Industrial Control & Safety Isolation Solution — JEIL TRANS EN61558-1:1998 METH Transformer | Safety Isolation Series
Where This Product Is Used
The JEIL TRANS EN61558-1:1998 METH Safety Isolation Transformer is engineered for demanding industrial and commercial environments where electrical safety, stable power delivery, and regulatory compliance are non-negotiable. Typical deployment scenarios include:
- Industrial Control Panels: Provides isolated, stable auxiliary power to PLC I/O modules, relay logic circuits, and HMI displays in manufacturing automation lines.
- Machine Tool & CNC Equipment: Supplies clean, isolated 24V/110V control voltage to servo drives, spindle controllers, and safety interlocks.
- Building Automation Systems (BAS): Powers HVAC controllers, fire alarm interfaces, and access control panels requiring galvanic isolation from the mains.
- Medical & Laboratory Equipment: Meets the isolation requirements for Class I medical devices and laboratory instruments where patient/operator safety is paramount.
- Marine & Offshore Control Systems: Isolates sensitive instrumentation from shipboard power distribution networks subject to voltage fluctuations.
- Renewable Energy & Power Conditioning: Used in solar inverter auxiliary circuits and battery management system (BMS) control boards.
Technical Specifications
| Parameter | Value |
|---|---|
| Model / SKU | EN61558-1:1998-METH |
| Brand | JEIL TRANS |
| Series | METH Safety Isolation Transformer |
| Compliance Standard | EN61558-1:1998 / IEC 61558-1 |
| Transformer Type | Safety Isolation Transformer (METH) |
| Country of Origin | South Korea (KR) |
| Weight | 1,590 g |
| Insulation Class | Class F (155°C) — typical for METH series |
| Dielectric Strength | Per EN61558-1:1998 test requirements |
| Mounting | Panel / DIN rail compatible (verify with datasheet) |
| Enclosure | Open frame / potted (confirm with order) |
Note: For exact VA rating, primary/secondary voltage, and terminal configuration, please contact us with your application requirements.
Why Engineers Specify This Model
- EN61558-1:1998 Certified: Fully compliant with the European safety standard for transformers — accepted across EU, Asia-Pacific, and export markets.
- True Galvanic Isolation: Eliminates ground loops and common-mode noise, protecting sensitive PLCs, sensors, and instrumentation from mains-borne interference.
- Korean Industrial Quality: JEIL TRANS is a recognized Korean manufacturer with decades of experience supplying transformers to global OEMs and panel builders.
- Robust Thermal Design: High-grade silicon steel core and Class F insulation ensure reliable continuous operation in high-ambient-temperature enclosures.
- Drop-in Replacement Compatibility: METH series dimensions and terminal layouts are consistent across the range, simplifying retrofits and spare-parts standardization.
- Low No-Load Losses: Optimized core geometry reduces standby power consumption — important for 24/7 industrial installations.
Complete System Bill of Materials
When specifying this transformer for a control panel or automation system, consider the following complementary components:
- Miniature Circuit Breaker (MCB) — primary-side overcurrent protection
- Fuse Holder + Fuse — secondary-side short-circuit protection
- DIN Rail Terminal Blocks — for clean primary/secondary wiring termination
- Surge Protection Device (SPD) — upstream mains transient suppression
- PLC Power Supply Module — downstream 24VDC regulated supply
- EMC Filter — for sensitive instrumentation applications
- Enclosure / Control Cabinet — IP54 or IP65 rated steel enclosure
Compliance & Industry Standards
- EN 61558-1:1998 — Safety of transformers, reactors, power supply units and combinations (General requirements and tests)
- IEC 61558-1 — International equivalent standard
- CE Marking — Low Voltage Directive (LVD) 2014/35/EU compliance
- RoHS Compliant — Restriction of Hazardous Substances
- Korean KC Mark — Domestic Korean safety certification (JEIL TRANS origin)
Quality Assurance & Sourcing
At Konmask.com, we source industrial automation components directly from authorized distributors and verified OEM channels. Every JEIL TRANS transformer we supply:
- Is inspected for physical integrity and label authenticity upon receipt
- Ships with original manufacturer documentation where available
- Is traceable to batch/lot records for quality audit purposes
- Carries a minimum 12-month warranty against manufacturing defects
We specialize in hard-to-find and legacy industrial components — if you need a specific VA rating, voltage configuration, or quantity, contact our technical team.
How to Source This Part
- Confirm your specification: VA rating, primary voltage (e.g. 220V/380V), secondary voltage (e.g. 24V/110V), and mounting style.
- Request a quote: Email support@konmask.com or call +0086 19859288691 with your BOM or datasheet reference.
- Lead time: In-stock units ship within 1–3 business days. Special configurations may require 2–4 weeks.
- Bulk / OEM orders: Volume pricing available for panel builders and system integrators — inquire for tiered pricing.
Application-Specific FAQ
Q: Is this transformer suitable for 24/7 continuous duty?
A: Yes. The METH series is rated for continuous operation. Ensure adequate ventilation around the unit per EN61558-1 installation guidelines.
Q: Can I use this transformer to power a Siemens S7-1200 PLC system?
A: Yes — pair it with a 24VDC SITOP or equivalent regulated PSU on the secondary side. The isolation transformer provides upstream mains isolation and noise filtering.
Q: What is the difference between METH and METS series from JEIL TRANS?
A: METH designates the standard safety isolation transformer series. METS typically refers to toroidal variants. Contact us to confirm the correct series for your application.
Q: Does this unit comply with UL standards for North American markets?
A: This model is certified to EN/IEC 61558-1. For UL 5085 compliance (North America), please contact us — we can source UL-listed variants.
Q: Can you supply a test report or certificate of conformity?
A: Yes. CoC and test reports are available upon request for qualified buyers. Contact our team with your order reference.
