downtime.
- TEDS support: Automatic transducer identification via IEEE 1451.4 TEDS eliminates manual calibration entry errors.
- Synchronous multi-channel: All PMX modules share a common clock, ensuring phase-coherent data across all channels.
- Software ecosystem: Native integration with HBM catman®AP, LabVIEW, MATLAB, and EtherCAT master controllers.
- Shunt calibration: Built-in electronic shunt for in-situ verification without disconnecting sensors.
- EMC hardened: Designed for industrial EMC environments per EN 61326-1.
System Architecture & Signal Flow
The WGX002-PX01PN slots into any PMX base unit (PX01 series carrier). The signal path is: Sensor → WGX002-PX01PN amplifier module → 24-bit ADC → PMX backplane bus → EtherCAT / Ethernet output → Host PC / PLC / SCADA. The modular architecture allows mixing of different module types (strain, voltage, IEPE, thermocouple) within a single chassis, with all channels time-stamped to a common reference clock.
Sourcing & Quality Verification
- Authenticity: All units sourced through verified HBM authorized distribution channels or directly from HBM-certified surplus inventories.
- Inspection: Each module undergoes incoming inspection including visual check, firmware version verification, and functional power-on test before dispatch.
- Documentation: Original HBM calibration certificate and datasheet available upon request.
- Traceability: Serial number and manufacturing date recorded for full supply chain traceability.
- Warranty: 90-day functional warranty against defects in materials and workmanship.
Procurement Process
- Inquiry: Submit your RFQ with required quantity and delivery timeline to support@konmask.com or via the product page.
- Quotation: We respond within 1 business day with pricing, lead time, and stock confirmation.
- Order Confirmation: Purchase order accepted via email, Shopify checkout, or wire transfer (T/T).
- Inspection & Dispatch: Module inspected, securely packaged in anti-static ESD packaging, and shipped via DHL Express / FedEx International Priority.
- Delivery: Typical transit: 3–7 business days worldwide. Tracking number provided upon dispatch.
- After-Sales: Technical support available via email and WhatsApp for integration and commissioning queries.
Technical FAQ
Q: Is the WGX002-PX01PN compatible with all PMX base units?
A: Yes. The WGX002-PX01PN is designed for the PX01 series PMX carrier and is compatible with all current PMX base unit variants (PX01PN, PX01ET, etc.).
Q: Can I use this module with quarter-bridge strain gauges?
A: Yes. The module supports full, half, and quarter-bridge configurations with selectable completion resistors.
Q: What software is required to configure the module?
A: HBM catman®AP (Windows) is the primary configuration and data acquisition software. EtherCAT master configuration is also supported via standard ESI files.
Q: Is calibration documentation available?
A: Yes. Original HBM calibration certificates and factory test reports are available upon request for quality-critical applications.
Q: Do you offer volume pricing for OEM or system integrator orders?
A: Yes. Please contact us directly at support@konmask.com for volume discount schedules.
