HIRSCHMANN MS20-1600SAAE MICE Switch Backplane | Replacement, Equivalent & Selection Guide
The HIRSCHMANN MS20-1600SAAE is a MICE (Modular Industrial Communication Equipment) switch backplane designed for high-availability industrial Ethernet networks. This page provides full technical specifications, compatible replacement options, equivalent models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: MS20-1600SAAE
- Brand / Manufacturer: HIRSCHMANN (Belden)
- Series: MICE (MS20)
- Form Factor: Modular Backplane
- Slot Capacity: Up to 16 module slots
- Interface: Industrial Ethernet (Fast Ethernet / Gigabit depending on installed modules)
- Redundancy Support: HIPER-Ring, MRP, RSTP/STP
- Power Supply: Dual redundant PSU slots
- Operating Temperature: -40°C to +70°C
- Protection Rating: IP30
- Mounting: DIN rail / rack mount
- Certifications: CE, UL, ATEX (zone 2), GL, DNV
- Weight: 880 g
- Management: Web-based, SNMP v1/v2c/v3, CLI, HiVision NMS
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the MS20-1600SAAE. Compatibility depends on your existing module inventory and network topology.
- HIRSCHMANN MS20-1600TAAE – Same backplane form factor, extended temperature variant; direct drop-in replacement in most installations.
- HIRSCHMANN MS30-1602SAAE – Next-generation MICE platform with enhanced throughput; backward-compatible with MS20 modules in most configurations.
- HIRSCHMANN MACH1040 – Higher-density managed switch for larger topologies; requires re-engineering of module layout.
- SIEMENS SCALANCE X-300 Series – Functionally equivalent managed industrial switch; requires protocol and configuration migration.
- MOXA EDS-G516E – 16-port Gigabit industrial Ethernet switch; suitable for greenfield replacements where MICE modularity is not required.
Note: Always verify firmware versions, module compatibility, and redundancy protocol support before substituting components in live systems.
Why Choose the Original Model
- Proven field reliability in harsh industrial environments (oil & gas, marine, rail, utilities).
- Modular architecture allows incremental expansion without replacing the entire switch chassis.
- Native HIPER-Ring support delivers sub-300ms network recovery — critical for real-time control systems.
- Long lifecycle support with Belden/HIRSCHMANN spare parts availability and firmware updates.
- Certified for hazardous locations (ATEX Zone 2, GL, DNV) — essential for offshore and classified-area deployments.
Typical Applications
- Industrial Ethernet backbone in process automation (DCS/SCADA networks)
- Substation automation and protection relay communication (IEC 61850)
- Marine and offshore vessel network infrastructure
- Railway trackside and rolling stock communication
- Oil & gas platform control networks
- Factory automation and machine-level Ethernet rings
System Compatibility
- Compatible DCS/PLC Platforms: Siemens S7, ABB 800xA, Emerson DeltaV, Honeywell Experion, Yokogawa CENTUM
- Compatible MICE Modules: MM2-2FXM2, MM2-2FXS2, MM4-4TX, MM4-2FXM2/2TX, and other MS20-series I/O modules
- NMS Integration: HIRSCHMANN HiVision, SNMP-based NMS (SolarWinds, PRTG, Nagios)
- Redundancy Protocols: HIPER-Ring, MRP (IEC 62439-2), RSTP (IEEE 802.1w), STP (IEEE 802.1d)
- Industrial Protocols: PROFINET, EtherNet/IP, Modbus TCP
Selection Guide
Use the criteria below to determine whether the MS20-1600SAAE is the right choice — or to identify the best alternative:
- Existing MICE module inventory? → MS20-1600SAAE or MS20-1600TAAE is the lowest-risk choice.
- Need extended temperature range (-40°C to +70°C)? → Confirm SAAE variant meets your spec; TAAE offers identical range.
- Scaling beyond 16 ports? → Evaluate MS30 series or MACH1040 for higher slot density.
- Greenfield installation without legacy modules? → MOXA EDS-G516E or SCALANCE X-300 may offer better price-performance.
- Hazardous area (ATEX Zone 2)? → MS20-1600SAAE is certified; verify equivalent certifications on any replacement.
- Budget-constrained MRO replacement? → Contact Konmask for refurbished/tested MS20-1600SAAE units with warranty.
Quality Assurance & Sourcing
- All units sourced through authorized distribution channels or verified secondary market suppliers.
- Pre-shipment functional testing available on request (power-on, port link, management access verification).
- Original packaging, documentation, and firmware media preserved where available.
- Traceability documentation (COO, batch records) provided for regulated industries.
- 12-month warranty on all stocked units; extended warranty available.
How to Order
- Step 1: Confirm part number: MS20-1600SAAE (check nameplate or existing purchase order).
- Step 2: Specify quantity and required delivery timeline.
- Step 3: Request a quote via [email protected] or call +0086 19859288691.
- Step 4: Receive proforma invoice with lead time confirmation.
- Step 5: Confirm payment and shipping method (DHL Express, FedEx, sea freight available).
Bulk orders and long-term supply agreements welcome. OEM/EPC procurement teams please inquire about framework pricing.
Replacement & Compatibility FAQ
Q: Can I use MS20-1600TAAE as a direct replacement for MS20-1600SAAE?
A: Yes. The TAAE variant shares the same backplane architecture and module compatibility. The primary difference is the temperature rating suffix — verify your environment spec before substituting.
Q: Are MS20 modules compatible with the MS30 backplane?
A: Most MS20 I/O modules are physically and electrically compatible with MS30 backplanes, but always verify with HIRSCHMANN’s compatibility matrix or contact Konmask for confirmation.
Q: Is the MS20-1600SAAE still in production?
A: The MS20 series has reached end-of-active-production but remains supported. Konmask maintains stock of new and refurbished units for MRO and lifecycle extension purposes.
Q: What is the lead time for MS20-1600SAAE?
A: In-stock units ship within 3–5 business days. For out-of-stock situations, typical lead time is 4–8 weeks depending on sourcing. Contact us for real-time availability.
Q: Can Konmask provide ATEX documentation for the MS20-1600SAAE?
A: Yes. Original ATEX certificates and EU Declaration of Conformity are available upon request for units in our inventory.
