HIMA F60MI2401 – 24-Channel Analog Input Module | HIMatrix Safety PLC Platform
Engineering Background
The HIMA F60MI2401 is a high-integrity analog input module engineered for the HIMatrix distributed safety controller platform. HIMA Paul Hildebrandt GmbH, founded in 1908 and headquartered in Brühl, Germany, is a global leader in safety-critical automation systems. The HIMatrix series represents HIMA’s modular, IEC 61508-certified architecture designed for process industries where functional safety is non-negotiable.
Product Positioning
The F60MI2401 serves as the primary analog signal acquisition front-end for HIMatrix safety controllers, enabling precise measurement of 4–20 mA and voltage signals from field transmitters, sensors, and transducers. It is the preferred choice for procurement engineers specifying SIL 2/3-rated analog input infrastructure in oil & gas, chemical, power generation, and offshore applications.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number / SKU | F60MI2401 |
| Manufacturer | HIMA Paul Hildebrandt GmbH |
| Series / Platform | HIMatrix Safety PLC |
| Module Type | Analog Input Module |
| Number of Channels | 24 (configurable) |
| Input Signal Range | 4–20 mA / 0–10 V (software selectable) |
| Resolution | 16-bit ADC |
| Accuracy | ±0.1% of full scale |
| Safety Integrity Level | SIL 2 / SIL 3 (IEC 61508) |
| Functional Safety Standard | IEC 61508, IEC 61511 |
| Supply Voltage | 24 V DC (18–30 V DC) |
| Power Consumption | ≤ 8 W (typical) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% RH, non-condensing |
| Protection Class | IP20 |
| Dimensions (W × H × D) | Refer to HIMA datasheet |
| Weight | 380 g (approx.) |
| Certifications | TÜV, CE, ATEX (zone 2 barrier compatible) |
| Communication Interface | HIMatrix backplane bus |
| Diagnostic Coverage | > 99% (DC high per IEC 61508) |
| Country of Origin | Germany |
Proven Application Environments
- Oil & Gas: Wellhead control panels, emergency shutdown systems (ESD), fire & gas detection (F&G)
- Chemical & Petrochemical: Reactor temperature/pressure monitoring, SIS loop integration
- Power Generation: Turbine control analog feedback, boiler safety interlocks
- Offshore Platforms: HIPPS (High Integrity Pressure Protection Systems)
- Water & Wastewater: Flow and level measurement in safety-rated loops
- Pharmaceutical: Process parameter monitoring under FDA 21 CFR Part 11 environments
Engineering Advantages
- SIL 3 Certified: Independently verified by TÜV Rheinland for use in safety instrumented functions up to SIL 3
- High Diagnostic Coverage: Internal self-test routines detect channel faults within one safety cycle, minimizing dangerous undetected failures
- Hot-Swap Capable: Module replacement without system shutdown in redundant HIMatrix configurations
- Galvanic Isolation: Channel-to-channel and channel-to-bus isolation protects against ground loops and transient interference
- Flexible Signal Conditioning: Software-configurable input type eliminates the need for external signal converters
- Compact Footprint: High channel density reduces cabinet space and wiring complexity
System Architecture & Signal Flow
The F60MI2401 plugs directly into the HIMatrix backplane, communicating with the central safety CPU via the proprietary high-speed safety bus. Field signals enter through front-face terminal connectors, pass through galvanically isolated input circuits, are digitized by a 16-bit ADC, and transmitted to the CPU for safety function execution. The module supports 1oo1, 1oo2, and 2oo3 voting architectures depending on the system redundancy configuration.
Compatible CPUs include HIMatrix F35, F60, and HIMAX series controllers. Engineering configuration is performed via ELOP II Factory or SILworX software environments.
Sourcing & Quality Verification
- All HIMA modules supplied by Konmask.com are sourced from authorized distribution channels or verified surplus with full traceability documentation
- Each unit undergoes incoming inspection: visual check, label verification, firmware version confirmation, and functional power-on test where applicable
- Original HIMA packaging, serial number, and date code are preserved and documented
- Certificate of conformity and test reports available upon request for SIL-critical procurement
- Lead time: In-stock units ship within 2–5 business days; special orders 4–8 weeks
Procurement Process
- Submit your RFQ via support@konmask.com or the product page inquiry form
- Receive formal quotation with unit price, lead time, and availability confirmation within 24 hours
- Issue PO referencing part number F60MI2401 and required quantity
- Payment via T/T bank transfer, PayPal, or approved credit terms for qualified accounts
- Shipment via DHL Express, FedEx, or UPS with full tracking and commercial invoice
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is the F60MI2401 compatible with HIMatrix F35 controllers?
A: Yes. The F60MI2401 is compatible with all HIMatrix backplane-based controllers including F35, F60, and HIMAX series, subject to firmware version compatibility. Consult HIMA system documentation or contact Konmask for configuration guidance.
Q: Can this module be used in SIL 3 safety loops?
A: Yes, the F60MI2401 is TÜV-certified for use in SIL 3 safety instrumented functions when deployed in the appropriate redundant architecture as specified in the HIMA safety manual.
Q: What is the difference between F60MI2401 and F60MI2402?
A: The F60MI2401 and F60MI2402 differ in channel count and input range configuration. Please contact Konmask with your application requirements for a definitive selection recommendation.
Q: Do you provide HIMA SILworX configuration files?
A: Konmask supplies hardware only. SILworX project files are customer-specific and must be developed by a qualified HIMA system integrator. We can refer you to certified HIMA partners upon request.
Q: What warranty applies?
A: Konmask provides a 12-month warranty against manufacturing defects on all supplied modules. Extended warranty and repair services are available on request.
