Honeywell 900RTC-BA50 8-Channel Analog Signal Interconnect Cable – HC900 Hybrid Control Designer Series
Imagine a critical process control loop in your refinery, chemical plant, or power generation facility suddenly losing analog signal continuity. Temperature readings flatline, flow transmitters go silent, and your DCS operator is flying blind. Without the correct RTP interconnect cable, even the most sophisticated Honeywell HC900 controller becomes an expensive paperweight. The Honeywell 900RTC-BA50 is the precision-engineered solution that keeps your analog I/O channels communicating reliably between the HC900 controller rack and the Remote Termination Panel (RTP).
The 900RTC-BA50 is a 5-meter (approximately 16.4 ft), 8-channel analog RTP cable purpose-built for the Honeywell HC900 Hybrid Control Designer platform — one of the most widely deployed mid-range DCS architectures in global process industries. Within the 900 Series cable family, the BA50 designation specifies the 5m length variant for analog channel termination, making it the preferred choice for panel layouts where the controller rack and RTP are in close-to-medium proximity. Its role in the HC900 ecosystem is non-negotiable: without it, analog I/O modules cannot interface with field wiring terminations.
Technical Specifications
- Part Number: 900RTC-BA50
- Manufacturer: Honeywell Process Solutions
- Series: HC900 Hybrid Control Designer (900 Series)
- Cable Type: Analog RTP Interconnect Cable
- Channel Count: 8 Channels (Analog)
- Cable Length: 5 meters (16.4 ft)
- Weight: 1,850 g (approx.)
- Compatible Controller: Honeywell HC900 Series
- Termination Type: Remote Termination Panel (RTP)
- Application: Analog I/O signal wiring between HC900 rack and RTP
Note: All specifications are sourced from Honeywell official documentation. Do not rely on third-party data sheets for safety-critical installations.
Key Features & Benefits
- Plug-and-Play Compatibility: Factory-terminated connectors designed to mate directly with HC900 analog I/O modules and RTP blocks — zero field crimping required, reducing installation errors.
- 8-Channel Density: Consolidates eight analog signal paths into a single managed cable run, dramatically reducing panel wiring clutter and commissioning time.
- 5-Meter Reach: Provides sufficient slack for standard cabinet layouts while maintaining signal integrity across the full cable length.
- Honeywell OEM Quality: Manufactured to Honeywell’s process automation standards, ensuring EMI shielding, insulation integrity, and connector retention force meet industrial-grade requirements.
- Drop-In Replacement: Identical form, fit, and function to original factory-installed cables — critical for maintenance replacements without re-engineering.
- Reduced Downtime Risk: Pre-tested cable assemblies eliminate the risk of wiring mistakes that cause costly process shutdowns during commissioning or maintenance.
Industry & Equipment Applications
- Oil & Gas: Upstream wellhead automation, midstream pipeline monitoring, downstream refinery process control
- Chemical & Petrochemical: Reactor temperature/pressure loop wiring, batch process controllers
- Power Generation: Boiler control systems, turbine auxiliary panels using HC900 architecture
- Pulp & Paper / Food & Beverage: Continuous process lines with Honeywell HC900 DCS integration
- Water & Wastewater Treatment: SCADA-linked HC900 installations requiring reliable analog I/O termination
- Pharmaceutical Manufacturing: GMP-compliant process control panels with validated HC900 configurations
System Integration & Compatible Parts
The 900RTC-BA50 is designed to work within the broader Honeywell HC900 ecosystem. Compatible and commonly paired components include:
- Honeywell HC900 Controller Rack (C50, C70, C75 variants)
- HC900 Analog Input Modules (900A16-0101, 900AIM-0001, etc.)
- HC900 Analog Output Modules (900B08-0101, etc.)
- HC900 Remote Termination Panels (RTP) — 8-channel analog type
- 900RTC-BA25 (2.5m variant) and 900RTC-BA100 (10m variant) for alternate lengths
- HC900 Power Supply Modules and Redundancy Kits
Always verify cable length and channel type against your specific HC900 I/O module slot assignment before ordering.
Our Quality Assurance Process
At Konmask.com, every Honeywell component we supply undergoes a structured verification process:
- Source Verification: Parts are sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Visual & Physical Inspection: Connector integrity, cable jacket condition, labeling accuracy, and part number confirmation are checked upon receipt.
- Documentation Package: We provide available test reports, certificates of conformance, or original packaging documentation upon request.
- Secure Packaging: All cables are shipped in anti-static, moisture-resistant packaging to prevent transit damage.
How to Order
- Submit an Inquiry: Use the contact form or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and availability confirmation.
- Order Confirmation: Approve the proforma invoice and confirm shipping details.
- Shipment & Tracking: We arrange international freight (DHL, FedEx, UPS, or sea freight) with full tracking provided.
- After-Sales Support: Our technical team is available post-delivery for installation guidance or compatibility questions.
Why Choose Konmask.com?
- ✅ Industrial Automation Specialists: We focus exclusively on PLC, DCS, and process control components — not a generalist electronics distributor.
- ✅ Global B2B Export Experience: Serving engineering firms, system integrators, and plant maintenance teams across 30+ countries.
- ✅ Fast Inquiry Response: Dedicated account managers respond to RFQs within 24 hours.
- ✅ Flexible Shipping: Air express and sea freight options to meet urgent and budget-sensitive project timelines.
- ✅ Technical Pre-Sales Support: Our engineers help you confirm compatibility before you commit to an order.
Frequently Asked Questions
Q: What is the difference between 900RTC-BA50 and 900RTC-BA25?
A: The BA50 is 5 meters long; the BA25 is 2.5 meters. Both are 8-channel analog RTP cables for the HC900 series. Choose based on the physical distance between your controller rack and RTP in the panel.
Q: Can the 900RTC-BA50 be used with HC900 digital I/O modules?
A: No. The 900RTC-BA50 is specifically designed for analog channel termination. Digital I/O modules require the corresponding digital RTP cable variants (e.g., 900RTC-BD series).
Q: Is this cable compatible with the Honeywell HC900 C75 controller?
A: Yes, the 900RTC-BA50 is compatible with all HC900 controller variants (C50, C70, C75) when used with the appropriate analog I/O modules and RTP.
Q: Do you supply original Honeywell packaging?
A: Where available, yes. Please specify your requirement at the time of inquiry and we will confirm packaging status.
Q: What is the lead time for the 900RTC-BA50?
A: Lead time varies by stock availability. Please contact us for a real-time availability check. We maintain relationships with multiple supply channels to minimize lead times.
Q: Can you provide a certificate of conformance?
A: Yes, documentation packages including CoC and inspection reports are available upon request for most items.
{
