LAZER LHZ004 – Laser Safety Interlock Controller | Trumpf Lazersafe Platform
Engineering Background: The LAZER LHZ004 is a dedicated laser safety controller engineered for integration with Trumpf laser cutting and welding systems. Designed to monitor and enforce laser safety interlocks, the LHZ004 ensures compliance with IEC 60825 and EN ISO 13849 safety standards in high-throughput industrial laser environments. This module is a critical component in Trumpf Lazersafe safety architectures, providing real-time interlock monitoring, fault detection, and safe-state output control.
Product Positioning: The LHZ004 is purpose-built for OEM and MRO procurement engineers maintaining Trumpf laser systems across automotive, aerospace, sheet metal fabrication, and precision manufacturing facilities. As a direct replacement or spare part, it delivers drop-in compatibility with existing Trumpf Lazersafe wiring harnesses and control cabinets, minimizing downtime and re-engineering costs.
Complete Technical Specifications
- Part Number / SKU: LHZ004
- Manufacturer: LAZER
- Series / Platform: Trumpf Lazersafe Safety Controller Series
- Function: Laser safety interlock controller and monitoring module
- Compatibility: Trumpf Lazersafe-equipped laser cutting and welding systems
- Safety Standards: IEC 60825 (Laser Safety), EN ISO 13849 (Safety of Machinery)
- Safety Integrity Level: SIL 2 / Performance Level d (PLd)
- Weight: 3,140 g (3.14 kg)
- Mounting: Panel / DIN rail mount (per Trumpf cabinet specification)
- Operating Environment: Industrial control cabinet, EMC-shielded enclosure
- Country of Origin: Germany (Trumpf OEM supply chain)
- Condition: New / Refurbished OEM-grade (specify at inquiry)
Proven Application Environments
- Trumpf TruLaser series laser cutting machines (CO₂ and solid-state)
- Trumpf TruMark and TruPulse laser marking and welding systems
- Automotive body-in-white laser welding lines
- Aerospace precision laser drilling and cutting cells
- Sheet metal fabrication and tube laser processing centers
- Medical device laser processing equipment
- Semiconductor and electronics laser micro-machining
Engineering Advantages
- Drop-in OEM Replacement: Direct pin-compatible with Trumpf Lazersafe wiring harnesses — no rewiring or firmware changes required.
- Certified Safety Architecture: Supports SIL 2 / PLd safety loop integrity for laser interlock circuits.
- Fast Fault Response: Sub-millisecond safe-state output switching on interlock breach detection.
- Robust EMC Design: Shielded housing and filtered I/O for reliable operation in high-RF laser environments.
- Reduced Downtime: Stocked for immediate dispatch — critical for minimizing unplanned laser system downtime.
- Traceable Quality: Each unit inspected and function-tested prior to shipment; documentation available on request.
System Architecture & Signal Flow
The LHZ004 interfaces directly with the Trumpf Lazersafe safety bus, monitoring all configured interlock zones — door interlocks, beam shutters, key switches, and E-stop circuits. On detection of an interlock fault, the controller immediately de-energizes the laser enable output and logs the fault state for diagnostic retrieval via the Trumpf machine HMI. The module communicates with the main Trumpf CNC/PLC via a dedicated safety-rated I/O interface, ensuring the laser source cannot be re-enabled until all interlocks are cleared and the safety reset sequence is completed by a qualified operator.
Sourcing & Quality Verification
- Sourced through verified Trumpf OEM and authorized industrial surplus channels
- Each unit undergoes incoming inspection: visual, dimensional, and functional verification
- Serialization and traceability documentation available upon request
- Counterfeit-prevention: all units verified against OEM part markings and label authentication
- Packaging: anti-static ESD bag + foam-lined export carton, suitable for international air and sea freight
Procurement Process
- Confirm Compatibility: Provide your Trumpf machine model and existing LHZ004 serial number for cross-reference verification.
- Request Quote: Contact us via email at support@konmask.com with quantity and delivery requirements.
- Order Confirmation: Pro-forma invoice issued within 1 business day; payment via T/T, PayPal, or trade credit.
- Dispatch: In-stock units ship within 2–3 business days via DHL Express / FedEx International with full tracking.
- After-Sales Support: 12-month warranty on verified OEM units; technical support from our engineering team.
Technical FAQ
Q: Is the LHZ004 compatible with all Trumpf Lazersafe versions?
A: The LHZ004 is designed for the Trumpf Lazersafe platform. Please confirm your machine’s Lazersafe version (V1/V2/V3) when ordering to ensure exact firmware and hardware compatibility.
Q: Can this unit be reprogrammed or reconfigured?
A: The LHZ004 is a factory-configured safety controller. Reconfiguration requires Trumpf service authorization. We supply units pre-configured to OEM specification.
Q: Do you provide a test report?
A: Yes. A functional test report is available upon request for all units. Serialized traceability documentation can be provided for regulated industries.
Q: What is the lead time for out-of-stock units?
A: Typical lead time for sourced units is 4–8 weeks. Contact us early to avoid production delays.
Q: Do you ship to the EU, USA, and Southeast Asia?
A: Yes. We ship worldwide via DHL Express, FedEx, and UPS. Export documentation (commercial invoice, packing list, COO) provided for all international shipments.
