Safety Instrumented System Solution – INVENSYS TRICONEX 2658 | Tricon Series
Where This Product Is Used
The INVENSYS TRICONEX 2658 External Terminator is a critical passive component deployed in Tricon Triple Modular Redundant (TMR) Safety Instrumented Systems (SIS). It is specified by process safety engineers across the following industries and applications:
- Oil & Gas – Upstream & Downstream: Emergency Shutdown (ESD) systems on wellheads, compressor stations, and pipeline SCADA nodes where field I/O cables require proper bus termination to prevent signal reflection.
- Petrochemical & Refining: High-integrity pressure protection systems (HIPPS) and burner management systems (BMS) where Tricon chassis backplane communication integrity is mandatory.
- LNG & Gas Processing Plants: Fire & Gas (F&G) detection panels interfaced with Tricon controllers, requiring terminated I/O field wiring for noise immunity.
- Nuclear & Power Generation: Safety-critical control loops where IEC 61511 / IEC 61508 compliance demands verified termination on all field signal cables.
- Chemical & Specialty Manufacturing: Reactor safety interlocks and process shutdown systems using Tricon I/O modules with external field termination assemblies.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 2658 |
| Manufacturer | INVENSYS TRICONEX (now Schneider Electric) |
| Product Family | Tricon TMR Safety System |
| Module Type | External Terminator / Field Termination Assembly |
| Compatible Chassis | Tricon v9 / v10 / v11 Main Chassis & Expansion Chassis |
| Compatible I/O Modules | Tricon Digital Input, Digital Output, Analog Input, Analog Output modules (series-dependent) |
| Termination Style | External plug-in terminator panel |
| Weight | 300 g (approx.) |
| Operating Temperature | 0°C to +60°C (storage: -40°C to +85°C) |
| Mounting | Direct plug-in to Tricon I/O module field connector |
| RoHS Compliance | Refer to manufacturer datasheet |
Why Engineers Specify This Model
- Signal Integrity: Eliminates bus reflections on Tricon field I/O wiring, ensuring clean digital and analog signal transmission in electrically noisy plant environments.
- TMR Architecture Compatibility: Designed specifically for Tricon’s triple-redundant backplane — no generic terminator can substitute without risking SIL degradation.
- Plug-and-Play Replacement: Direct OEM form-factor replacement; no rewiring of field cables required during maintenance or module swap.
- Reduced Commissioning Risk: Pre-wired termination eliminates field wiring errors during initial system commissioning or I/O module replacement.
- Long Service Life: Passive component design with no active electronics — minimal failure modes, suitable for 10+ year SIS lifecycle deployments.
- OEM Traceability: Sourced with full part number traceability to INVENSYS / Schneider Electric manufacturing records.
Complete System Bill of Materials
The TRICONEX 2658 External Terminator is typically specified alongside the following Tricon system components:
- Tricon Main Chassis (e.g., 8310, 8311)
- Tricon Communication Module (e.g., 4351A, 4352A)
- Tricon Digital Input Module (e.g., 3501E, 3503E)
- Tricon Digital Output Module (e.g., 3601E, 3603E)
- Tricon Analog Input Module (e.g., 3700A, 3703E)
- Tricon Power Supply Module (e.g., 8312, 8110)
- Tricon Field Termination Assembly (FTA) cables
- TRICONEX 2658 External Terminator (this item)
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- IEC 61511: Functional Safety – Safety Instrumented Systems for the Process Industry Sector
- IEC 61508: Functional Safety of E/E/PE Safety-related Systems
- SIL 3 Capable Architecture: Tricon TMR platform is certified for use in SIL 3 safety loops; proper termination is a prerequisite for maintaining SIL integrity
- ATEX / IECEx: Consult project-specific hazardous area classification requirements
- ISA-84: Application of Safety Instrumented Systems for the Process Industries
Quality Assurance & Sourcing
At Konmask.com, every TRICONEX component undergoes a structured quality verification process before dispatch:
- ✅ Visual Inspection: Connector pins, housing, and label integrity checked against OEM reference
- ✅ Part Number Verification: Cross-referenced against INVENSYS / Schneider Electric part databases
- ✅ Functional Pre-check: Passive continuity and resistance verification where applicable
- ✅ Secure Packaging: ESD-safe anti-static packaging with desiccant for long-distance shipping
- ✅ Documentation: Certificate of conformance and packing list included with every shipment
We source from authorized distributors, decommissioned plant inventories with full traceability, and certified refurbishment partners. Counterfeit-free guarantee.
How to Source This Part
- Add to Cart directly on this page for standard lead times.
- Request a Quote for volume orders (5+ units) or urgent AOG/shutdown requirements — email support@konmask.com.
- Provide your BOM if you need multiple Tricon components — we offer consolidated sourcing and single-shipment delivery.
- Expedited Shipping available for plant shutdown and turnaround (TAR) scenarios — contact us with your required delivery date.
- Export Documentation: We support international buyers with commercial invoices, packing lists, and HS code declarations for customs clearance.
Application-Specific FAQ
Q: Is the TRICONEX 2658 compatible with all Tricon chassis versions?
A: The 2658 is designed for the Tricon platform. Compatibility depends on the specific I/O module and chassis generation (v9/v10/v11). Please confirm your chassis model number when ordering.
Q: Can I use a generic terminator instead of the OEM 2658?
A: Not recommended for SIS applications. Using non-OEM terminators may void your SIL certification and introduce signal integrity risks. Always specify OEM parts for safety-critical loops.
Q: What is the lead time for the TRICONEX 2658?
A: In-stock units ship within 1–3 business days. For out-of-stock scenarios, typical sourcing lead time is 2–4 weeks. Contact us for real-time availability.
Q: Do you provide a warranty?
A: Yes. All components carry a 12-month warranty against manufacturing defects. Refurbished units are covered under a 6-month warranty with full test documentation.
Q: Can you supply the full Tricon system or just individual modules?
A: Both. Konmask.com specializes in both individual spare parts and complete Tricon system assemblies. Submit your BOM to support@konmask.com for a consolidated quote.
Q: Do you ship internationally?
A: Yes. We ship globally with DHL, FedEx, and UPS Express. Export documentation and customs support included.
