HIMA F3DIO 20/8 02 (F3DIO20/802) Digital I/O Module | Replacement, Equivalent & Selection Guide
The HIMA F3DIO 20/8 02 (part number F3DIO20/802) is a safety-rated Digital Input/Output module designed for the HIMA HIMax safety PLC platform. It delivers 20 digital inputs and 8 digital outputs in a single compact module, certified for use in SIL 3 / IEC 61508 safety instrumented systems across oil & gas, chemical, power generation, and industrial automation environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | F3DIO 20/8 02 / F3DIO20/802 |
| Manufacturer | HIMA Paul Hildebrandt GmbH |
| Series | HIMax |
| Module Type | Digital I/O (DIO) |
| Digital Inputs | 20 channels |
| Digital Outputs | 8 channels |
| Safety Integrity Level | SIL 3 (IEC 61508) |
| Input Voltage | 24 V DC |
| Output Type | Transistor (solid-state) |
| Communication | HIMax backplane bus |
| Approvals | TÜV, ATEX (Zone 2), IECEx |
| Weight | approx. 860 g |
| Operating Temperature | 0 °C to +60 °C |
| Housing | DIN-rail / HIMax rack mount |
Compatible Replacement & Equivalent Models
When the F3DIO 20/8 02 is unavailable or end-of-life, the following models may serve as functional equivalents or drop-in replacements depending on your system revision:
- HIMA F3DIO 20/8 01 — Previous hardware revision; same I/O count, verify firmware compatibility before substitution.
- HIMA F3DIO 16/8 01 — Reduced input count (16 DI / 8 DO); suitable when full 20-input capacity is not required.
- HIMA F3DIO 8/8 01 — Compact variant for smaller I/O footprints in HIMax racks.
- HIMA F35DO 16 01 — Pure digital output module; pair with a dedicated DI module if output-only expansion is needed.
- Third-party SIL 3 DIO modules — Pilz, Rockwell GuardLogix, or Siemens S7-F series may be considered for full system migrations; requires full re-engineering and re-validation.
⚠ Always verify hardware revision, firmware version, and HIMax rack slot compatibility before substituting any module in a certified safety system.
Why Choose the Original Model
- Factory-certified SIL 3 safety rating — no re-validation cost.
- Seamless plug-and-play replacement within existing HIMax racks.
- Full HIMA ELOP II / SILworX engineering tool compatibility.
- Proven field reliability in critical process safety applications.
- Backed by HIMA global service and spare-parts support.
Typical Applications
- Emergency Shutdown Systems (ESD) in oil & gas facilities
- Burner Management Systems (BMS) in power plants
- High-integrity pressure protection systems (HIPPS)
- Fire & Gas detection and suppression control
- Chemical reactor safety interlocks
- Offshore platform safety instrumented systems
System Compatibility
- Platform: HIMA HIMax Safety PLC
- Rack: HIMax central rack and expansion racks
- Engineering Software: SILworX (HIMA), ELOP II Factory
- Communication: HIMax proprietary backplane; supports redundant CPU configurations
- Standards: IEC 61508, IEC 61511, EN 50156, NFPA 72
Selection Guide
Use the table below to select the right HIMA DIO module for your application:
| Requirement | Recommended Model |
|---|---|
| 20 DI + 8 DO, SIL 3, HIMax | F3DIO 20/8 02 ✓ (this product) |
| 16 DI + 8 DO, SIL 3, HIMax | F3DIO 16/8 01 |
| 8 DI + 8 DO, SIL 3, HIMax | F3DIO 8/8 01 |
| Pure DO expansion, SIL 3 | F35DO 16 01 |
| Previous revision (legacy) | F3DIO 20/8 01 |
Not sure which module fits your rack configuration? Contact our technical team — we’ll verify slot compatibility and firmware revision for you.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels.
- Each module undergoes visual inspection, functional verification, and packaging integrity check before shipment.
- Traceability documentation and test reports available upon request.
- Genuine HIMA OEM parts — no counterfeit or refurbished units without prior disclosure.
- Export compliance: ECCN classification and export licensing support available.
How to Order
- Add the HIMA F3DIO 20/8 02 (F3DIO20/802) to your cart.
- Proceed to checkout — we accept T/T bank transfer, PayPal, and major credit cards.
- For bulk orders (>3 units) or urgent requirements, contact us directly for lead time and pricing.
- Provide your project PO number or end-user declaration if required for export compliance.
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace F3DIO 20/8 01 with F3DIO 20/8 02 directly?
A: In most cases yes — the 02 revision is the updated successor. Verify your HIMax firmware version and SILworX project settings before hot-swapping in a live safety system.
Q: Is this module compatible with HIMA H41q / H51q systems?
A: No. The F3DIO 20/8 02 is designed exclusively for the HIMax platform. For H41q/H51q, refer to the HIMA F2 or F3 series modules.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. CoC and traceability documentation are available upon request at time of order.
Q: What is the lead time?
A: In-stock units ship within 3–5 business days. Out-of-stock items typically have a 4–8 week lead time. Contact us to confirm current availability.
Q: Can you source other HIMA HIMax modules?
A: Yes — we specialize in HIMA, ABB, Siemens, Rockwell, and other industrial automation components. Submit your BOM for a complete quote.
© 2026 Konmask.com. All rights reserved.
