CNC & Robotics Motion Control Solution — Kollmorgen AKM54H-ACCNC-00 | AKM Series
The Kollmorgen AKM54H-ACCNC-00 is a high-performance AC synchronous servo motor from the industry-proven AKM (Servo Motor) Series. Engineered for precision motion control in demanding industrial environments, this model delivers exceptional torque density, low cogging, and seamless integration with Kollmorgen drive platforms — making it the preferred choice for engineers specifying reliable, high-cycle automation systems.
Where This Product Is Used
The AKM54H-ACCNC-00 is deployed across a wide range of precision motion applications:
- CNC Machining Centers — Spindle and axis drives requiring tight velocity and position loop performance
- Industrial Robotics — Joint actuators in articulated arms and SCARA robots demanding high torque-to-inertia ratios
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and labeling lines
- Semiconductor & Electronics Manufacturing — Wafer handling, PCB drilling, and precision gantry systems
- Printing & Converting Equipment — Web tension control and register mark tracking
- Medical Device Manufacturing — Surgical robot joints and diagnostic imaging positioning stages
- Textile & Winding Machines — Tension-controlled winding with dynamic speed response
Technical Specifications
- Part Number: AKM54H-ACCNC-00
- Series: AKM (Kollmorgen AC Synchronous Servo Motor)
- Frame Size: 54 (NEMA / IEC compatible)
- Winding Code: H (High voltage winding)
- Feedback: Resolver (standard) — compatible with SFD, EnDat, Hiperface options
- Brake: None (no holding brake)
- Shaft: Standard smooth shaft (no keyway)
- IP Rating: IP65 (dust-tight, water jet protected)
- Insulation Class: Class F (155°C)
- Magnet Type: Rare-earth neodymium permanent magnet
- Compatible Drives: Kollmorgen AKD, S700, SERVOSTAR 600 series
- Weight: Approx. 3.0 kg
- Certifications: CE, UL, cUL
Why Engineers Specify This Model
- High Torque Density — Compact frame delivers maximum continuous and peak torque, reducing machine footprint
- Low Cogging Torque — Skewed stator design ensures smooth rotation at low speeds, critical for precision contouring
- Plug-and-Play with AKD Drives — Smart Feedback Device (SFD) enables auto-identification and zero-tuning commissioning
- Robust IP65 Sealing — Withstands coolant splash, dust, and wash-down environments common in machine tool applications
- Wide Speed Range — Maintains rated torque across a broad RPM band for flexible machine design
- Long Service Life — Premium bearings and Class F insulation rated for high-cycle, 24/7 industrial duty
Complete System Bill of Materials
For a fully operational servo axis using the AKM54H-ACCNC-00, engineers typically specify:
- Servo Drive: Kollmorgen AKD-P00306-NBEC-0000 (3A continuous / 9A peak)
- Power Cable: Kollmorgen CF-CFBM7DF-SBBG (motor power cable, shielded, flex-rated)
- Feedback Cable: Kollmorgen CF-CFBM7DF-CEAW (resolver/SFD feedback cable)
- Mating Connector Kit: AKM connector kit (motor side, IP65)
- Coupling: Bellows or zero-backlash jaw coupling (application-dependent)
- Motion Controller: Kollmorgen KAS (Kollmorgen Automation Suite) or third-party EtherCAT master
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- UL / cUL Listed — Recognized for use in North American industrial installations
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
- IP65 — IEC 60529 ingress protection standard
- Insulation Class F — IEC 60085 thermal classification
- HS Code: 8501.52 — AC motors, multi-phase, output 750W–75kW
Quality Assurance & Sourcing
At Konmask.com, every Kollmorgen AKM54H-ACCNC-00 unit is subject to our rigorous sourcing and verification protocol:
- ✅ Authentic OEM Parts — Sourced directly from authorized Kollmorgen distribution channels
- ✅ Pre-shipment Inspection — Visual, dimensional, and label verification against OEM specifications
- ✅ Traceability — Full lot and serial number documentation retained on file
- ✅ Anti-counterfeit Screening — All units checked against known counterfeit indicators
- ✅ Secure Packaging — OEM or equivalent protective packaging with ESD-safe materials where applicable
- ✅ Warranty Support — 12-month replacement warranty on verified genuine units
How to Source This Part
- Request a Quote — Contact us at support@konmask.com with your required quantity and delivery timeline
- Lead Time Confirmation — We confirm stock availability or estimated lead time within 24 business hours
- Purchase Order — Submit your PO; we accept T/T bank transfer, PayPal, and major credit cards
- Inspection & Dispatch — Units are inspected, documented, and dispatched via DHL / FedEx / UPS with full tracking
- After-sales Support — Our technical team is available for commissioning guidance and warranty claims
Application-Specific FAQ
Q: Is the AKM54H-ACCNC-00 compatible with the Kollmorgen AKD drive?
A: Yes. The AKM54H-ACCNC-00 is fully compatible with the AKD servo drive family. When paired with an AKD drive equipped with SFD (Smart Feedback Device), the motor auto-identifies and the drive auto-configures — eliminating manual parameter entry.
Q: What feedback device does this motor use?
A: The standard AKM54H-ACCNC-00 is equipped with a resolver. Resolver-based feedback is highly robust in harsh environments (vibration, temperature extremes, EMI). Alternative feedback options (EnDat 2.2, Hiperface, SFD) are available on other AKM54H variants.
Q: Can this motor be used in a vertical axis application?
A: Yes, with the appropriate holding brake. The AKM54H-ACCNC-00 does not include an integrated brake (suffix -00). For vertical axes requiring load holding at rest, specify the AKM54H-ACCNC-B0 variant with integrated 24VDC holding brake.
Q: What is the IP rating and can it handle coolant exposure?
A: The motor is rated IP65, providing full protection against dust ingress and low-pressure water jets from any direction. It is suitable for machine tool environments with coolant mist and splash, but not for direct coolant immersion.
Q: Do you provide documentation and test reports?
A: Yes. Upon request, we can provide the OEM datasheet, dimensional drawing, and our internal inspection report for the specific serial number shipped.
