Motion Control Solution – INFRANOR MSM0606 Servo Drive Board | XtrapulsPac Series
Where This Product Is Used
The INFRANOR MSM0606 Servo Drive Board is a precision servo amplifier module engineered for demanding industrial motion control environments. Typical deployment scenarios include:
- CNC Machining Centers – Axis interpolation and spindle torque regulation in multi-axis milling and turning machines
- Industrial Robotics – Joint-level servo control in articulated arms and SCARA robots requiring sub-millisecond response
- Automated Assembly Lines – Pick-and-place, press-fit, and conveyor indexing systems where position repeatability is critical
- Semiconductor & Electronics Manufacturing – Wafer handling, PCB drilling, and SMT placement equipment
- Packaging Machinery – High-speed cam-profile motion in form-fill-seal and cartoning lines
- Medical & Laboratory Automation – Precision dosing pumps, imaging stages, and diagnostic instrument drives
Technical Specifications
- Part Number / SKU: MSM0606
- Manufacturer: INFRANOR GMBH (Switzerland)
- Product Series: XtrapulsPac / MSM Drive Series
- Module Type: AC Servo Drive Board (Amplifier PCB)
- Weight: 2,130 g (approx.)
- Form Factor: Board-level module for rack or panel integration
- Compatible Motors: INFRANOR AC brushless servo motors (SMH, SMA series)
- Communication Interface: CANopen / proprietary INFRANOR bus (model-dependent)
- Protection Class: Short-circuit, over-temperature, over-voltage, under-voltage
- Country of Origin: Germany / Switzerland
Why Engineers Specify This Model
- Drop-in Replacement Compatibility – MSM0606 maintains pin and firmware compatibility within the MSM drive family, minimizing retrofit engineering time
- High Dynamic Response – Current loop bandwidth optimized for tight velocity and position loops in multi-axis coordinated motion
- Robust EMC Design – Shielded PCB layout and integrated filtering reduce radiated emissions in noise-sensitive factory environments
- Proven Field Reliability – Widely deployed in European OEM machine tools since the 1990s; extensive installed base with documented MTBF data
- Compact Board Format – Enables dense drive cabinet layouts without sacrificing thermal headroom
Complete System Bill of Materials
For a fully operational servo axis using the MSM0606, engineers typically specify:
- INFRANOR MSM0606 Servo Drive Board (this item)
- INFRANOR SMH / SMA Series AC Brushless Servo Motor
- Feedback encoder cable (resolver or incremental encoder, shielded)
- DC bus capacitor bank or AC power supply module
- CANopen master controller or motion controller (e.g., Beckhoff, Siemens)
- 24 VDC logic power supply
- Safety relay / STO (Safe Torque Off) module per IEC 62061
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) 2014/35/EU
- EMC Directive 2014/30/EU
- RoHS 2 Compliant (Directive 2011/65/EU)
- IEC 61800-3 (Adjustable Speed Electrical Power Drive Systems – EMC)
- IEC 61800-5-1 (Safety requirements for power drive systems)
- UL recognition applicable to OEM integration (verify with local authority)
Quality Assurance & Sourcing
Konmask.com sources the INFRANOR MSM0606 through verified industrial surplus and authorized distribution channels. Every unit undergoes:
- Visual inspection for PCB damage, burnt components, and connector integrity
- Label and serial number verification against INFRANOR manufacturing records
- Functional power-on test where test fixtures are available
- Anti-static packaging with humidity indicator card
- Photographic documentation of actual shipped unit available on request
We do not sell counterfeit, remarked, or reconditioned parts represented as new without explicit disclosure.
How to Source This Part
To place an order or request a quote for the INFRANOR MSM0606 Servo Drive Board:
- Online: Add to cart directly at Konmask.com
- Email RFQ: support@konmask.com – include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; sourcing orders typically 7–21 days
- Export: We ship worldwide with DHL, FedEx, and UPS Express; export documentation (commercial invoice, packing list, COO) provided
Application-Specific FAQ
Q: Is the MSM0606 compatible with third-party servo motors?
A: The MSM0606 is optimized for INFRANOR SMH/SMA motors. Use with third-party motors requires careful commutation and feedback parameter matching; consult our technical team before ordering.
Q: Can this board be repaired if a power stage component fails?
A: Board-level repair is possible by qualified servo drive technicians. Common failure modes (IGBT, gate driver IC, capacitor) are serviceable. Contact us for repair referrals.
Q: Do you provide the MSM0606 firmware or configuration software?
A: INFRANOR’s XtraWin or WinDrive configuration software is required. We can assist with software sourcing; firmware is typically stored in on-board EEPROM and transfers with the board.
Q: What warranty applies?
A: Konmask.com offers a 90-day functional warranty on all tested units. Warranty covers failure under normal operating conditions and excludes physical damage after receipt.
Q: Can you supply multiple units for a production line retrofit?
A: Yes. Contact us with your BOM quantity and timeline. Volume pricing is available for orders of 3+ units.
