AB 1794-IM8 Flex 16-Point Digital Input Module | FLEX I/O Series

Allen-Bradley 1794-IM8 16-Point Digital Input Module – FLEX I/O Series

When a digital input module fails on the plant floor, the consequences are immediate and severe: PLCs lose visibility into field device states, safety interlocks go blind, and entire production lines grind to a halt. Operators are left guessing whether a conveyor has stopped, a valve has closed, or a sensor has tripped — decisions that once took milliseconds now require manual intervention, costing thousands of dollars per hour in downtime. The Allen-Bradley 1794-IM8 exists precisely to prevent this scenario, delivering rock-solid 16-point digital input acquisition that keeps your control system fully informed at all times.

Within the FLEX I/O platform — Rockwell Automation’s modular, distributed I/O architecture designed for space-constrained and remote-panel applications — the 1794-IM8 occupies a critical role as a high-density discrete input module. Its 16-channel capacity in a compact FLEX form factor makes it the preferred choice for machine builders and system integrators worldwide who need to maximize I/O density without sacrificing reliability. Deployed across automotive assembly, food & beverage processing, water treatment, and semiconductor fabrication, the 1794-IM8 is one of the most widely specified FLEX I/O modules in global industrial automation.

Technical Specifications

• Catalog Number: 1794-IM8
• Series: Allen-Bradley FLEX I/O
• Number of Inputs: 16 points (8 per group, 2 groups)
• Input Voltage: 10–30V DC (24V DC nominal)
• Input Current: 2–15 mA per point
• ON-State Voltage: 10–30V DC minimum
• OFF-State Voltage: 0–5V DC maximum
• Input Impedance: 2.4 kΩ
• Response Time: 1 ms (hardware filter)
• Isolation: 500V AC optical isolation between field and backplane
• Backplane Current: 75 mA @ 5V DC
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5–95% non-condensing
• Dimensions (H × W × D): 94 × 23 × 87 mm
• Weight: Approx. 100 g
• Certifications: UL, CE, CSA, C-Tick
• Standards Compliance: IEC 61131-2 Type 1 & Type 3

Note: Specifications are based on published Rockwell Automation documentation. Always verify against the official product datasheet for your specific revision.

Key Features & Benefits

• 16 Discrete Inputs in a Compact Module: Maximizes I/O density in FLEX I/O racks, reducing panel space and wiring costs.
• Optical Isolation: 500V AC isolation protects the backplane and controller from field-side voltage transients and noise.
• IEC 61131-2 Compliant: Accepts a wide range of standard 24V DC field devices including proximity sensors, push buttons, and limit switches.
• Dual-Group Architecture: Two independent 8-point groups allow separate field power supplies, simplifying zone isolation and maintenance.
• LED Status Indicators: Per-point LEDs provide instant visual diagnostics without requiring a laptop or software connection.
• Hot-Swap Capable: Modules can be replaced under power (with appropriate adapter), minimizing maintenance downtime.
• Wide Operating Temperature Range: Suitable for harsh industrial environments from 0°C to 55°C.
• Broad Compatibility: Works with all FLEX I/O adapter modules including 1794-AENT, 1794-ACN15, and 1794-ADNK.

Industry & Equipment Applications

• Automotive Manufacturing: Body-in-white welding lines, transfer press monitoring, end-of-line test stations
• Food & Beverage: Conveyor position sensing, filling machine interlocks, CIP system status monitoring
• Water & Wastewater Treatment: Pump run/fault status, valve position feedback, level switch inputs
• Pharmaceutical: Clean-room equipment interlocks, batch process event capture, safety door monitoring
• Semiconductor Fabrication: Tool status monitoring, handler position sensing, cleanroom HVAC control
• Material Handling: Sorter divert confirmation, pallet presence detection, conveyor jam detection
• Oil & Gas: Remote wellhead monitoring, pipeline valve status, compressor station I/O

System Integration & Compatible Parts

The 1794-IM8 is designed to integrate seamlessly within the FLEX I/O ecosystem. Common compatible components include:

• Adapter Modules: 1794-AENT (EtherNet/IP), 1794-ACN15 (ControlNet), 1794-ADNK (DeviceNet), 1794-ASB (Remote I/O)
• Power Supplies: 1794-PS13, 1794-PS3
• Terminal Bases: 1794-TB3, 1794-TB3S, 1794-TB32
• Controllers: ControlLogix (1756 series), CompactLogix (1769 series), MicroLogix 1500
• Programming Software: Studio 5000 Logix Designer, RSLogix 5000

If you need assistance selecting compatible adapters, terminal bases, or controllers for your application, our engineering team is available to support your system design.

Our Quality Assurance Process

At Konmask.com, every Allen-Bradley 1794-IM8 module we supply undergoes a rigorous multi-stage quality process before shipment:

• Source Verification: Modules are sourced exclusively from authorized distributors, certified resellers, or verified surplus channels with documented provenance.
• Visual Inspection: Each unit is inspected for physical damage, label authenticity, and correct revision markings.
• Functional Testing: Where applicable, modules are bench-tested to confirm backplane communication and I/O point functionality.
• Anti-Counterfeit Screening: We apply industry-standard counterfeit detection protocols including hologram verification and component-level inspection.
• Secure Packaging: Units are shipped in ESD-safe packaging with desiccant to prevent moisture damage during transit.

How to Order

1. Submit an inquiry via our website contact form or email support@konmask.com
2. Provide your required quantity, delivery timeline, and destination country
3. Receive a formal quotation within 1 business day
4. Confirm order and complete payment via T/T, PayPal, or other agreed method
5. Receive shipping confirmation with tracking number within 2–5 business days

For urgent requirements or large-volume orders, please call us directly at +0086 19859288691.

Why Choose Konmask.com?

• ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
• ✅ Global Sourcing Network: Access to both new and certified surplus Allen-Bradley inventory from verified global suppliers.
• ✅ Technical Expertise: Our team includes experienced automation engineers who can advise on compatibility and system integration.
• ✅ Fast Response: Quotations within 24 hours, with expedited shipping options for critical downtime situations.
• ✅ Transparent Documentation: Full traceability documentation available upon request, including test reports and certificates of conformance.
• ✅ After-Sales Support: We stand behind every shipment with responsive post-sale technical and logistics support.

Frequently Asked Questions

Q: Is the 1794-IM8 compatible with EtherNet/IP networks?
A: Yes, when paired with the 1794-AENT EtherNet/IP adapter module, the 1794-IM8 can be accessed over EtherNet/IP networks and programmed via Studio 5000 Logix Designer.

Q: Can the 1794-IM8 be used with ControlLogix and CompactLogix controllers?
A: Yes. The 1794-IM8 is fully compatible with ControlLogix (1756 series) and CompactLogix (1769 series) controllers via the appropriate FLEX I/O adapter.

Q: Do you supply new or refurbished units?
A: We supply both new (factory-sealed) and certified surplus (tested, fully functional) units. Please specify your preference when requesting a quotation.

Q: What is the lead time for the 1794-IM8?
A: Lead time depends on current stock levels. In-stock units typically ship within 2–5 business days. Contact us for real-time availability.

Q: Can you provide a certificate of conformance or test report?
A: Yes. Documentation including inspection reports and certificates of conformance is available upon request for all orders.

Q: What is the difference between the 1794-IM8 and 1794-IM16?
A: The 1794-IM8 provides 16 input points in a standard FLEX I/O module width, while the 1794-IM16 is a different catalog number. Please verify your exact requirements with our team before ordering.

---
