KOLLMORGEN M.3000.1064 R4 Servo Drive | Replacement, Equivalent & Selection Guide
The KOLLMORGEN M.3000.1064 R4 is a high-performance servo drive from KOLLMORGEN’s M-Series platform, engineered for precision motion control in demanding industrial automation environments. This page provides full technical specifications, compatible replacement options, equivalent models, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Manufacturer: KOLLMORGEN
- Part Number / SKU: M.3000.1064 R4
- Series: M-Series (M.3000)
- Product Type: Servo Drive
- Revision: R4
- Continuous Output Current: ~10.6 A (refer to datasheet for exact rating)
- Input Voltage: 3-phase AC, 230 V / 400 V (model-dependent)
- Communication Interface: EtherCAT / CANopen / Analog (verify with KOLLMORGEN datasheet)
- Feedback Support: Resolver, EnDat, SinCos, Hiperface
- Protection Class: IP20
- Mounting: DIN rail / panel mount
- Weight: ~300 g
- Compliance: CE, UL (verify current certifications)
Note: Always verify specifications against the official KOLLMORGEN M.3000.1064 R4 datasheet before final design-in.
Compatible Replacement & Equivalent Models
When the original M.3000.1064 R4 is unavailable or discontinued, the following models may serve as functional replacements. Verify electrical and mechanical compatibility before substitution:
- KOLLMORGEN AKD-P00606-NBEC-0000 – AKD platform successor; EtherCAT, 6 A continuous, compatible motor feedback
- KOLLMORGEN AKD-P01206-NBEC-0000 – 12 A continuous, direct upgrade path for higher current applications
- KOLLMORGEN S700 Series – Legacy M-Series replacement with expanded fieldbus support
- Siemens SINAMICS S120 – Cross-brand alternative for multi-axis servo systems
- Lenze i700 Servo Inverter – Compatible for EtherCAT-based motion architectures
- Bosch Rexroth IndraDrive Cs – Compact servo drive alternative for similar power ranges
Disclaimer: Cross-brand replacements require full engineering validation. Konmask.com recommends consulting your system integrator before substitution.
Why Choose the Original KOLLMORGEN M.3000.1064 R4
- Drop-in compatibility: Designed as a direct fit for existing KOLLMORGEN M-Series servo systems — no re-parameterization of the motion controller required.
- Proven reliability: KOLLMORGEN’s M-Series drives are field-proven in thousands of installations across packaging, robotics, and semiconductor equipment.
- Revision R4 improvements: R4 revision incorporates firmware and hardware refinements over earlier revisions, improving thermal management and EMC performance.
- OEM-grade sourcing: Konmask.com sources from authorized channels and verified distributors to ensure genuine, traceable parts.
Typical Applications
- CNC machine tool axes and spindle control
- Robotic arm joint drives (SCARA, articulated, delta)
- Semiconductor wafer handling and pick-and-place
- Packaging machinery (form-fill-seal, labeling, cartoning)
- Printing and converting equipment
- Medical device motion platforms
- Textile and winding machinery
System Compatibility
- Compatible Motors: KOLLMORGEN AKM, RBE, and legacy M-Series servo motors with matching feedback type
- Compatible Controllers: KOLLMORGEN AKD PDMM, KAS (Kollmorgen Automation Suite), third-party EtherCAT masters
- Fieldbus: EtherCAT (CoE), CANopen DS402, analog ±10 V velocity/torque command
- Software: KOLLMORGEN WorkBench commissioning software (free download from KOLLMORGEN)
Selection Guide
Use the following criteria to confirm the M.3000.1064 R4 is the correct drive for your application:
- Step 1 – Current rating: Confirm your motor’s continuous and peak current requirements match the drive’s output ratings.
- Step 2 – Supply voltage: Verify your facility’s AC supply voltage (230 V or 400 V) matches the drive’s input specification.
- Step 3 – Feedback type: Match the motor encoder/resolver type (EnDat 2.1/2.2, SinCos, Hiperface, Resolver) to the drive’s supported feedback interfaces.
- Step 4 – Fieldbus: Confirm the motion controller’s communication protocol (EtherCAT, CANopen, analog) is supported.
- Step 5 – Revision: Specify R4 explicitly when ordering to ensure hardware/firmware consistency with your existing installation.
- Step 6 – Environment: Confirm ambient temperature, humidity, and IP rating requirements are within the drive’s operating envelope.
Quality Assurance & Sourcing
- All units sourced through verified industrial distribution channels
- Inspection includes visual check, label verification, and functional test where applicable
- Traceability documentation available upon request (lot number, country of origin)
- Warranty: 12 months from date of shipment (see full terms at Konmask.com/policies)
- Returns accepted within 30 days for unused, unopened units in original packaging
How to Order
- Confirm part number: KOLLMORGEN M.3000.1064 R4
- Specify quantity and required delivery timeline
- Add to cart and proceed to checkout, or contact us for bulk/OEM pricing
- For urgent requirements, email [email protected] or call +0086 19859288691
- Lead time: In-stock units ship within 1–3 business days; ex-stock orders subject to availability
Replacement & Compatibility FAQ
Q: Is the KOLLMORGEN M.3000.1064 R4 still in production?
A: The M.3000 series has been superseded by the AKD platform. Konmask.com maintains stock of genuine M.3000.1064 R4 units for legacy system support. Contact us for current availability.
Q: Can I replace the M.3000.1064 R4 with an AKD drive without changing the motor?
A: In many cases yes, provided the motor feedback type is supported by the AKD and the current ratings are compatible. A re-commissioning session in WorkBench will be required.
Q: What is the difference between R3 and R4 revisions?
A: R4 incorporates hardware and firmware refinements. Always use the same revision as your existing installation to ensure parameter compatibility. Contact KOLLMORGEN technical support for detailed revision change notes.
Q: Do you provide a certificate of conformity?
A: Yes. A certificate of conformity and traceability documentation can be provided upon request for all orders.
Q: Can Konmask.com source other KOLLMORGEN part numbers?
A: Yes. We source across the full KOLLMORGEN portfolio including AKD, AKM, S700, and legacy M-Series. Submit your BOM or part list to [email protected].
