KUKA 00-106-446 – Precision Axis 1-3 Gearbox for KR 150 / KR 180 / ZH 150 / ZH 180 | KUKA KR C Series
Engineering Background
The KUKA 00-106-446 is a factory-original precision gearbox (reducer) engineered for the axis 1–3 drive train of KUKA’s heavy-payload KR 150 and KR 180 series robots, including the ZH 150 and ZH 180 shelf-mounted variants. Designed to KUKA’s exacting tolerances, this unit delivers the torsional rigidity and backlash control demanded by high-cycle automotive, foundry, and heavy-assembly automation lines.
Product Positioning
Konmask.com supplies this part as a verified OEM-grade replacement for maintenance engineers and procurement teams requiring a drop-in solution with full dimensional and performance compatibility. Every unit is sourced through audited supply channels and undergoes pre-shipment inspection before dispatch.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 00-106-446 |
| Manufacturer | KUKA Roboter GmbH |
| Compatible Robot Models | KR 150, KR 180, ZH 150, ZH 180 |
| Application Axes | Axis 1, Axis 2, Axis 3 |
| Component Type | Precision Planetary / Cycloidal Gearbox (Reducer) |
| Robot Series Platform | KUKA KR C / KR C2 Generation |
| Payload Class | 150 kg – 180 kg |
| Country of Origin | Germany (DE) |
| Unit Weight | 323 kg |
| Condition | New / Refurbished OEM (specify on inquiry) |
| Warranty | 12 months (contact for details) |
Proven Application Environments
- Automotive Body-in-White: Spot welding and material handling lines requiring sustained 150–180 kg payload capacity at high duty cycles.
- Foundry & Die Casting: ZH shelf-mount configuration for overhead part extraction in thermally aggressive environments.
- Heavy Assembly: Engine block and transmission assembly stations where axis repeatability directly impacts torque-bolt quality.
- Palletizing & Logistics: High-throughput end-of-line palletizing with continuous multi-shift operation.
- Maintenance & Overhaul (MRO): Direct OEM-compatible replacement to minimize robot downtime during scheduled or emergency maintenance.
Engineering Advantages
- OEM Dimensional Compatibility: Exact bolt pattern, shaft interface, and housing geometry — no field modification required.
- Backlash Control: Maintains KUKA-specified angular backlash limits to preserve TCP repeatability (±0.06 mm class).
- Torsional Rigidity: High-stiffness gear train sustains rated torque under shock-load conditions typical of heavy-payload cycles.
- Sealed Lubrication System: Factory-filled with KUKA-approved grease; compatible with standard KUKA re-lubrication intervals.
- Thermal Stability: Rated for continuous operation across industrial ambient temperature ranges without derating.
System Architecture & Signal Flow
In the KR 150 / KR 180 kinematic chain, the 00-106-446 gearbox sits between the axis servo motor output shaft and the robot structural arm link. The servo drive (KSD / KPP) delivers torque commands via the KR C controller; the gearbox reduces motor speed and multiplies torque to drive the arm link through its working envelope. Correct installation torque on the mounting flange and proper grease fill level are critical to achieving rated service life — refer to KUKA documentation BA KR 150/180 for torque specifications.
Sourcing & Quality Verification
- All units sourced through audited industrial automation supply channels.
- Pre-shipment visual and dimensional inspection performed on every unit.
- Part number 00-106-446 verified against KUKA spare parts catalog cross-reference.
- Packaging: industrial-grade crating with moisture barrier for international freight.
- Documentation available: packing list, inspection report, certificate of origin on request.
Procurement Process
- Inquiry: Submit your robot serial number and current fault description to [email protected] for compatibility confirmation.
- Quotation: Receive a formal quotation with lead time, unit price (HKD/USD), and freight options within 1 business day.
- Order Confirmation: Purchase order or online checkout accepted; proforma invoice issued for bank transfer orders.
- Inspection & Dispatch: Pre-shipment inspection completed; tracking number provided within 24–48 hours of payment clearance.
- Delivery: DHL / FedEx / freight forwarder options available; export documentation (commercial invoice, packing list, COO) included.
- After-Sales: 12-month warranty support; technical installation guidance available via email or video call.
Technical FAQ
Q: Is 00-106-446 compatible with both KR 150 and KR 180?
A: Yes. The gearbox is a shared component across the KR 150, KR 180, ZH 150, and ZH 180 variants within the same robot generation. Always confirm with your robot serial number.
Q: What is the difference between KR and ZH variants?
A: KR denotes floor-mount configuration; ZH (Zentralhand) denotes shelf/ceiling-mount configuration. The gearbox unit itself is mechanically identical — mounting orientation and cable routing differ.
Q: Can this gearbox be used on KR C4-generation robots?
A: The 00-106-446 is catalogued for the KR C / KR C2 generation. KR C4 variants may use a different part number. Please provide your robot type plate data for confirmation.
Q: Do you supply new or refurbished units?
A: Both options are available subject to stock. Please specify your requirement at inquiry stage. All refurbished units are fully inspected and tested.
Q: What is the typical lead time?
A: In-stock units ship within 2–3 business days. Out-of-stock lead time is 2–4 weeks depending on sourcing. Contact us for real-time availability.
