Industrial Robot Motion Control Solution – KUKA KSD1-48C200-105-413 | KSD1 Series Servo Drive
When a KUKA robot arm freezes mid-cycle on an automotive welding line or a palletizing cell loses axis control during a high-throughput shift, the root cause is almost always the servo drive. The KUKA KSD1-48C200-105-413 is the precision servo drive unit engineered to power and regulate KUKA robot joint motors — and without it, the entire robotic cell comes to a standstill, halting production and triggering costly downtime. No substitute, no workaround: this is the part that keeps the robot moving.
Within the KSD1 series, the KSD1-48C200-105-413 variant is specified for high-current, 48V DC bus applications, delivering up to 200A peak output to drive demanding joint axes in KUKA KR, KRC, and compatible robot platforms. The KSD1 series is a cornerstone of KUKA’s modular drive architecture, widely deployed across automotive, aerospace, electronics manufacturing, and logistics automation worldwide. Its compact DIN-rail-compatible form factor and robust EMC design make it a preferred choice for system integrators building high-reliability robotic workcells.
Where This Product Is Used
- Automotive Body-in-White (BIW) Welding Lines — Powers KUKA KR 16, KR 30, and KR 60 robots performing spot welding and seam welding on vehicle chassis, where continuous high-torque axis control is critical.
- Automotive Paint Shop Robots — Drives articulated arm axes in paint application robots requiring smooth, vibration-free motion for consistent coating quality.
- Palletizing & Depalletizing Cells — Controls heavy-payload KUKA robots stacking and unstacking goods at high cycle rates in FMCG and logistics warehouses.
- Machine Tending & CNC Loading — Provides precise positioning for robots loading/unloading CNC machining centers, ensuring repeatability within ±0.05 mm.
- Electronics Assembly & PCB Handling — Enables fine-motion control in cleanroom-compatible KUKA cells handling sensitive electronic components.
- Aerospace Component Machining — Supports large-frame KUKA robots performing drilling, riveting, and surface finishing on aircraft structural parts.
- MRO & Spare Parts Replacement — Direct replacement unit for failed KSD1-48C200-105-413 drives in existing KUKA robot installations globally.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | KSD1-48C200-105-413 |
| Brand | KUKA |
| Series | KSD1 |
| Product Type | Robot Servo Drive / Motor Drive Unit |
| DC Bus Voltage | 48V DC |
| Peak Output Current | 200A |
| Compatible Controllers | KUKA KRC2, KRC4 (verify with system documentation) |
| Weight | Approx. 580g |
| Condition Available | New / Refurbished / Used-Tested |
Note: All specifications are based on KUKA published documentation. Konmask.com does not fabricate or alter technical data. Confirm compatibility with your robot controller version before ordering.
Why Engineers Specify This Model
- High Peak Current Capacity (200A) — Handles the instantaneous torque demands of heavy-payload robot axes without thermal derating during aggressive duty cycles.
- 48V DC Bus Architecture — Matches KUKA’s low-voltage high-current drive bus design, ensuring compatibility with the KSD1 series power supply and regenerative braking modules.
- Modular KSD1 Platform — Plug-and-play replacement within existing KSD1 drive cabinets; no rewiring or controller reconfiguration required when replacing a like-for-like unit.
- Robust EMC Shielding — Designed to operate in electrically noisy industrial environments alongside welding equipment, VFDs, and high-frequency machinery.
- Proven Field Reliability — Deployed in millions of KUKA robot installations across 6 continents; extensive global MRO supply chain ensures long-term parts availability.
- Compact Form Factor — Space-efficient design fits within standard KUKA KRC drive cabinets without modification.
Complete System Bill of Materials
The KSD1-48C200-105-413 operates as part of a coordinated KUKA drive system. Common companion parts include:
- KUKA KPS-600/20 — KSD1 Series Power Supply Unit
- KUKA KSD1-16 / KSD1-08 — Smaller-axis companion servo drives
- KUKA KRC4 Controller Cabinet — System controller housing the KSD1 drive rack
- KUKA SmartPAD / KCP2 Teach Pendant — Operator interface for robot programming
- KUKA Motor Cables (48V, shielded) — Axis motor power and resolver cables
- KUKA Resolver / Encoder Feedback Modules — Position feedback for closed-loop control
Contact support@konmask.com for a complete BOM quote for your KUKA robot model.
Compliance & Industry Standards
- Designed and manufactured under KUKA’s ISO 9001-certified quality management system
- CE Marked — Compliant with EU Machinery Directive and EMC Directive
- RoHS Compliant (verify specific batch with documentation)
- Compatible with IEC 61800 series standards for adjustable speed electrical power drive systems
- Suitable for use in ISO 10218-compliant industrial robot safety installations
Quality Assurance & Sourcing
At Konmask.com, every KUKA servo drive unit undergoes a structured verification process before dispatch:
- Visual Inspection — Connectors, PCB, housing, and labeling checked for damage or tampering
- Part Number Verification — Physical label cross-referenced against order specification and KUKA part database
- Functional Test (where applicable) — Refurbished and used units bench-tested on KUKA-compatible test rigs
- Anti-Static Packaging — All drives shipped in ESD-safe bags with foam cushioning
- Traceability Documentation — Test reports and sourcing certificates available on request
We source from authorized KUKA distributors, certified MRO suppliers, and decommissioned-equipment refurbishers with full chain-of-custody documentation.
How to Source This Part
- Submit an Inquiry — Email support@konmask.com or call +0086 19859288691 with your part number and required quantity.
- Receive a Quote — Our team responds within 24 hours with pricing, lead time, and condition options (new / refurbished / used-tested).
- Confirm & Pay — Secure payment via T/T bank transfer, PayPal, or other agreed methods.
- Dispatch & Track — Parts shipped via DHL / FedEx / UPS with full tracking. Export documentation provided for international orders.
- After-Sales Support — Technical assistance available post-delivery for installation verification.
Application-Specific FAQ
Q: Is the KSD1-48C200-105-413 compatible with KUKA KRC2 and KRC4 controllers?
A: The KSD1 series was primarily designed for KRC2-era drive cabinets. Compatibility with KRC4 depends on the specific cabinet configuration. Always verify with your KUKA system documentation or contact our technical team before ordering.
Q: Can I replace a faulty KSD1-48C200-105-413 without reprogramming the robot?
A: In most cases, a like-for-like drive replacement does not require robot reprogramming. However, drive parameters stored in the unit may need to be reloaded from the KRC controller backup. Consult your KUKA service manual.
Q: Do you supply new or refurbished units?
A: We supply both. New units come with full OEM packaging where available. Refurbished units are tested and certified by our technical team. Condition is clearly stated in your quotation.
Q: What is the typical lead time for this part?
A: In-stock units ship within 1–3 business days. For sourced units, lead time is typically 5–15 business days depending on global availability.
Q: Can you supply the full KSD1 drive set for a KUKA robot?
A: Yes. We can supply complete KSD1 drive sets including power supply, axis drives, and cables. Contact us with your robot model and axis configuration for a complete quote.
Q: Do you provide export documentation for international shipments?
A: Yes. We provide commercial invoices, packing lists, and certificates of origin. For specific country requirements, please advise at the time of inquiry.
