Jetter JL3-0250-25-3RVP Servo Motor | Replacement, Equivalent & Selection Guide
The Jetter JL3-0250-25-3RVP is a compact, high-performance AC servo motor from Jetter’s JL3 series, engineered for precision motion control in industrial automation systems. This page provides full technical specifications, verified replacement options, equivalent models, and a practical selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | JL3-0250-25-3RVP |
| Manufacturer | Jetter AG |
| Series | JL3 |
| Motor Type | AC Servo Motor |
| Rated Output Power | 250 W (0.25 kW) |
| Rated Speed | 2500 rpm |
| Feedback Type | Resolver (3RVP) |
| Protection Class | IP65 (shaft end IP54) |
| Insulation Class | Class F |
| Mounting | Flange mount (IEC standard) |
| Weight (approx.) | 750 g |
| Condition | New / Surplus / Refurbished available |
Note: Specifications are based on manufacturer datasheets. Contact us to confirm exact parameters for your application.
Compatible Replacement & Equivalent Models
If the JL3-0250-25-3RVP is discontinued, on long lead time, or outside budget, the following models may serve as functional equivalents. Always verify electrical and mechanical compatibility before substitution.
| Model | Brand | Power | Speed | Feedback | Compatibility Notes |
|---|---|---|---|---|---|
| JL3-0250-25-3EVP | Jetter | 250 W | 2500 rpm | Encoder | Same frame; encoder replaces resolver |
| JL3-0500-25-3RVP | Jetter | 500 W | 2500 rpm | Resolver | Higher power; same series & drive interface |
| MSM022B-0300-NN-M0-CH0 | Rexroth | 200 W | 3000 rpm | Encoder | Cross-brand; verify drive compatibility |
| SGMJV-02ADA21 | Yaskawa | 200 W | 3000 rpm | Encoder | Cross-brand; requires drive parameter mapping |
| HF-KP23 | Mitsubishi | 200 W | 3000 rpm | Encoder | Cross-brand; verify connector & flange |
⚠ Disclaimer: Cross-brand replacements require engineering validation. Konmask.com recommends consulting your system integrator before substitution.
Why Choose the Original Model
- Seamless Integration: The JL3-0250-25-3RVP is factory-matched to Jetter JetMove servo drives — no parameter remapping required.
- Resolver Feedback Reliability: Resolver-based feedback (3RVP) offers superior noise immunity in harsh industrial environments compared to optical encoders.
- Compact 250 W Frame: Ideal for space-constrained machine designs without sacrificing torque density.
- OEM Warranty Compliance: Using the original part preserves machine OEM warranty and CE/UL certification integrity.
- Proven Field Record: Widely deployed in Jetter-based packaging, textile, and assembly automation lines globally.
Typical Applications
- Packaging machinery (pick-and-place, sealing, labeling)
- Textile and weaving machine axis control
- Assembly line conveyor positioning
- Printing and converting equipment
- CNC auxiliary axes and tool changers
- Medical device manufacturing equipment
System Compatibility
The JL3-0250-25-3RVP is designed to operate with the following Jetter system components:
- Servo Drives: Jetter JetMove 203, JetMove 208, JetMove 2xx series
- Controllers: Jetter JC-647, JC-647x, JetControl series PLCs
- Cables: Jetter resolver cable sets (RVP-compatible, shielded)
- Software: JetSym STX / JetSym WorkBench for commissioning
For non-Jetter drive systems, a resolver-to-encoder converter module may be required.
Selection Guide
Use the following criteria to confirm the JL3-0250-25-3RVP is the right choice — or to identify the correct alternative:
| Selection Criterion | Recommendation |
|---|---|
| Required power ≤ 250 W | ✅ JL3-0250-25-3RVP is correct |
| Required power 251–500 W | Consider JL3-0500-25-3RVP |
| Resolver feedback required | ✅ 3RVP suffix confirms resolver |
| Encoder feedback preferred | Select JL3-0250-25-3EVP variant |
| Existing Jetter JetMove drive | ✅ Direct plug-in compatible |
| Third-party drive system | Verify resolver interface or use cross-brand equivalent |
| Harsh environment (EMI, vibration) | ✅ Resolver preferred over encoder |
| Budget-sensitive replacement | Consider Yaskawa SGMJV or Mitsubishi HF-KP series with drive adaptation |
Quality Assurance & Sourcing
- Verified Supply Chain: All units sourced from authorized distributors, OEM surplus, or certified refurbishers.
- Pre-Shipment Inspection: Visual inspection, label verification, and basic electrical continuity check on every unit.
- Authenticity Guarantee: Counterfeit-free policy — units rejected if markings, date codes, or packaging are inconsistent.
- Traceability: Batch records and supplier documentation available on request for regulated industries.
- Warranty: 12-month warranty on new units; 90-day warranty on tested surplus/refurbished units.
How to Order
- Confirm Part Number: Verify JL3-0250-25-3RVP matches your nameplate and drive documentation.
- Specify Condition: New, surplus, or refurbished — we stock multiple grades.
- Request a Quote: Email support@konmask.com with quantity, required delivery date, and destination country.
- Receive Proforma Invoice: We issue PI within 1 business day with lead time and shipping options.
- Confirm & Ship: Payment confirmed → unit inspected → shipped with tracking and commercial invoice.
Bulk / OEM orders: Volume pricing available for 5+ units. Contact us for a dedicated quote.
Replacement & Compatibility FAQ
Q: Can I replace JL3-0250-25-3RVP with an encoder-based motor?
A: Only if your Jetter drive supports encoder feedback mode. The JL3-0250-25-3EVP is the direct encoder variant. Confirm drive firmware version before switching.
Q: Is the JL3-0250-25-3RVP still in production?
A: Jetter has transitioned some JL3 series models. Contact us to confirm current availability and lead time — we maintain surplus stock for discontinued variants.
Q: Can I use a Yaskawa or Mitsubishi motor as a drop-in replacement?
A: Mechanically possible with flange adapters, but electrically requires drive reconfiguration. Not recommended without engineering sign-off.
Q: Do you provide test reports?
A: Yes. Functional test reports are available for refurbished units. New units ship with manufacturer documentation.
Q: What is the lead time?
A: In-stock units ship within 2–3 business days. Out-of-stock sourcing typically takes 7–21 business days depending on origin.
