Honeywell EM9118B2-6 – 6-Channel Analog Input Module | Experion PKS / TDC 3000 Platform
Engineering Background
The Honeywell EM9118B2-6 is a high-density analog input module engineered for Honeywell’s Distributed Control System (DCS) architecture. Designed to interface directly with field transmitters, it delivers precision signal conditioning and digitization for process variables including temperature, pressure, flow, and level across demanding industrial environments.
Product Positioning
Targeted at process automation engineers requiring reliable, OEM-grade analog front-end hardware for Honeywell Experion PKS, TDC 3000, or compatible control networks. The EM9118B2-6 is a direct-replacement module suitable for both greenfield installations and brownfield upgrades where signal integrity and system compatibility are non-negotiable.
Complete Technical Specifications
- Part Number: EM9118B2-6
- Manufacturer: Honeywell Process Solutions
- Module Type: Analog Input (AI)
- Number of Channels: 6
- Signal Types Supported: 4–20 mA, 0–10 V DC, thermocouple, RTD (configuration-dependent)
- Resolution: 16-bit A/D conversion
- Input Impedance: High-impedance differential inputs
- Isolation: Channel-to-channel and channel-to-bus isolation
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Power Consumption: Per DCS backplane specification
- Weight: 350 g
- HS Code: 853710
- Country of Origin: United States
- Compliance: CE, UL, RoHS (verify with datasheet for specific revision)
Proven Application Environments
- Oil & gas upstream/downstream process control
- Petrochemical and refinery DCS loops
- Power generation plant instrumentation
- Pharmaceutical batch process monitoring
- Pulp & paper continuous process control
- Water treatment and municipal utility SCADA integration
Engineering Advantages
- High-density I/O: 6 analog channels per module slot reduces rack space and wiring complexity
- Precision digitization: 16-bit resolution ensures accurate representation of field signals across the full dynamic range
- Galvanic isolation: Protects controller backplane from field-side transients and ground loops
- Hot-swap compatibility: Supports live insertion/removal in redundant DCS configurations (verify with system integrator)
- OEM firmware: Factory-loaded firmware ensures full compatibility with Honeywell configuration tools (Control Builder, Station)
- Long service life: Designed to Honeywell’s industrial-grade MTBF standards for 24/7 continuous operation
System Architecture & Signal Flow
Field transmitters connect to the EM9118B2-6 terminal block via shielded twisted-pair wiring. Each channel passes through an input protection circuit, then to a multiplexed A/D converter stage. Digitized values are transferred over the DCS backplane bus to the controller module (e.g., C200, C300, or equivalent) for real-time processing. The module supports HART pass-through on current-loop channels where applicable, enabling asset management without additional hardware.
Sourcing & Quality Verification
- Source: Verified surplus and authorized distribution channels
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check prior to shipment
- Authenticity: Konmask.com sources exclusively from traceable supply chains; counterfeit-risk screening applied
- Condition: New surplus or refurbished-to-spec; condition stated explicitly on order confirmation
- Warranty: 12-month replacement warranty against manufacturing defects
Procurement Process
- Submit RFQ via Konmask.com product page or email support@konmask.com
- Receive availability confirmation and lead-time quote within 24 business hours
- Review and approve proforma invoice
- Payment via T/T, PayPal, or approved credit terms
- Shipment via DHL / FedEx / UPS with full tracking; export documentation included
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is the EM9118B2-6 compatible with Experion PKS R500 and later?
A: Compatibility depends on firmware revision and system configuration. Contact our engineering team with your system version for confirmation.
Q: Can this module replace an EM9118B2-4 (4-channel variant)?
A: The 6-channel variant occupies the same slot form factor but has different channel count. Verify backplane addressing and I/O builder configuration before substitution.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. CoC and inspection report are available upon request for all orders.
Q: What is the lead time for stock orders?
A: In-stock units ship within 2–5 business days. Out-of-stock items: 4–8 weeks typical sourcing lead time.
Q: Can HART communication be used through this module?
A: HART pass-through is supported on 4–20 mA channels when the host DCS controller and configuration software support HART multiplexing.
