Honeywell CC-SDOR01 Digital Output Relay Module – Experion PKS Series
When a digital output relay module fails in a live DCS environment, the consequences cascade instantly — actuators freeze, control loops open, and entire process units can trip offline. In high-stakes industries like oil & gas, power generation, and chemical processing, even minutes of unplanned downtime translate into six-figure losses. The Honeywell CC-SDOR01 is the precision-engineered relay output module that keeps your Experion PKS control system commanding field devices with absolute reliability, eliminating that risk at the source.
The CC-SDOR01 occupies a critical position within Honeywell’s C300 Controller I/O family — the backbone of the Experion PKS platform deployed across thousands of facilities worldwide. As a Series C Smart I/O module, it delivers relay-isolated digital outputs that interface directly with solenoids, motor starters, and discrete actuators, making it one of the most widely specified DO modules in global process automation. Its proven track record in continuous-process industries has established it as a benchmark for output reliability in DCS architecture.
Technical Specifications
- Part Number: CC-SDOR01
- Module Type: Digital Output Relay (DO Relay)
- Series: Honeywell Experion PKS — Series C Smart I/O
- Output Isolation: Relay contact isolation per channel
- Form Factor: Series C I/O module, mounts on C300 I/O Link
- Communication: C300 I/O Link (FTE-based Experion network)
- Compatibility: Honeywell C300 Controller, Experion PKS R400 and above
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Certifications: CE, UL listed (refer to Honeywell datasheet for full certification list)
- Weight: Approx. 100 g
Note: All specifications are sourced from Honeywell official documentation. Contact us to verify the latest revision datasheet for your project.
Key Features & Benefits
- Relay Contact Isolation: Each output channel uses relay contacts to provide galvanic isolation, protecting the controller backplane from field-side voltage transients and inductive load kickback.
- Hot-Swap Capable: Designed for removal and insertion under power (RIUP), enabling maintenance without process shutdown — a critical advantage in continuous-operation facilities.
- Integrated Diagnostics: On-module diagnostics report channel-level faults back to the Experion PKS operator station in real time, enabling predictive maintenance before failures occur.
- Series C Smart I/O Architecture: Participates in the C300 I/O Link for deterministic, high-speed data exchange with the C300 Controller, ensuring output commands are executed within defined scan cycles.
- Compact DIN-Rail Compatible Form Factor: Optimized for high-density I/O marshalling cabinets, reducing panel footprint in brownfield and greenfield installations alike.
- Long Service Life: Built to Honeywell’s industrial-grade standards for extended MTBF in harsh plant environments.
Industry & Equipment Applications
- Oil & Gas: Wellhead control panels, pipeline valve actuation, compressor start/stop sequencing
- Petrochemical & Refining: Reactor interlock systems, pump motor starters, emergency shutdown (ESD) output interfaces
- Power Generation: Turbine auxiliary control, boiler burner management, switchgear control
- Pulp & Paper: Conveyor drive control, valve sequencing, process interlock outputs
- Pharmaceutical & Life Sciences: Batch process control, clean-room HVAC actuator control, CIP/SIP valve outputs
- Water & Wastewater: Pump station control, dosing system outputs, SCADA-integrated valve control
System Integration & Compatible Parts
The CC-SDOR01 is designed to integrate seamlessly within the Honeywell Experion PKS ecosystem. Compatible and commonly paired components include:
- C300 Controller: CC-PCF901 / CC-PCF902 — the host controller for Series C I/O modules
- I/O Link Extender: CC-LINK01 — extends the C300 I/O Link for remote I/O cabinets
- Digital Input Modules: CC-SDIL01 — for paired DI/DO loop architectures
- Analog Output Modules: CC-TAOX11 / CC-PAOX01 — for mixed I/O marshalling
- Power Supply: CC-PWR001 / CC-PWR002 — Series C I/O power supply modules
- FTE Network Switch: Cisco IE series switches qualified for Experion PKS FTE networks
Our team can assist with full BOM verification to ensure cross-revision compatibility before shipment.
Our Quality Assurance Process
At Konmask.com, every Honeywell CC-SDOR01 unit undergoes a rigorous multi-stage inspection before dispatch:
- Visual Inspection: Examination of PCB, connectors, and housing for physical damage, corrosion, or counterfeit indicators
- Label & Traceability Verification: Part number, revision, and serial number cross-checked against Honeywell’s published documentation
- Functional Pre-Check: Where test equipment is available, modules are powered and LED status indicators verified
- Anti-Static Packaging: All modules shipped in ESD-safe bags with foam cushioning inside double-wall cartons
- Documentation Package: Certificate of conformance and inspection report available upon request
How to Order
- Click “Request a Quote” or contact us directly via email or WhatsApp
- Provide your required quantity, delivery timeline, and destination country
- Our team will confirm availability, lead time, and issue a formal quotation within 24 hours
- Upon PO confirmation, we arrange inspection, packaging, and export documentation
- Shipment via DHL / FedEx / UPS Express or sea freight — your choice
For urgent requirements or large-volume orders, please contact us directly for priority handling.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Parts: PLC, DCS, servo drives, HMI — we speak the language of your engineering team
- ✅ Global Export Experience: Serving clients in 40+ countries with compliant export documentation
- ✅ Fast Response: Quotations within 24 hours, technical support from engineers — not sales scripts
- ✅ Authentic Parts Only: We do not deal in counterfeits; every unit is inspected and traceable
- ✅ Flexible MOQ: Single-unit orders accepted — no minimum order quantity for most items
- ✅ Secure Payment: T/T, PayPal, and other B2B payment methods accepted
Frequently Asked Questions
Q: Is the Honeywell CC-SDOR01 in stock?
A: Stock levels vary. Please contact us for real-time availability. We maintain relationships with multiple verified suppliers to source units quickly even when not in immediate stock.
Q: What is the difference between CC-SDOR01 and other Honeywell DO modules?
A: The CC-SDOR01 specifically provides relay contact outputs, offering galvanic isolation ideal for switching inductive loads. Other DO modules in the Series C family may use transistor (solid-state) outputs suited for different load types. Consult your I/O design specification to confirm the correct module type.
Q: Can this module be used with Honeywell TDC 3000?
A: No. The CC-SDOR01 is a Series C Smart I/O module designed exclusively for the Experion PKS C300 Controller platform. TDC 3000 uses a different I/O architecture (HPM/LCN). Please contact us if you need TDC 3000 compatible modules.
Q: Do you provide a warranty?
A: Yes. We offer a standard 90-day warranty against defects in materials and workmanship. Extended warranty options are available — please inquire at the time of order.
Q: Can you provide export documentation for customs clearance?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and other documents required for international customs clearance upon request.
