Honeywell FS-TIDI-1624 – 24-Channel Safe Digital Input Module | Safety Manager SC Platform
Engineering Background
The Honeywell FS-TIDI-1624 is a certified safe digital input module engineered for deployment within Honeywell’s Safety Manager SC (SMSC) safety instrumented system platform. Designed to meet the rigorous demands of process safety applications, this module provides 24 channels of isolated digital input acquisition with hardware-enforced diagnostics, making it a cornerstone component in SIL 2 and SIL 3 safety loops across oil & gas, petrochemical, power generation, and chemical processing industries.
Product Positioning
As a procurement engineer sourcing safety-critical I/O, the FS-TIDI-1624 delivers the combination of IEC 61508-certified architecture, proven field reliability, and seamless integration with the Safety Manager SC controller that reduces validation overhead and accelerates SIS commissioning timelines. Konmask.com supplies this module as new, surplus-new, and refurbished-tested stock with full traceability documentation.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number / SKU | FS-TIDI-1624 |
| Manufacturer | Honeywell Process Solutions |
| Product Series | Safety Manager SC (SMSC) |
| Module Type | Safe Digital Input (TIDI) |
| Number of Channels | 24 channels |
| Input Voltage Range | 24 V DC (nominal) |
| Input Signal Type | Discrete / Digital (dry contact or voltage) |
| Safety Integrity Level | SIL 2 (single module) / SIL 3 (redundant configuration) |
| Safety Standard | IEC 61508, IEC 61511 |
| Diagnostic Coverage | High (internal self-diagnostics per IEC 61508) |
| Channel Isolation | Galvanic isolation per channel group |
| Communication Interface | Safety Manager SC backplane bus |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5% to 95% RH, non-condensing |
| Power Consumption | Per SMSC system power budget |
| Form Factor | Plug-in module, SMSC chassis-mounted |
| Weight | Approx. 300 g |
| Country of Origin | USA / Honeywell certified manufacturing |
| Certifications | TÜV, FM, ATEX (consult datasheet for full listing) |
Proven Application Environments
- Oil & Gas: Emergency Shutdown (ESD) systems, High Integrity Pressure Protection Systems (HIPPS), wellhead control panels
- Petrochemical & Refining: Burner Management Systems (BMS), reactor safety interlocks, compressor protection
- Power Generation: Turbine trip systems, boiler safety loops, generator protection
- Chemical Processing: Toxic gas detection interlocks, pressure relief monitoring, batch reactor safety
- LNG & Terminals: Loading arm interlocks, cryogenic process safety, fire & gas integration
- Offshore Platforms: Topsides ESD, subsea control integration, FPSO safety systems
Engineering Advantages
- SIL 2/3 Certified Architecture: Hardware and firmware co-designed to IEC 61508 Part 2 & 3, eliminating the need for external safety relays on most input loops
- 24-Channel Density: High channel count per module slot reduces chassis footprint and wiring complexity in large SIS cabinets
- Integrated Diagnostics: Continuous self-test routines detect open-circuit, short-circuit, and stuck-at faults without process interruption
- Seamless SMSC Integration: Native backplane communication with Safety Manager SC controller eliminates gateway latency and simplifies safety function configuration in Safety Builder engineering tool
- Hot-Swap Capability: Supports module replacement under power in redundant configurations, maximizing system availability
- Proven Field Record: Deployed globally in thousands of SIS installations across major EPC contractors and end-user facilities
System Architecture & Signal Flow
The FS-TIDI-1624 resides in the Safety Manager SC I/O chassis and communicates via the proprietary SMSC safety backplane to the SM SC controller. Field wiring connects to the module’s terminal block (or marshalling panel via cable assembly). Each input channel passes through:
- Field Terminal → Galvanic isolation barrier
- Signal conditioning & filtering → Analog-to-digital conversion
- Diagnostic engine (open/short/stuck-at detection)
- Safety backplane → SM SC controller safety logic execution
- Safety function output → Final element actuation
The module supports 1oo1, 1oo2, and 2oo3 voting architectures as configured in the Safety Manager SC application logic, enabling flexible SIL achievement strategies.
Sourcing & Quality Verification
- Stock Condition: New, Surplus-New (OEM packaging), and Refurbished-Tested available — specify at inquiry
- Traceability: Serial number, manufacturing date code, and firmware revision documented per shipment
- Testing Protocol: All refurbished units undergo functional power-on test, channel-by-channel I/O verification, and diagnostic self-test confirmation before dispatch
- Authenticity: Sourced from authorized distribution channels and verified OEM surplus; counterfeit screening applied to all incoming stock
- Warranty: 12-month replacement warranty on all stock grades; extended warranty available on request
- Export Compliance: EAR99 / ECCN classification confirmed; export license assessment provided for controlled-destination orders
Procurement Process
- Submit RFQ — Email support@konmask.com with quantity, required condition grade, and delivery timeline
- Receive Quote — Pricing, lead time, and stock condition confirmed within 24 business hours
- Purchase Order — Issue PO against confirmed quote; proforma invoice issued for prepayment orders
- Quality Inspection — Pre-shipment inspection report and photos provided upon request
- Shipment — DHL / FedEx / UPS express with full tracking; EXW Xiamen or CIF destination available
- After-Sales Support — Technical datasheet, wiring diagrams, and firmware compatibility guidance provided post-delivery
