Industrial Motion Control Solution – KOLLMORGEN 0190-A2450 | PRD-AMPB25EB-00 | CDN500-19 Series
Where This Product Is Used
The KOLLMORGEN 0190-A2450 (PRD-AMPB25EB-00 / CDN500-19 / 0190-07970) servo amplifier is engineered for demanding industrial motion control environments. Typical deployment scenarios include:
- CNC Machining Centers – Provides precise axis positioning and velocity control for multi-axis milling, turning, and grinding machines.
- Robotic Assembly Lines – Drives servo motors in articulated robot arms requiring high dynamic response and tight torque regulation.
- Semiconductor & Electronics Manufacturing – Supports sub-micron positioning stages in wafer handling and PCB pick-and-place equipment.
- Packaging Machinery – Controls high-speed indexing, filling, and sealing axes with synchronised multi-drive coordination.
- Printing & Converting Equipment – Maintains web tension and registration accuracy across wide-format and narrow-web presses.
- Medical & Laboratory Automation – Powers precision dosing pumps, imaging gantries, and diagnostic instrument actuators.
Technical Specifications
- Manufacturer: KOLLMORGEN
- Part Number / SKU: 0190-A2450
- Alternate Part Numbers: PRD-AMPB25EB-00 | HE 810-802902-034 | CDN500-19 | 0190-07970
- Product Type: AC Servo Amplifier / Drive
- Series: Goldline / AKD Compatible Platform
- Continuous Output Current: 25 A (peak rating per PRD-AMPB25EB designation)
- Supply Voltage: 3-phase AC input (refer to OEM datasheet for exact voltage range)
- Feedback Interface: Encoder / Resolver compatible (model-dependent)
- Communication: Analog ±10 V, Step/Direction, and fieldbus-ready variants
- Protection Class: IP20 (panel-mount)
- Weight: Approx. 700 g
- Compliance: CE, UL (verify current certification status with OEM documentation)
Why Engineers Specify This Model
- High Peak Torque Density – The 25 A peak current rating (PRD-AMPB25EB) delivers the burst torque needed for rapid acceleration in servo-intensive applications.
- Multi-Reference Compatibility – Cross-referenced under four part numbers (0190-A2450, PRD-AMPB25EB-00, CDN500-19, 0190-07970), simplifying procurement across different OEM documentation sets.
- Drop-In Replacement Confidence – Maintains identical form, fit, and function for legacy KOLLMORGEN Goldline drive platforms, minimising re-commissioning time.
- Broad Motor Compatibility – Pairs with KOLLMORGEN Goldline, AKM, and compatible third-party servo motors without firmware changes.
- Proven Field Reliability – Widely deployed in Tier-1 automotive and aerospace manufacturing lines with documented MTBF performance.
Complete System Bill of Materials
For a fully operational servo axis using this amplifier, engineers typically specify:
- KOLLMORGEN Servo Amplifier – 0190-A2450 / PRD-AMPB25EB-00 (this unit)
- Compatible Servo Motor – KOLLMORGEN Goldline or AKM series (size matched to load)
- Feedback Cable – Encoder or resolver cable assembly (shielded, OEM-specified length)
- Power Cable – Motor power cable with appropriate gauge for 25 A continuous
- DC Bus Capacitor / Regen Resistor – External braking resistor for high-inertia loads
- 24 VDC Control Power Supply – Logic supply for drive enable and I/O
- Motion Controller / PLC – EtherCAT, PROFIBUS, or analog command source
- EMC Line Filter – Mains filter for CE compliance in conducted emissions
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) and EMC Directive compliance
- UL Listed – Suitable for North American panel installations (verify current listing)
- RoHS – Manufactured in accordance with hazardous substance restrictions
- IEC 61800-5-1 – Adjustable speed electrical power drive systems safety standard
- ISO 13849 – Functional safety considerations for STO (Safe Torque Off) variants
Quality Assurance & Sourcing
Every unit shipped by Konmask.com undergoes the following quality process:
- Visual and dimensional inspection against OEM reference drawings
- Label and part-number cross-verification (all four reference numbers confirmed)
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Traceable sourcing documentation available on request
We source from authorised distributors, certified refurbishers, and verified surplus channels. Counterfeit-prevention protocols are applied to all KOLLMORGEN inventory.
How to Source This Part
- In Stock: Add to cart and check out directly — most orders ship within 1–3 business days.
- Lead Time / MOQ: Contact us for volume pricing, blanket orders, or expedited delivery.
- Export & Cross-Border: We ship globally. Export documentation (CO, packing list, commercial invoice) provided for international orders.
- Repair & Exchange: Core exchange programme available — enquire via email for details.
Application-Specific FAQ
Q: Is the 0190-A2450 a direct replacement for CDN500-19?
A: Yes. CDN500-19 and 0190-A2450 are cross-reference part numbers for the same KOLLMORGEN servo amplifier assembly. Confirm with your OEM documentation before installation.
Q: Which servo motors are compatible with PRD-AMPB25EB-00?
A: This amplifier is designed for KOLLMORGEN Goldline series motors. Compatibility with AKM motors depends on firmware version and feedback type — contact our technical team for confirmation.
Q: Can this drive be used with a Siemens or Allen-Bradley PLC?
A: Yes, via analog ±10 V command or Step/Direction interface. EtherCAT or PROFIBUS variants require the appropriate option card — verify the exact variant before ordering.
Q: What is the warranty on this unit?
A: Konmask.com provides a 90-day functional warranty on all servo amplifiers. Extended warranty and service contracts are available on request.
Q: Do you provide installation support?
A: Our engineering team can provide parameter setup guidance, wiring diagrams, and commissioning checklists. Contact [email protected] for technical assistance.
