KUKA KPP 600-20 Controller Drive Power Module | KR C4 / KR C4 Compact Platform
Engineering Background: The KPP 600-20 series is KUKA’s dedicated Controller Drive Power Supply (Kondensatorpaket / Power Pack) designed for the KR C4 robot controller family. It provides regulated DC bus power to the KSD servo drives, enabling precise multi-axis motion control in demanding industrial environments. Three part variants cover different output configurations: KPP 600-20 2X40 (PN: 00-160-152), KPP 600-20 3X20 UL (PN: 00-245-213), and KPP 600-20 UL (PN: 00-198-259).
Product Positioning: Sourced directly from verified KUKA-authorized channels and tested OEM pull inventory, this module is the critical power backbone for KR C4-based robot cells. It is the preferred replacement unit for maintenance engineers managing KUKA KR 6, KR 10, KR 16, KR 20, KR 30, and KR 60 robot arms in automotive, electronics, and general manufacturing lines.
Complete Technical Specifications
- Manufacturer: KUKA Roboter GmbH (Germany)
- Series / Platform: KR C4 / KR C4 Compact Controller
- Module Type: Controller Drive Power Supply (KPP)
-
Part Numbers:
- KPP 600-20 2X40 — PN: 00-160-152 (Dual-axis 40A output)
- KPP 600-20 3X20 UL — PN: 00-245-213 (Triple-axis 20A, UL-listed)
- KPP 600-20 UL — PN: 00-198-259 (Standard UL-listed variant)
- Input Voltage: 3-phase AC 400 V / 480 V (±10%)
- DC Bus Output Voltage: 600 V DC
- Rated Current: 20 A continuous (peak per axis as per variant)
- Cooling: Forced air (integrated fan)
- Protection Class: IP20 (cabinet-mounted)
- Operating Temperature: 0 °C to +45 °C
- Storage Temperature: −25 °C to +70 °C
- Weight: Approx. 800 g
- Certifications: CE, UL (UL variants)
- Compatible Controllers: KR C4, KR C4 Compact, KR C4 smallSize
Proven Application Environments
- Automotive body-in-white welding and assembly lines (KUKA KR 16 / KR 30 cells)
- Electronics PCB handling and pick-and-place automation
- Palletizing and depalletizing systems (KR 60 / KR 120 configurations)
- Machine tending and CNC loading applications
- Collaborative robot cells requiring KR C4 Compact controllers
- Aerospace component machining and inspection lines
Engineering Advantages
- Drop-in Replacement: Direct OEM form-factor — no wiring modification required for KR C4 cabinet swap-out.
- Multi-variant Coverage: Single listing covers three PN variants; confirm your PN before ordering or contact us for cross-reference verification.
- UL-Listed Options: 00-245-213 and 00-198-259 carry UL certification for North American installations.
- Tested Before Shipment: Each unit undergoes DC bus voltage output verification and insulation resistance testing prior to dispatch.
- Genuine OEM Parts: No third-party remanufactured or counterfeit components — traceable to KUKA supply chain.
System Architecture & Signal Flow
The KPP 600-20 rectifies incoming 3-phase AC mains into a stabilized 600 V DC bus. This bus feeds the KSD (KUKA Servo Drive) modules mounted in the same KR C4 cabinet. The KPC (KUKA Power Controller) manages enable/disable signals via the SIB (Safety Interface Board), ensuring STO (Safe Torque Off) compliance per IEC 62061 / ISO 13849-1 PLd. The KPP also manages regenerative braking energy via the internal ballast resistor circuit, protecting the DC bus during deceleration events.
Sourcing & Quality Verification
- All units are sourced from KUKA-authorized distributors or verified OEM pull inventory from decommissioned robot cells.
- Each module is inspected for physical damage, connector integrity, and capacitor condition.
- Functional test report available upon request for critical production line replacements.
- Traceability documentation (serial number, production date code) provided with shipment.
Procurement Process
- Confirm your exact part number (00-160-152 / 00-245-213 / 00-198-259) from the module label or KR C4 cabinet BOM.
- Contact [email protected] or call +0086 19859288691 for stock confirmation and lead time.
- Submit PO with delivery address — we support DDP, DAP, EXW Incoterms.
- Shipment via DHL Express / FedEx International Priority with full tracking.
- 30-day warranty on all tested units; 12-month warranty on new-in-box stock.
Technical FAQ
Q: Can KPP 600-20 2X40 (00-160-152) replace KPP 600-20 3X20 UL (00-245-213)?
A: These are different output configurations (2×40A vs 3×20A). Cross-replacement requires KR C4 cabinet reconfiguration and KUKA WorkVisual project update. Contact our engineers for compatibility assessment.
Q: Is the KPP 600-20 UL (00-198-259) compatible with 480V North American mains?
A: Yes. The KPP 600-20 series accepts 400–480V AC input and the UL variants are certified for North American installations.
Q: What is the typical failure mode for KPP 600-20 modules?
A: Most common failures include DC bus capacitor degradation (visible as E1292 / E1293 fault codes on KR C4) and IGBT bridge failure due to sustained overload. Our pre-shipment test covers both failure modes.
Q: Do you provide installation support?
A: Yes. Remote commissioning guidance via email or video call is available at no charge for verified purchasers.
