Industrial Position Sensing Solution — KWANGWOO RAA-001007-2102 | Rotary Encoder Series
Where This Product Is Used
The KWANGWOO RAA-001007-2102 Rotary Encoder is deployed across demanding industrial environments where precise angular position or rotational speed feedback is critical to system performance and safety:
- CNC Machining Centers & Lathes — Closed-loop axis position feedback for X/Y/Z spindle control, ensuring sub-millimeter repeatability.
- Servo Drive Systems — Real-time shaft position reporting to servo amplifiers (e.g., Siemens SINAMICS, Mitsubishi MR-J series) for torque and velocity regulation.
- Conveyor & Material Handling Lines — Speed synchronization across multi-motor conveyor segments in automotive, food processing, and logistics facilities.
- Packaging Machinery — Registration mark detection and film-feed length control on form-fill-seal and labeling equipment.
- Crane & Hoist Systems — Drum rotation counting and overtravel limit detection in overhead cranes and port equipment.
- Printing & Paper Converting — Web tension control and print-register alignment on offset and flexographic presses.
- Robotics & Collaborative Arms — Joint angle feedback in articulated robot arms requiring high-resolution position data.
- Wind Turbine Pitch Control — Blade pitch angle monitoring in renewable energy installations.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | KWANGWOO |
| Part Number | RAA-001007-2102 |
| Product Type | Rotary Encoder |
| SKU | RAA-001007-2102 |
| Output Type | Please confirm with datasheet (incremental / absolute) |
| Resolution (PPR) | Refer to official KWANGWOO datasheet |
| Supply Voltage | Refer to official KWANGWOO datasheet |
| Output Signal | Refer to official KWANGWOO datasheet |
| Shaft Diameter | Refer to official KWANGWOO datasheet |
| Protection Rating | Refer to official KWANGWOO datasheet |
| Operating Temperature | Refer to official KWANGWOO datasheet |
| Weight | 100 g (approx.) |
| Country of Origin | To be confirmed |
Note: For full electrical and mechanical specifications, please request the official KWANGWOO RAA-001007-2102 datasheet via support@konmask.com.
Why Engineers Specify This Model
- Brand Reliability — KWANGWOO encoders are recognized in Asian industrial markets for consistent build quality and long MTBF in continuous-duty applications.
- Drop-in Compatibility — The RAA-001007-2102 form factor and connector pinout are designed for straightforward integration into existing encoder mounting flanges and PLC/drive input cards.
- Robust Construction — Metal housing and sealed bearing assembly resist vibration, dust, and coolant splash common in machine-tool environments.
- Signal Integrity — Differential line-driver output (where applicable) ensures noise immunity over long cable runs in electrically noisy factory floors.
- Proven in MRO & OEM Contexts — Suitable both as an OEM build component and as a maintenance replacement for worn or damaged encoders on legacy equipment.
Complete System Bill of Materials
For a complete rotary encoder feedback loop, engineers typically source the following alongside the RAA-001007-2102:
- Encoder cable with shielded twisted pairs (A, B, Z channels + power) — matched connector to drive/PLC input module
- Flexible shaft coupling (zero-backlash bellows or jaw type) — to absorb misalignment and protect encoder bearings
- Encoder mounting bracket / flange adapter — if replacing a different-frame encoder
- PLC high-speed counter module (e.g., Siemens FM350, Mitsubishi QD62) — for pulse counting and position calculation
- Servo drive or frequency inverter with encoder feedback input — for closed-loop speed/position control
- Cable conduit and ferrite cores — for EMI suppression on signal lines
Contact support@konmask.com for bundled BOM sourcing assistance.
Compliance & Industry Standards
- Designed for use in industrial automation environments in accordance with general IEC 61010 safety principles for measurement and control equipment.
- Encoder signal interfaces compatible with RS-422 / TTL differential standards (verify per datasheet).
- RoHS compliance status: please confirm with KWANGWOO official documentation prior to use in restricted-substance regulated markets (EU, California Prop 65).
- CE marking applicability: confirm with manufacturer declaration of conformity.
Quality Assurance & Sourcing
Konmask.com sources industrial automation components through verified supply channels with a focus on authenticity and traceability:
- Authenticity — All units are inspected upon receipt; counterfeit or non-conforming parts are rejected and not listed.
- Traceability — Batch and lot documentation available on request for OEM and MRO procurement teams.
- Condition — New, original packaging unless explicitly stated otherwise in the listing.
- Lead Time — Contact us for current stock availability and lead time before placing large-volume orders.
- Warranty — Subject to Konmask.com standard warranty terms; contact support for details.
How to Source This Part
- Confirm your application requirements — resolution (PPR), voltage, output type, shaft size, and mounting configuration.
- Request a datasheet — Email support@konmask.com with your application details for the official KWANGWOO RAA-001007-2102 datasheet and cross-reference guide.
- Request a quote — Provide quantity, delivery address, and required lead time. Volume pricing is available for orders of 5+ units.
- Place your order — Secure checkout via this product page, or request a proforma invoice for bank transfer / corporate PO payment.
- Track & receive — Shipment tracking provided; packaging includes original manufacturer labeling for incoming inspection.
📞 +0086 19859288691 | ✉️ support@konmask.com
Application-Specific FAQ
Q: Can the RAA-001007-2102 replace my existing encoder without rewiring?
A: It depends on the output type (incremental vs. absolute) and connector pinout of your current encoder. Contact us with your existing part number for a compatibility check.
Q: What is the maximum cable length supported?
A: For differential (RS-422) output variants, cable runs up to 100 m are typically achievable with proper shielded cable. Confirm with the datasheet for your specific variant.
Q: Is this encoder suitable for food-grade or washdown environments?
A: Only if the IP rating meets your washdown requirements. Please verify the protection class in the datasheet before specifying for food & beverage applications.
Q: Can I use this with a Siemens S7 or Mitsubishi Q-series PLC?
A: Yes, provided the PLC high-speed counter module supports the encoder’s output signal type (TTL/RS-422). Wiring diagrams available on request.
Q: Do you offer technical support for integration?
A: Yes. Our engineering support team can assist with wiring, parameter configuration, and troubleshooting. Reach us at support@konmask.com.
