Precision Motion Control Solution – Kollmorgen AKD-P00306-NBEC-0000 | AKD Series
Where This Product Is Used
The Kollmorgen AKD-P00306-NBEC-0000 is a high-performance digital servo drive engineered for demanding industrial motion control applications. Engineers and system integrators specify this drive across a wide range of industries:
- CNC Machining Centers – Delivers precise axis positioning and velocity control for multi-axis milling, turning, and grinding machines.
- Industrial Robotics – Powers articulated robot joints requiring fast dynamic response and tight torque regulation.
- Packaging Machinery – Synchronizes servo axes in form-fill-seal, cartoning, and labeling lines for high-throughput production.
- Semiconductor & Electronics Assembly – Provides sub-micron positioning accuracy for pick-and-place, wafer handling, and PCB drilling equipment.
- Printing & Converting – Maintains web tension and registration accuracy in high-speed printing presses and slitter-rewinders.
- Medical Devices – Supports smooth, quiet motion in imaging systems, surgical robots, and laboratory automation platforms.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | AKD-P00306-NBEC-0000 |
| Series | AKD (Advanced Kollmorgen Drive) |
| Continuous Output Current | 3 A |
| Peak Output Current | 9 A (3× continuous) |
| Supply Voltage | 120–240 VAC, Single or Three Phase |
| DC Bus Voltage | 170–340 VDC |
| Fieldbus Interface | EtherCAT + CANopen (dual-port) |
| Feedback Supported | SFD3, EnDat 2.2, BiSS-C, Resolver, Incremental Encoder |
| Control Modes | Position, Velocity, Torque, Electronic Gearing |
| Safe Torque Off (STO) | SIL 2 / PLd Cat. 3 |
| Protection Class | IP20 |
| Operating Temperature | 0 °C to +40 °C (up to +55 °C derated) |
| Weight | 2.5 kg |
| Dimensions (H×W×D) | Refer to Kollmorgen AKD Installation Manual |
Why Engineers Specify This Model
- Dual Fieldbus Flexibility – Native EtherCAT and CANopen on a single unit eliminates the need for separate gateway hardware, reducing panel footprint and wiring cost.
- Auto-Tuning via WorkBench – Kollmorgen’s WorkBench software performs one-click auto-tuning, dramatically reducing commissioning time on new machine builds.
- SIL 2 Safe Torque Off – Integrated STO meets EN 61800-5-2 without external safety relays, simplifying CE/UL machine safety compliance.
- Wide Feedback Compatibility – Supports SFD3, EnDat 2.2, BiSS-C, resolver, and incremental encoder, making it compatible with virtually all Kollmorgen AKM servo motors and many third-party motors.
- Compact 3A Frame – The P00306 frame is optimized for space-constrained control cabinets while delivering full servo performance for light-to-medium load axes.
Complete System Bill of Materials
For a fully operational servo axis using the AKD-P00306-NBEC-0000, engineers typically specify the following complementary components:
- Kollmorgen AKM Series Servo Motor (e.g., AKM21, AKM31) – matched to 3A drive rating
- Kollmorgen CFB or CFD Feedback Cable – motor-to-drive feedback connection
- Kollmorgen CPB Power Cable – motor power connection
- 24 VDC Control Power Supply – for drive logic and I/O
- EtherCAT Master Controller (e.g., Beckhoff CX series, Omron NJ/NX) or CANopen Master PLC
- External Regenerative Resistor (if high-inertia or frequent deceleration cycles)
- Line Filter (EMC) – per EN 61800-3 Category C2/C3 requirements
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C – Power Conversion Equipment
- IEC 61800-5-1 – Electrical safety of adjustable speed drives
- IEC 61800-5-2 – Functional safety (STO, SIL 2 / PLd Cat. 3)
- IEC 61800-3 – EMC requirements for drive systems
- RoHS 2 Compliant
Quality Assurance & Sourcing
Konmask.com sources the AKD-P00306-NBEC-0000 exclusively through verified industrial distribution channels. Every unit undergoes the following before shipment:
- Visual and cosmetic inspection against OEM cosmetic standards
- Label and nameplate verification (part number, serial number, date code)
- Packaging integrity check with anti-static and moisture-barrier protection
- Documentation review – datasheet, declaration of conformity available on request
We do not sell counterfeit, refurbished-as-new, or grey-market product. Traceability documentation is available for qualified OEM and MRO customers.
How to Source This Part
- In-Stock Orders – Add to cart and check out directly. Same-day dispatch available for orders placed before 15:00 CST.
- Volume / OEM Pricing – Contact support@konmask.com for quantity breaks of 5+ units.
- Urgent / Emergency Procurement – Call or WhatsApp +0086 19859288691 for expedited sourcing and air-freight options.
- Cross-Reference / Replacement – If you are replacing a legacy drive, share your existing part number and motor nameplate data; our engineers will confirm compatibility.
Application-Specific FAQ
Q: Can the AKD-P00306-NBEC-0000 control a third-party servo motor?
A: Yes. The AKD supports resolver and incremental encoder feedback natively, enabling use with many non-Kollmorgen motors. Motor parameters must be manually entered in WorkBench. Contact us for compatibility assessment.
Q: Is EtherCAT and CANopen available simultaneously?
A: The NBEC variant provides both EtherCAT and CANopen ports; however, only one fieldbus is active at a time, selected via WorkBench configuration.
Q: What is the difference between AKD-P and AKD-B?
A: The AKD-P (Panel-mount) variant is designed for installation inside a control cabinet. The AKD-B (Book-style) variant supports shared DC bus configurations for multi-axis systems. The P00306 is the panel-mount, 3A model.
Q: Does this drive support functional safety without an external safety relay?
A: Yes. The integrated STO (Safe Torque Off) function meets SIL 2 / PLd Category 3 per IEC 61800-5-2, eliminating the need for an external safety relay on the STO circuit.
Q: What software is used to commission this drive?
A: Kollmorgen WorkBench (free download from Kollmorgen.com) is the primary commissioning and diagnostic tool. It supports auto-tuning, scope functions, and full parameter management over USB or Ethernet.
