JDS UNIPHASE 2214-30SLQTA Argon Laser Head | Single Line 514nm Replacement, Equivalent & Selection Guide
The JDS UNIPHASE 2214-30SLQTA is a high-performance argon-ion laser head designed for single-line operation, delivering stable 514 nm (green) output. Widely used in scientific research, flow cytometry, holography, and precision measurement, this model is recognized for its reliability and long service life. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Model / SKU: 2214-30SLQTA
- Brand: JDS UNIPHASE (JDSU)
- Series: 2214 Single-Line Argon Laser Series
- Laser Type: Argon-Ion (Ar+)
- Output Mode: Single Line (514.5 nm)
- Output Power: ~30 mW (nominal)
- Beam Mode: TEM₀₀
- Polarization: Linear, vertical (>100:1)
- Beam Diameter: ~0.7 mm (1/e²)
- Beam Divergence: <1.2 mrad (full angle)
- Warm-up Time: ~20 minutes to rated power
- Operating Voltage: Per matched power supply specification
- Cooling: Air-cooled (fan integrated)
- Weight: ~3.66 kg
- Connector: Compatible with JDSU 2200-series power supplies
- Compliance: CE, FDA Class IIIb
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the JDS UNIPHASE 2214-30SLQTA. Always verify electrical and mechanical compatibility before substitution:
- JDS UNIPHASE 2214-30MLQTA — Multi-line variant; same platform, broader spectral output
- JDS UNIPHASE 2218-30SLQTA — Higher-power variant in the same 2200 series
- Coherent Innova 70C Series — Alternative brand, similar power class, different power supply interface
- Melles Griot 543-AP-A01 — Compact argon alternative for lower-power applications
- Spectra-Physics 163C-A03 — Legacy equivalent, requires adapter for power supply compatibility
Note: Cross-brand replacements may require power supply, mounting, or beam alignment adjustments. Contact Konmask for pre-sales compatibility verification.
Why Choose the Original Model
- Proven single-line stability: Factory-tuned etalon ensures clean 514.5 nm output without mode competition
- Long tube life: JDSU 2214 series is rated for extended operational hours under proper conditions
- Drop-in compatibility: Direct replacement for existing 2200-series installations without system redesign
- Traceable quality: OEM-sourced units with original documentation available through Konmask
- Reduced integration risk: Eliminates beam alignment and power supply re-calibration costs associated with cross-brand substitution
Typical Applications
- Flow cytometry and cell sorting (488 nm / 514 nm excitation)
- Holographic recording and interferometry
- Raman spectroscopy (514 nm excitation line)
- Laser Doppler velocimetry (LDV)
- Semiconductor wafer inspection and photolithography
- Fluorescence microscopy
- Optical trapping and particle manipulation
System Compatibility
- Power Supply: JDSU 2200-series laser power supply (e.g., 2200-15SL, 2200-30SL)
- Mounting: Standard 2200-series kinematic mount; compatible with most OEM instrument frames
- Beam Path: Collimated output; compatible with standard 1-inch optic mounts and fiber coupling adapters
- Control Interface: Analog current control via matched power supply; optional RS-232 with compatible PSU
- Operating Environment: Indoor, temperature-controlled lab environment; 15–35°C ambient
Selection Guide
Use the following criteria to determine whether the 2214-30SLQTA is the right choice for your application:
- Required wavelength: If your application demands a clean 514.5 nm line (e.g., Raman, flow cytometry), the single-line model is preferred over multi-line variants
- Power requirement: 30 mW is suitable for most analytical and research applications; upgrade to 2218 series for >50 mW needs
- Existing infrastructure: If you already operate a JDSU 2200-series power supply, the 2214-30SLQTA is a direct drop-in — no additional investment required
- Budget vs. OEM: Refurbished OEM units from Konmask offer significant cost savings vs. new, with tested performance guarantees
- Replacement urgency: Konmask maintains stock of tested units for rapid dispatch; contact us for lead time confirmation
Quality Assurance & Sourcing
- All units sourced through Konmask are inspected and function-tested prior to shipment
- Original OEM units available; refurbished units clearly labeled with condition grade
- Traceable documentation (datasheet, test report) provided upon request
- Secure export packaging with ESD and vibration protection for international shipments
- Konmask is an authorized industrial component distributor serving global B2B customers since 2015
How to Order
- Confirm your required model: JDS UNIPHASE 2214-30SLQTA
- Specify quantity and preferred condition (new OEM / refurbished)
- Contact Konmask via email or phone for stock availability and pricing
- Receive proforma invoice → confirm payment → dispatch within agreed lead time
- Track shipment via provided logistics reference
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I use the 2214-30MLQTA as a direct replacement for the 2214-30SLQTA?
A: Mechanically and electrically yes, but the multi-line variant will output multiple wavelengths simultaneously. If your application requires a single 514 nm line, the SLQTA is required.
Q: Is the 2214-30SLQTA compatible with third-party power supplies?
A: It is designed for JDSU 2200-series PSUs. Third-party supplies may work but require careful current/voltage matching. Konmask can advise on compatibility.
Q: What is the typical service life of this laser head?
A: Under normal operating conditions, argon-ion tubes in this class typically deliver 5,000–10,000+ hours. Actual life depends on duty cycle and operating current.
Q: Do you offer warranty on refurbished units?
A: Yes. Konmask provides a 90-day functional warranty on all tested refurbished units. Terms available on request.
Q: Can Konmask source specific variants or accessories (e.g., etalon, power supply)?
A: Yes. Contact us with your full BOM and we will provide availability and pricing for complete system components.
