Industrial Motion Control Solution – Kollmorgen S30361-NA-SB | AKD Series
Where This Product Is Used
The Kollmorgen S30361-NA-SB is a high-performance AC servo drive engineered for demanding industrial motion control applications. Engineers and system integrators specify this unit across a wide range of industries and use cases:
- CNC Machining Centers – Delivers precise axis positioning and velocity control for milling, turning, and grinding operations requiring sub-micron repeatability.
- Industrial Robotics – Powers articulated robot joints in automotive assembly, welding, and pick-and-place cells where dynamic response and torque accuracy are critical.
- Packaging Machinery – Synchronizes multi-axis motion in form-fill-seal, cartoning, and labeling equipment at high throughput rates.
- Semiconductor & Electronics Manufacturing – Supports ultra-smooth, low-vibration motion in wafer handling, PCB drilling, and SMT placement machines.
- Material Handling & Conveyors – Enables precise speed regulation and positioning in automated storage and retrieval systems (AS/RS) and AGV drive systems.
- Printing & Converting – Maintains tight register control in web-fed printing presses and slitting/rewinding lines.
- Medical & Laboratory Automation – Provides quiet, smooth motion for diagnostic imaging gantries, liquid handling robots, and surgical positioning systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | S30361-NA-SB |
| Manufacturer | Kollmorgen |
| Series | AKD (Advanced Kollmorgen Drive) |
| Drive Type | AC Servo Amplifier / Servo Drive |
| Input Voltage | 120–240 VAC, Single or Three Phase |
| Continuous Output Current | 3 A (rms) |
| Peak Output Current | 9 A (rms) |
| Communication Interface | EtherCAT, CANopen, Modbus TCP/IP |
| Feedback Supported | SFD, EnDat 2.1/2.2, Resolver, Incremental Encoder |
| Operating Temperature | 0 °C to +40 °C (ambient) |
| Protection Rating | IP20 |
| Weight | 3.5 kg |
| Compliance | CE, UL, cUL, RoHS |
Note: Specifications are based on published Kollmorgen AKD series data. Verify against the official datasheet for your application.
Why Engineers Specify This Model
- Auto-Tuning Technology – Kollmorgen’s AKD auto-tuning algorithm reduces commissioning time from hours to minutes, even on complex mechanical loads.
- Wide Feedback Compatibility – Native support for SFD (Smart Feedback Device), EnDat, resolver, and incremental encoders eliminates the need for external converter modules.
- EtherCAT Real-Time Network – Sub-millisecond cycle times enable tight multi-axis synchronization in coordinated motion applications.
- Safe Torque Off (STO) – Integrated SIL 2 / PLd safety function meets EN 61800-5-2 without external safety relays, simplifying panel design.
- Compact DIN-Rail Footprint – Space-efficient housing reduces control cabinet size and wiring complexity.
- Kollmorgen WorkBench Software – Intuitive PC-based commissioning, oscilloscope, and diagnostic tools accelerate startup and troubleshooting.
Complete System Bill of Materials
For a fully operational servo axis using the S30361-NA-SB, the following components are typically required:
- Kollmorgen S30361-NA-SB Servo Drive (this unit)
- Kollmorgen AKM or KBM Series Servo Motor (matched to drive current rating)
- Motor Power Cable (shielded, rated for servo duty)
- Feedback Cable (SFD or EnDat, matched to motor encoder)
- 24 VDC Control Power Supply (min. 2 A)
- EtherCAT or CANopen Master Controller (PLC or motion controller)
- Regenerative Braking Resistor (application-dependent)
- EMC Line Filter (recommended for CE compliance)
- Kollmorgen WorkBench Software (free download from Kollmorgen)
Compliance & Industry Standards
- CE Marking – Complies with EU Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU).
- UL / cUL Listed – Recognized under UL 508C (Power Conversion Equipment) for North American markets.
- RoHS Compliant – Free of restricted hazardous substances per EU Directive 2011/65/EU.
- Functional Safety – Safe Torque Off (STO) certified to SIL 2 (IEC 62061) and PLd / Cat. 3 (EN ISO 13849-1).
- IEC 61800-5-1 – Adjustable speed electrical power drive systems safety requirements.
Quality Assurance & Sourcing
At Konmask.com, every Kollmorgen S30361-NA-SB unit is subject to our multi-point quality process:
- Authentic Origin – Sourced through verified industrial distribution channels; no grey-market or counterfeit units.
- Pre-Shipment Inspection – Visual inspection, label verification, and packaging integrity check before dispatch.
- Traceability – Lot codes and serial numbers recorded for full supply-chain traceability.
- Warranty – 12-month warranty against manufacturing defects; DOA replacement policy within 7 days of receipt.
- Secure Packaging – Anti-static, foam-padded export carton to protect sensitive electronics during international transit.
How to Source This Part
- Add to Cart – Click “Add to Cart” and proceed to checkout for immediate online purchase.
- Request a Quote – For volume orders (5+ units) or project-based procurement, email support@konmask.com for a competitive quote within 24 hours.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock items: contact us for ETA.
- Export & Customs – We handle export documentation (commercial invoice, packing list, COO) for international shipments. HS Code: 8504.40 (static converters).
- Technical Pre-Sales Support – Our engineers can assist with drive sizing, cable selection, and compatibility verification before purchase.
Application-Specific FAQ
Q: Is the S30361-NA-SB compatible with Siemens S7 or Allen-Bradley PLCs?
A: Yes. Via EtherCAT or CANopen, the AKD drive integrates with most major PLC platforms. EtherCAT master modules are available for Siemens, Rockwell, Beckhoff, and others.
Q: Can this drive operate in torque mode for tension control applications?
A: Yes. The AKD supports position, velocity, and torque control modes, selectable via the WorkBench software or fieldbus commands.
Q: What is the maximum cable length between drive and motor?
A: Kollmorgen recommends a maximum of 25 m for standard cables. Longer runs require low-capacitance cables and may need an output filter.
Q: Does the S30361-NA-SB support multi-axis synchronization?
A: Yes. Using EtherCAT with a compatible motion controller, multiple AKD drives can be synchronized with microsecond-level jitter for electronic gearing and camming.
Q: Is a regenerative braking resistor included?
A: No. An external braking resistor is required for applications with high deceleration loads. Contact us for sizing assistance.
