Process Automation Solution – Honeywell TC-SDRX01 | C300 DCS Series
The Honeywell TC-SDRX01 is a high-density Digital Input Module engineered for the Experion PKS C300 Distributed Control System. Designed for mission-critical process environments, it delivers reliable discrete signal acquisition across power generation, oil & gas, chemical, and advanced manufacturing facilities.
Where This Product Is Used
- Oil & Gas Processing: Monitoring valve open/close status, pump run/stop feedback, and emergency shutdown (ESD) logic inputs at upstream and downstream facilities.
- Power Generation: Capturing turbine trip signals, breaker status, and interlock feedback in combined-cycle and coal-fired power plants.
- Chemical & Petrochemical Plants: Integrating discrete field device status into DCS logic for reactor control, compressor sequencing, and safety instrumented systems (SIS).
- Pulp & Paper / Water Treatment: Acquiring motor run feedback, level switch inputs, and flow switch signals for continuous process monitoring.
- Pharmaceutical Manufacturing: Supporting FDA-compliant batch process control with validated discrete I/O in cleanroom environments.
Technical Specifications
- Part Number: TC-SDRX01
- Module Type: Digital Input (DI)
- Compatible Platform: Honeywell Experion PKS — C300 Controller Series
- Series: TotalPlant Solution (TPS) / Experion PKS
- Input Channels: 32 discrete input channels
- Input Voltage: 24 VDC (nominal)
- Signal Type: Dry contact / wet contact discrete inputs
- Communication: FTE (Fault Tolerant Ethernet) backplane interface
- Isolation: Optical isolation per channel group
- Diagnostics: Online self-diagnostics with fault reporting to Experion Station
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Weight: 1.6 kg
- Certifications: CE, UL, FM (Class I, Div 2)
Why Engineers Specify This Model
- Native C300 Integration: Plug-and-play compatibility with the C300 controller chassis eliminates custom configuration and reduces commissioning time.
- High Channel Density: 32 DI channels per module minimizes cabinet footprint and reduces total installed cost in large-scale DCS architectures.
- Fault-Tolerant Design: Supports redundant FTE network paths, ensuring continuous data acquisition even during network segment failures.
- Online Diagnostics: Real-time channel-level fault detection reduces mean time to repair (MTTR) and supports predictive maintenance strategies.
- Proven Field Reliability: Widely deployed across global Honeywell Experion PKS installations with documented multi-decade service life.
Complete System Bill of Materials
For a complete C300 DCS digital input subsystem, engineers typically specify:
- TC-SDRX01 — Digital Input Module (this item)
- TC-CCR014 / TC-CCR016 — C300 Controller Module
- TC-FPCXX — FIM (Field Interface Module) as applicable
- TC-PRS021 / TC-PRS023 — Power Supply Module
- TC-FTEB01 — FTE Bridge Module
- Appropriate I/O termination assembly (ITA) for field wiring
Compliance & Industry Standards
- IEC 61131-2: Programmable Controllers — Equipment Requirements and Tests
- IEC 61508 / IEC 61511: Functional Safety (SIL-capable system architecture)
- ATEX / FM Class I Division 2 (when used with approved barriers)
- CE Marking — EMC Directive 2014/30/EU
- UL Listed for industrial control equipment
- RoHS Compliant
Quality Assurance & Sourcing
Every TC-SDRX01 unit offered by Konmask.com undergoes a structured verification process:
- Visual inspection against Honeywell OEM physical standards (label, PCB revision, connector integrity)
- Functional power-on verification where applicable
- Traceability documentation available upon request
- Sourced from authorized distribution channels and verified surplus inventories
- Packaged with ESD-safe materials and shipped with protective foam inserts
How to Source This Part
Konmask.com maintains ready stock of the Honeywell TC-SDRX01 for immediate dispatch. For volume orders, project-based procurement, or expedited delivery requirements:
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Web: https://konmask.com
- Lead time: In-stock units ship within 1–3 business days; project quantities quoted within 24 hours.
Application-Specific FAQ
Q: Is the TC-SDRX01 compatible with Honeywell Experion PKS R500 and later?
A: Yes. The TC-SDRX01 is compatible with Experion PKS R400 through current releases when used with a C300 controller chassis. Confirm firmware revision compatibility with your site’s Experion version before installation.
Q: Can this module be hot-swapped during plant operation?
A: The C300 platform supports online module replacement (hot-swap) when the system is configured for redundancy. Consult your Honeywell system integrator for site-specific procedures.
Q: What is the difference between TC-SDRX01 and TC-SDRX11?
A: The TC-SDRX01 is the standard 32-channel DI module; the TC-SDRX11 variant includes enhanced diagnostics and extended temperature ratings. Verify your project specification before ordering.
Q: Do you provide a warranty or return policy?
A: Yes. Konmask.com offers a 90-day functional warranty on all modules. Contact support@konmask.com for warranty claims or pre-purchase technical consultation.
