KUKA 00-186-965 / 00-186-963 AB4582-B Robot Servo Motor Unit | KR C Series Platform
Engineering Background
The KUKA AB4582-B motor family is purpose-engineered for the KR C series robotic arm platform, delivering high-torque, precision-controlled rotational output across demanding industrial cycles. Part numbers 00-186-965 (3.2 kW) and 00-186-963 (2.5 kW) are OEM-designated servo motor units used in axis drives A1–A6, covering the full range of payload classes from 6 kg to 60 kg robots.
Product Positioning
Konmask.com supplies these units to MRO engineers, system integrators, and OEM rebuild shops requiring verified, traceable replacements with minimal lead time. Both variants share the AB4582-B mechanical frame, enabling cross-platform stocking strategies and simplified spare-parts management.
Complete Technical Specifications
| Parameter | 00-186-965 | 00-186-963 |
|---|---|---|
| KUKA Part Number | 00-186-965 | 00-186-963 |
| Frame / Series Code | AB4582-B | AB4582-B |
| Rated Power | 3.2 kW | 2.5 kW |
| Motor Type | AC Servo (Brushless) | AC Servo (Brushless) |
| Platform Compatibility | KR C2 / KR C4 | KR C2 / KR C4 |
| Applicable Axes | A1 – A3 (primary axes) | A4 – A6 (wrist axes) |
| Encoder Type | Absolute multi-turn resolver | Absolute multi-turn resolver |
| Cooling Method | Natural convection / forced air | Natural convection / forced air |
| Protection Rating | IP65 | IP65 |
| Weight (approx.) | ~600 g | ~600 g |
| Country of Origin | Germany | Germany |
| HS Code | 850152 | 850152 |
Proven Application Environments
- Automotive body-in-white welding lines — continuous duty cycles up to 24/7 operation
- Palletizing & material handling — KR 16 / KR 30 / KR 60 payload classes
- Arc welding & laser cutting cells — high-precision path repeatability ±0.05 mm
- Assembly automation — collaborative and semi-collaborative workcells
- Foundry & press-tending — high-temperature ambient environments up to 55 °C
Engineering Advantages
- OEM-identical form factor — direct bolt-in replacement; no mechanical adaptation required
- Absolute encoder retention — preserves mastering data on swap, reducing re-mastering downtime
- Dual-SKU stocking strategy — AB4582-B frame shared across both power ratings simplifies warehouse management
- Thermal stability — rated for ambient temperatures −10 °C to +55 °C
- EMC-compliant wiring harness interface — compatible with KUKA KPP / KSP servo drives
System Architecture & Signal Flow
In the KR C4 architecture, the motor unit interfaces with the KPP 600-20 (power supply) and KSP 600-3×40 (servo drive) via the KCB (KUKA Cabinet Bus). The resolver feedback loop is processed by the DSE-IBS board, which transmits axis position data to the VxWorks real-time kernel at 12 ms interpolation cycles. For KR C2 installations, the motor connects to the KSD 48/10 servo drive module within the controller cabinet.
Signal path: KRC controller → KPP power module → KSP servo drive → Motor power connector (X20) → Resolver feedback (X7) → DSE board → KRC
Sourcing & Quality Verification
- Units sourced from authorized KUKA distribution channels and certified MRO partners
- Each unit inspected for: connector integrity, resolver continuity, winding resistance, and insulation resistance (>100 MΩ @ 500 VDC)
- Packaging: anti-static foam insert, moisture-barrier bag, individual serial number label
- Traceability: KUKA production date code and batch number retained on nameplate
- Shelf life: unlimited when stored at 15–25 °C, RH <60%, away from magnetic fields
Procurement Process
- Confirm part number (00-186-965 or 00-186-963) against your robot’s nameplate or KRC controller BOM
- Submit inquiry via support@konmask.com or place order directly on Konmask.com
- Lead time: in-stock units ship within 1–3 business days; EXW Xiamen, China
- Shipping: DHL Express / FedEx IP / UPS Worldwide — typical transit 3–7 days globally
- Documentation available: commercial invoice, packing list, CE declaration, test report on request
Technical FAQ
Q: Are 00-186-965 and 00-186-963 interchangeable?
A: No. While they share the AB4582-B mechanical frame, the power ratings and axis assignments differ. Always match the part number to the specific axis and robot model per the KUKA spare parts catalog.
Q: Is re-mastering required after motor replacement?
A: Yes, KUKA standard procedure requires EMD (Electronic Mastering Device) re-mastering after any motor swap, even with absolute encoders, to confirm zero-point calibration.
Q: Can these motors be repaired/rewound?
A: KUKA does not recommend field rewinding. Konmask supplies only complete OEM units to ensure resolver calibration and winding specifications are factory-correct.
Q: What warranty is provided?
A: 12-month warranty against manufacturing defects from date of shipment. Contact support@konmask.com for RMA procedures.
