Honeywell 2210-S211-P1F1-H111 – Thermal Magnetic Circuit Breaker | 2210 Series
The Honeywell 2210-S211-P1F1-H111 is a precision-engineered thermal magnetic circuit breaker designed for demanding industrial control panel applications. Combining thermal overload protection with instantaneous magnetic trip response, this device safeguards critical automation circuits, PLC power supplies, and motor branch circuits against both sustained overloads and short-circuit faults.
Product Positioning: Targeted at procurement engineers and panel builders requiring a compact, reliable, and UL/CE-compliant overcurrent protection device within Honeywell’s proven 2210 Series platform. Ideal for OEM control cabinets, MCC panels, and distributed I/O enclosures where space efficiency and trip accuracy are non-negotiable.
Complete Technical Specifications
| Manufacturer | Honeywell |
| Part Number / SKU | 2210-S211-P1F1-H111 |
| Series / Platform | 2210 Series |
| Device Type | Thermal Magnetic Circuit Breaker (CIR BRKR THRMMAG) |
| Number of Poles | 2-Pole |
| Trip Mechanism | Thermal (overload) + Magnetic (short-circuit) |
| Mounting Style | Panel Mount |
| Operating Voltage | Up to 250V AC / 65V DC (typical for 2210 series) |
| Interrupt Capacity | 5,000A (typical) |
| Terminal Type | Screw Terminal |
| Approvals / Certifications | UL 489, CE, RoHS |
| Operating Temperature | -25°C to +85°C |
| Enclosure / IP Rating | IP40 (panel-mounted) |
| Country of Origin | United States |
| HS Code | 8536.20.00 |
Note: Confirm exact amperage rating and voltage class from the physical nameplate or Honeywell datasheet for your specific unit. Contact Konmask.com for datasheet access.
Proven Application Environments
- PLC & DCS Power Supply Protection – Protects 24VDC/120VAC control power feeds to Siemens, Allen-Bradley, Schneider, and Honeywell DCS controllers
- Motor Control Centers (MCC) – Branch circuit protection for fractional and integral horsepower motor starters
- OEM Control Panels – Space-efficient overcurrent protection in custom-built automation enclosures
- Industrial HVAC & BMS Systems – Honeywell’s native integration in building management and HVAC control panels
- Distributed I/O Enclosures – Field panel protection for remote I/O modules and instrumentation loops
- Marine & Offshore Control Systems – Suitable for harsh environment panels with wide temperature tolerance
Engineering Advantages
- Dual-mechanism protection – Thermal bimetal element handles sustained overloads; magnetic solenoid provides instantaneous short-circuit interruption, eliminating the need for separate fuse protection
- Compact 2-pole footprint – Optimized for high-density panel layouts; reduces enclosure size and wiring complexity
- Manual reset operation – Positive trip indication and manual reset prevent automatic restart after fault, enhancing personnel safety
- Vibration-resistant design – Suitable for mobile equipment and high-vibration industrial environments
- Long mechanical life – Rated for >10,000 operations under load, reducing maintenance intervals
- UL 489 listed – Meets branch circuit protection requirements for North American installations
System Architecture & Signal Flow
In a typical PLC control panel architecture, the 2210-S211-P1F1-H111 is positioned at the branch circuit level, downstream of the main disconnect and upstream of individual load devices:
Main Disconnect (Isolator)
│
▼
Honeywell 2210-S211-P1F1-H111 ◄── Branch Circuit Protection
│
├── PLC Power Supply (24VDC)
├── I/O Module Bus
└── HMI / Operator Panel
The thermal element monitors RMS current continuously; the magnetic element responds within milliseconds to fault currents exceeding the instantaneous trip threshold (typically 10–14× rated current), ensuring upstream components and wiring are protected from thermal damage.
Sourcing & Quality Verification
- Authorized Distribution Network – Konmask.com sources Honeywell components through verified industrial distributors with full traceability
- Counterfeit Prevention – All units inspected for authentic Honeywell markings, date codes, and packaging integrity prior to shipment
- Datasheet & Certification Documents – Original Honeywell datasheets, UL certificates, and CE declarations of conformity available upon request
- Warranty – Manufacturer’s standard warranty applies; Konmask.com provides 12-month quality guarantee on all shipped units
Procurement Process
- Submit RFQ – Email support@konmask.com with quantity, required delivery date, and destination port
- Receive Quotation – Formal quotation with unit price, lead time, and shipping options within 24 business hours
- Order Confirmation – Purchase order accepted via email; proforma invoice issued for payment processing
- Quality Inspection & Shipment – Pre-shipment inspection report provided; shipped via DHL / FedEx / sea freight with full tracking
- Post-Delivery Support – Technical support and replacement assistance available throughout warranty period
Technical FAQ
Q: What is the rated current of the 2210-S211-P1F1-H111?
A: The exact amperage is encoded in the part number suffix. Please contact Konmask.com for the confirmed datasheet or submit your nameplate photo for verification.
Q: Is this breaker suitable for DC circuits?
A: Honeywell 2210 series breakers are rated for both AC and DC applications. Confirm the DC voltage rating from the product datasheet for your specific configuration.
Q: Can this replace a standard fuse in a control panel?
A: Yes. As a UL 489-listed circuit breaker, the 2210-S211-P1F1-H111 provides resettable branch circuit protection, eliminating the need for fuse replacement after a fault event.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. Contact us for urgent requirements or large quantity orders.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC and original manufacturer documentation are available upon request for all orders.
