KUKA 00-104-986 RV-410F-236 Robot Gearbox | Replacement, Equivalent & Selection Guide
The KUKA 00-104-986 (RV-410F-236) is a precision RV-series cycloidal reduction gearbox engineered for KUKA industrial robot arms. Designed for high-torque, high-rigidity joint drive applications, this unit is a critical component in KUKA KR series robots. Konmask.com supplies genuine and compatible-grade replacements with full traceability and technical support.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 00-104-986 |
| Model | RV-410F-236 |
| Brand | KUKA |
| Type | RV Cycloidal Gearbox (Robot Joint Reducer) |
| Reduction Ratio | 236 |
| Series | RV-F Series |
| Rated Torque | ~4,100 N·m (nominal, refer to OEM datasheet) |
| Application | Industrial Robot Joint Drive (Axis 1–3) |
| Weight | Approx. 323 g (unit weight; confirm with datasheet) |
| Condition | New / Refurbished / Exchange available |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the KUKA 00-104-986 RV-410F-236. Always verify mounting dimensions, ratio, and torque ratings before substitution:
- Nabtesco RV-410F-236 — OEM-equivalent cycloidal reducer; direct form-fit replacement
- Nabtesco RV-320F-236 — Lower torque class; suitable for lighter-duty axis substitution
- Nabtesco RV-500F-236 — Higher torque class; uprated alternative for demanding cycles
- Sumitomo Cyclo BBB Series (equivalent ratio) — Cross-brand cycloidal option; requires adapter verification
- KUKA 00-104-987 / 00-104-985 — Adjacent KUKA part numbers; confirm ratio and flange compatibility
Contact Konmask for a free compatibility check before ordering a replacement.
Why Choose the Original KUKA 00-104-986
- Factory-calibrated for KUKA KR series robot kinematic chains
- Guaranteed dimensional and ratio compliance with OEM specifications
- Minimizes re-commissioning time — plug-and-play replacement
- Full traceability: serial number, batch, and OEM certification documentation available
- Backed by Konmask sourcing quality assurance process
Typical Applications
- KUKA KR 500, KR 600, KR 1000 TITAN series robot joint drives (Axis 1–3)
- Heavy-payload robotic welding and material handling systems
- Automotive body-in-white assembly lines
- Foundry and press-tending automation cells
- Palletizing and large-part transfer robots
System Compatibility
- Robot Controllers: KUKA KR C4, KR C5
- Robot Series: KR QUANTEC, KR FORTEC, KR TITAN
- Axis Position: Primarily Axis 1, 2, 3 (high-torque joints)
- Lubrication: Nabtesco/KUKA-approved grease (Vigo Grease RE No.0 or equivalent)
Selection Guide
Use the following criteria to confirm the correct gearbox for your application:
- Step 1 — Verify Part Number: Cross-reference KUKA 00-104-986 against your robot BOM or spare parts list.
- Step 2 — Confirm Reduction Ratio: RV-410F-236 — the suffix denotes the gear ratio. Do not substitute a different ratio without reconfiguring the robot controller.
- Step 3 — Check Torque Class: RV-410F indicates ~4,100 N·m rated torque. Ensure application load does not exceed this.
- Step 4 — Flange & Mounting: Confirm output flange bolt pattern and input shaft dimensions match your robot arm housing.
- Step 5 — Condition Preference: Choose new OEM, certified refurbished, or exchange unit based on budget and lead-time requirements.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Pre-shipment inspection: visual, dimensional, and rotation torque check
- Packaging: anti-static foam + moisture-barrier bag + rigid outer carton
- Documentation: packing list, inspection report, and OEM label photos provided
- Export compliance: HS Code 8483.40 (Gears and Gearing)
How to Order
- Online: Add to cart — we confirm stock and lead time within 1 business day
- Email RFQ: [email protected] — include part number, quantity, and required condition
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 3–5 business days; sourced units 7–21 days
- Payment: T/T, PayPal, credit card, and trade-term options available
Replacement & Compatibility FAQ
Q: Can I use a Nabtesco RV-410F-236 to replace KUKA 00-104-986?
A: Yes. The KUKA 00-104-986 is based on the Nabtesco RV-410F-236 platform. In most cases it is a direct replacement, but always verify the output flange configuration for your specific robot model.
Q: Is the gear ratio 236 critical?
A: Yes. The robot controller motion parameters are calibrated to the exact ratio. Substituting a different ratio will cause positioning errors and may damage the robot.
Q: Do you offer exchange / core return programs?
A: Yes. Contact us with your failed unit details for an exchange pricing quote.
Q: What is the typical service life?
A: Under normal operating conditions and proper lubrication intervals, RV-F series gearboxes typically achieve 10,000–20,000 operating hours.
Q: Can Konmask provide a certificate of conformance?
A: Yes, upon request for new OEM units. Refurbished units include an inspection report.
